- BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE-1
1605 Author
: Date
:
2001 AVALON (RM808U)
BODY ELECTRICAL SYSTEM
PRECAUTION
HINT:
Take care to observe the following precautions when performing inspections or removal and replacement
of body electrical related parts.
1. HEADLIGHT SYSTEM
Halogen bulbs have pressurized gas inside and require special handling. They can burst if scratched or
dropped. Hold a bulb only by its plastic or metal case. Don't touch the glass part of a bulb with bare hands.
2. SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
The AVALON is equipped with an SRS (Supplemental Restraint System) such as the driver airbag and front
passenger airbag. Failure to carry out service operation in the correct sequence could cause the SRS to
unexpectedly deploy during servicing, possibly leading to a serious accident. Before servicing (including re-
moval or installation of parts, inspection or replacement), be sure to read the precautionary notices in the
RS section.
3. AUDIO SYSTEM

If the negative (-) terminal cable is disconnected from the battery, the preset AM, FM 1 and FM 2 sta-
tions stored in memory are erased, so make sure to note the stations and reset them after the negative
(-) terminal cable is reconnected to the battery.

If the negative (-) terminal cable is disconnected from the battery, the radio, tape player and CD player
will not operate as well as audio anti - theft system. Be sure to input the correct ID number so that the
radio, tape player and CD player can be operated again.
4. MOBILE COMMUNICATION SYSTEM
If the vehicle is equipped with a mobile communication system, refer to precautions in the IN section.

BE04Q-06
BE-2
- BODY ELECTRICALTROUBLESHOOTING
1606 Author
: Date
:
2001 AVALON (RM808U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
POWER OUTLET
SymptomSuspect AreaSee page
Electric power source cannot be taken out of the power outlet11. PWR OUTLET No. 1, 2 Fuse
12.Wire Harness-
-
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
HEADLIGHT AND TAILLIGHT SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
FOG LIGHT SYSTEM:
SymptomSuspect AreaSee page
Fog light does not light with light control SW HEAD.
(Headlight is normal)
1. FOG Fuse
2. Fog Light Relay
3. Fog Light Switch
4. Wire Harness-
BE-26
BE-26
-
Fog light does not light with light control SW HEAD.
(Headlight does not light)1. Other Parts*1
2. Wire Harness
-
-
Only one light does not light.1. Bulb
2. Wire Harness-
-
*1: Inspect Headlight System.
TURN SIGNAL AND HAZARD WARNING SYSTEM:
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. Hazard Warning Switch
2. Turn Signal Flasher
3. Wire HarnessBE-29
BE-29
-
The flashing frequency is abnormal.
1. Bulb
2. Turn Signal Switch
3. Wire Harness-
BE-29
-
Hazard warning light does not light up.
(Turn is normal.)1. HAZ Fuse
2. Wire Harness-
-
Hazard warning light does not light up in one direction.1. Hazard Warning Switch
2. Wire HarnessBE-29
-
*1Turn signal does not light up.
1. Ignition Switch
2. TURN Fuse
3. Turn Signal Switch
4. Wire HarnessBE-16
-
BE-29
-
*2Turn signal does not light up.
1. TURN Fuse
2. Turn Signal Switch
3. Wire Harness-
BE-29
-
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE-29
-
Only one bulb does not light up.1. Bulb
2. Wire Harness-
-
*1: Combination Meter, Wiper and Washer do not operate.
*
2: Combination Meter, Wiper and Washer are normal.

- BODY ELECTRICALTROUBLESHOOTING
BE-5
1609 Author
: Date
:
2001 AVALON (RM808U) Seat Belt warning light does not light up.
1. Bulb
2. Body Control System
3. Meter Circuit Plate
4. Wire Harness-
DI-615
BE-53
-
Discharge warning light does not light up.
1. AM2 - Fuse
2. Bulb
3. Meter Circuit Plate
4. Wire Harness
5. Generator-
-
BE-53
-
CH-9
Light Failure warning light does not light up.
1. Bulb
2. Light Failure Sensor
3. Bulb Check Relay
4. Wire Harness
5. Taillight System-
BE-53
BE-53
-
BE-2
Brake warning light does not light up.
1. Bulb
2. Parking Brake Switch
3. Brake Fluid Level Warning Switch
4. Bulb Check Relay
5. Meter Circuit Plate
6. Wire Harness-
BE-53
BE-53
BE-53
BE-43
-
SRS Warning light does not light up.
1. AM2 - Fuse
2. Bulb
3. Airbag Sensor Assembly
4. Meter Circuit Plate
5. Wire Harness-
-
RS-62
RS-67
BE-43
Open Door warning light does not light up.
1. DOME Fuse
2. Bulb
3. Door Courtesy Switch
4. Body Control System
5. Meter Circuit Plate
6. Wire Harness-
-
BE-31
DI-615
BE-43
-
Washer Level warning light does not light up.
1. Bulb
2. Washer Fluid Level Warning Switch
3. Meter Circuit Plate
4. Wire Harness-
BE-53
BE-43
-
COMBINATION METER (Indicator Lights):
SymptomSuspect AreaSee page
O/D OFF indicator light does not light up.
1. Bulb
2. O/D OFF Switch
3. ECM
4. Meter Circuit Plate
5. Wire Harness-
DI-203
DI-1
BE-43
-
Cruise Control indicator light does not light up.
1. Bulb
2. Cruise Control ECU
3. Meter Circuit Plate
4. Wire Harness-
DI-549
BE-43
-
High beam indicator light does not light up.
1. Bulb and Taillight
2. Headlight System
3. Meter Circuit Plate
4. Wire Harness-
BE-2
BE-43
-
Turn indicator light does not light up.
1. Bulb
2. Turn Signal and Hazard Warning System
3. Meter Circuit Plate
4. Wire Harness-
BE-2
BE-43
-

DI6LJ-01
DI-622
- DIAGNOSTICSBODY CONTROL SYSTEM
778 Author
: Date
:
2001 AVALON (RM808U)
PROBLEM SYMPTOMS TABLE
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH:
SymptomSuspect AreaSee page
Ignition switch is not set to each position.1. Ignition switch
2. Power source circuitBE-16
DI-627
Key unlock warning system does not operate.
(The buzzer does not sound when the driver's door is opened with
the ignition OFF and key inserted)
1. Power source circuit
2. Key unlock warning switch circuit
3. Door courtesy switch circuit
4. Driver door ECU
5. Multiplex communication circuit
6. Body ECU
7. Wire harnessDI-627
DI-637
DI-639
DI-676
DI-718
IN-30
IN-30
Key unlock warning system does not operate.
(The buzzer sounds when the ignition key is ACC or ON)1. Ignition switch
2. Power source circuit
3. Wire harnessBE-16
DI-627
IN-30
HEADLIGHT AND TAILLIGHT SYSTEM (USA):
SymptomSuspect AreaSee page
Only one side headlight does not light.
1. HEAD-(LH, RH) fuse
2. Headlight bulb
3. Wire harnessBE-9
-
IN-30
Headlight does not light.
1. HEAD-(LH, RH) fuse
2. Headlight control relay circuit
3. Light control switch circuit
4. Headlight bulb
5. Wire harnessBE-9
DI-635
DI-631
-
IN-30
ºLo-Beamº does not light.
1. Headlight bulb
2. Headlight dimmer switch
3. Light control switch circuit
4. Wire harness-
DI-631
DI-631
IN-30
ºHi-Beamº does not light.
1. Headlight bulb
2. Headlight dimmer switch
3. Light control switch circuit
4. Wire harness-
DI-631
DI-631
IN-30
ºFlashº does not light.1. Headlight dimmer switch
2. Wire harnessDI-631
IN-30
Only one side taillight does not light.1. Taillight bulb
2. Wire harness-
IN-30
Taillight does not light.
1. TAIL fuse
2. Taillight control relay circuit
3. Light control switch circuit
4. Body ECU
5. Wire harnessBE-9
DI-633
DI-631
IN-30
IN-30
Rear Combination light does not light.
1. Bulb
2. Light failure sensor
3. Wire harness-
BE-53
IN-30

- DIAGNOSTICSBODY CONTROL SYSTEM
DI-623
779 Author
: Date
:
2001 AVALON (RM808U)
HEADLIGHT AND TAILLIGHT SYSTEM (CANADA):
SymptomSuspect AreaSee page
Only one side headlight does not light.
1. Headlight bulb
2. HEAD LWR (LH, RH) fuse
3. Wire harness-
BE-9
IN-30
Headlight does not light.
1. Headlight bulb
2. Headlight control relay circuit
3. Light control switch circuit
4. Wire harness-
DI-635
DI-631
IN-30
ºLo-Beamº does not light.
1. Headlight bulb
2. HEAD LWR (LH, RH) fuse
3. Headlight control relay circuit
4. Headlight dimmer switch
5. Wire harness-
BE-9
DI-635
DI-631
IN-30
ºHi-Beamº does not light.
1. Headlight bulb
2. HEAD UPR (LH, RH) fuse
3. DRL fuse
4. D.R.L. relay No.2, 3 and 4 relay circuit
5. Headlight dimmer switch
6. Wire harness-
BE-9
BE-9
DI-668
DI-631
IN-30
ºFlashº does not light.
1. Headlight bulb
2. HEAD UPR (LH, RH) fuse
3. DRL fuse (R/B No.7)
4. D.R.L. relay No.2, 3 and 4 relay circuit
5. Headlight dimmer switch
6. Wire harness-
BE-9
BE-9
DI-668
DI-631
IN-30
Headlight does not light with engine running and light control SW
OFF.
1. DOME fuse
2. GAUGE fuse
3. DRL fuse
4. Parking brake switch circuit
5. Generator
6. Wire harnessBE-9
BE-9
BE-9
DI-670
CH-9
IN-30
Only one side taillight does not light.1. Bulb
2. Wire harness-
IN-30
Taillight does not light.
1. TAIL fuse
2. Taillight control relay circuit
3. Light control switch circuit
4. Body ECU
5. Wire harnessBE-9
DI-633
DI-631
IN-30
IN-30
Rear Combination light does not light.
1. Taillight bulb
2. Light failure sensor
3. Wire harness-
BE-53
IN-30
AUTO TURN OFF SYSTEM:
SymptomSuspect AreaSee page
ºAuto turn-off systemº does not operate.
1. Drivers door courtesy switch circuit
2. Driver door ECU
3. Multiplex communication circuit
4. Body ECUDI-639
DI-676
DI-718
IN-30
