2001 TOYOTA AVALON Service Repair Manual

SA0W7-03
- SUSPENSION AND AXLEREAR AXLE HUB
SA-47
1381 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-45).
HINT:
After installation, check the ABS speed sensor signal (See page DI-212 or DI-252) and rear wheel align-
ment (See page SA-7).

SA0W6-02
R10948
Z00206
W03211
A
A
B
- SUSPENSION AND AXLEREAR AXLE HUB
SA-45
1379 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. REMOVE REAR WHEEL
Torque: 103 N´m (1,050 kgf´cm, 76 ft´lbf)
2. REMOVE BRAKE CALIPER AND DISC
(a) Remove the brake caliper and disc.
Torque: 47 N´m (475 kgf´cm, 34 ft´lbf)
(b) Support the brake caliper securely.
3. CHECK BEARING BACKLASH AND AXLE HUB DEVI-
ATION
(a) Using a dial indicator, check the backlash near the center
of the axle hub.
Maximum: 0.05 mm (0.0020 in.)
If the backlash exceeds the maximum, replace the axle hub.
(b) Using a dial indicator, check the deviation at the surface
of the axle hub outside the hub bolt.
Maximum: 0.07 mm (0.0028 in.)
If the deviation exceeds the maximum, replace the axle hub.
4. DISCONNECT ABS SPEED SENSOR
Remove the bolt and disconnect the ABS speed sensor.
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
5. REMOVE REAR AXLE HUB
(a) Remove the 4 bolts and rear axle hub.
Torque: 80 N´m (820 kgf´cm, 59 ft´lbf)
(b) Remove the O-ring.
HINT:
At the time of installation, coat a new O-ring with MP grease.
(c) Support the backing plate securely.
6. REMOVE REAR AXLE CARRIER
(a) Loosen the 3 nuts.
Torque:
Nut A (Reused nut): 196 N´m (2,000 kgf´cm, 145 ft´lbf)
Nut A (New nut): 255 N´m (2,600 kgf´cm, 188 ft´lbf)
Nut B: 181 N´m (1,850 kgf´cm, 134 ft´lbf)

R11165
SA-46
- SUSPENSION AND AXLEREAR AXLE HUB
1380 Author
: Date
:
2001 AVALON (RM808U)
HINT:
At the time of installation, please refer to the following items.

After stabilizing the suspension, torque the nuts.

If reusing the 2 nuts A, coat the nut's threads with engine
oil.
(b) Remove the bolt and nut, and disconnect the strut rod
from the rear axle carrier.
NOTICE:
Do not turn the nut.
Torque: 113 N´m (1,150 kgf´cm, 83 ft´lbf)
(c) Remove the 2 nuts and bolts on the lower side of the
shock absorber.
(d) Remove the nut, washer and bolt and disconnect the No.
1 and No. 2 lower suspension arm from the rear axle carri-
er.
(e) Remove the rear axle carrier.

SA0VF-02
F07385
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part

38 (390, 28)
51 (520, 38)
51 (520, 38)
56 (570, 41)
181 (1,850, 134)
19 (195, 14)
181 (1,850, 134)
113 (1,150, 83)
5.4 (55, 48 in.´lbf)
113 (1,150, 83)
43 (440, 32)
Suspension Member Lower Stopper Suspension Member Lower Stopper
Suspension Member
Adjusting
TubeStabilizer
Bar Bracket
Suspension
Arm Washer
No. 2 Lower Suspension Arm
No. 1 Lower Suspension Arm
Parking Brake Cable
Strut Rod
Heated Oxygen
Sensor

Gasket Tailpipe
Center Exhaust Pipe

GasketSuspension Member Upper Stopper43 (440, 32)
SA-56
- SUSPENSION AND AXLEREAR LOWER SUSPENSION ARM AND STRUT ROD
1390 Author
: Date
:
2001 AVALON (RM808U)
REAR LOWER SUSPENSION ARM AND STRUT ROD
COMPONENTS

SA1F8-02
F06459
F06461
- SUSPENSION AND AXLEREAR LOWER SUSPENSION ARM AND STRUT ROD
SA-59
1393 Author
: Date
:
2001 AVALON (RM808U)
DISASSEMBLY
DISASSEMBLE NO. 2 LOWER SUSPENSION ARM
(a) Loosen the 2 lock nuts.
(b) Turn the adjusting tube and disassemble the No. 2 lower
suspension arm.
(c) Remove the 2 lock nuts.

SA0VJ-02
- SUSPENSION AND AXLEREAR LOWER SUSPENSION ARM AND STRUT ROD
SA-61
1395 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-57).
HINT:
After installation, check the rear wheel alignment (See page SA-7).

SA1F9-02
F06460
W03223
AB
F06462
SA-60
- SUSPENSION AND AXLEREAR LOWER SUSPENSION ARM AND STRUT ROD
1394 Author
: Date
:
2001 AVALON (RM808U)
REASSEMBLY
ASSEMBLE NO. 2 LOWER SUSPENSION ARM
(a) Install the 2 lock nuts.
(b) Turn the adjusting tube and assemble the No. 2 lower
suspension arm.
HINT:
When assembling the No. 2 lower suspension arm, try to make
sure that the lengths of A and B shown in the illustration are the
same.
Maximum difference: 3.0 mm (0.118 in.)
(c) Adjust the No. 2 lower suspension arm length by turning
the adjusting tube.
Arm length: 512.3 mm (20.169 in.)
(d) Temporarily tighten the 2 lock nuts.
HINT:
After adjusting the rear wheel alignment, torque the lock nuts
(See page SA-7).
Torque: 56 N´m (570 kgf´cm, 41 ft´lbf)

SA0VG-02
W03216
W03217
Rear
F06465A
A B
B
- SUSPENSION AND AXLEREAR LOWER SUSPENSION ARM AND STRUT ROD
SA-57
1391 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. REMOVE REAR WHEEL
Torque: 103 N´m (1,050 kgf´cm, 76 ft´lbf)
2. REMOVE CENTER EXHAUST PIPE
3. REMOVE STRUT ROD
(a) Remove the bolt and disconnect the parking brake cable.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(b) Remove the 2 bolts and nuts.
Torque: 113 N´m (1,150 kgf´cm, 83 ft´lbf)
NOTICE:
Do not turn the nut.
HINT:
At the time of installation, after stabilizing the suspension,
torque the bolts.
(c) Remove the strut rod.
4. REMOVE NO. 2 LOWER SUSPENSION ARM
(a) Remove the 3 nuts, suspension arm washer and washer.
Torque: 181 N´m (1,850 kgf´cm, 134 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nuts.
(b) Remove the No. 2 lower suspension arm.
HINT:
At the time of installation, face the paint mark to the rearward.
5. REMOVE STABILIZER BAR BRACKETS
(See page SA-63)
6. REMOVE NO. 1 LOWER SUSPENSION ARM
(a) Support the suspension member with a jack.
(b) Remove the 4 nuts, 2 bolts and 8 suspension member
stoppers.
Torque:
A: 51 N´m (520 kgf´cm, 38 ft´lbf)
B: 38 N´m (390 kgf´cm, 28 ft´lbf)
(c) Lower the suspension member.
