DIAGNOSTIC TROUBLE CODE CHART
If a malfunction code is displayed during the DTC check, check the circuit listed for that code in the table
below (Proceed to the page given for that circuit.).
DTC No.
(See Page)Detection ItemTrouble AreaSRS
Warning Light
B0100/13
(DI-362)

Short in D squib circuit
Steering wheel pad (squib)

Spiral cable

Airbag sensor assembly

Wire harness
ON
B0101/14
(DI-367)

Open in D squib circuit
Steering wheel pad (squib)

Spiral cable

Airbag sensor assembly

Wire harness
ON
B0102/11
(DI-371)

Short in D squib circuit (to ground)
Steering wheel pad (squib)

Spiral cable

Airbag sensor assembly

Wire harness
ON
B0103/12
(DI-375)

Short in D squib circuit (to B+)
Steering wheel pad (squib)

Spiral cable

Airbag sensor assembly

Wire harness
ON
B0105/53
(DI-379)
Short in P squib circuit
Front passenger airbag assembly (squib)

Airbag sensor assembly

Wire harness
ON
B0106/54
(DI-383)
Open in P squib circuit
Front passenger airbag assembly (squib)

Airbag sensor assembly

Wire harness
ON
B0107/51
(DI-386)
Short in P squib circuit (to ground)
Front passenger airbag assembly (squib)

Airbag sensor assembly

Wire harness
ON
B0108/52
(DI-389)
Short in P squib circuit (to B+)
Front passenger airbag assembly (squib)

Airbag sensor assembly

Wire harness
ON
B0110/43
(DI-392)
Short in side squib (RH) circuit
Side airbag assembly RH (squib)

Airbag sensor assembly

Wire harness
Blink
B0111/44
(DI-396)
Open in side squib (RH) circuit
Side airbag assembly RH (squib)

Airbag sensor assembly

Wire harness
Blink
B0112/41
(DI-402)
Short in side squib (RH) circuit
(to ground)
Side airbag assembly RH (squib)

Airbag sensor assembly

Wire harness
Blink
B0113/42
(DI-402)
Short in side squib (RH) circuit
(to B+)
Side airbag assembly RH (squib)

Airbag sensor assembly

Wire harness
Blink
B0115/47
(DI-405)
Short in side squib (LH) circuit
Side airbag assembly LH (squib)

Airbag sensor assembly

Wire harness
Blink
B0116/48
(DI-409)
Open in side squib (LH) circuit
Side airbag assembly LH (squib)

Airbag sensor assembly

Wire harness
Blink

DI-356
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
512 Author
: Date
:
2001 AVALON (RM808U)DTC No.
(See Page)
Detection ItemTrouble AreaSRS
Warning Light
B0117/45
(DI-412)
Short in side squib (LH) circuit
(to ground)
Side airbag assembly LH (squib)

Airbag sensor assembly

Wire harness
Blink
B0118/46
(DI-415)
Short in side squib (LH) circuit
(to B+)
Side airbag assembly LH (squib)

Airbag sensor assembly

Wire harness
Blink
B0130/63
(DI-418)
Short in P/T squib (RH) circuit
Seat belt pretensioner RH (squib)

Airbag sensor assembly

Wire harness
Blink
B0131/64
(DI-422)
Open in P/T squib (RH) circuit
Seat belt pretensioner RH (squib)

Airbag sensor assembly

Wire harness
Blink
B0132/61
(DI-425)
Short in P/T squib (RH) circuit
(to ground)
Seat belt pretensioner RH (squib)

Airbag sensor assembly

Wire harness
Blink
B0133/62
(DI-428)
Short in P/T squib (RH) circuit
(to B+)
Seat belt pretensioner RH (squib)

Airbag sensor assembly

Wire harness
Blink
B0135/73
(DI-431)
Short in P/T squib (LH) circuit
Seat belt pretensioner LH (squib)

Airbag sensor assembly

Wire harness
Blink
B0136/74
(DI-435)
Open in P/T squib (LH) circuit
Seat belt pretensioner LH (squib)

Airbag sensor assembly

Wire harness
Blink
B0137/71
(DI-438)
Short in P/T squib (LH) circuit
(to ground)
Seat belt pretensioner LH (squib)

Airbag sensor assembly

Wire harness
Blink
B0138/72
(DI-441)
Short in P/T squib (LH) circuit
(to B+)
Seat belt pretensioner LH (squib)

Airbag sensor assembly

Wire harness
Blink
B1100/31
(DI-444)
Airbag sensor assembly malfunction
Airbag sensor assemblyON
B1140/32
(DI-446)
Side airbag sensor assembly (RH)
malfunction
Side airbag sensor assembly (RH)

Airbag sensor assembly

Wire harness
Blink
B1141/33
(DI-454)
Side airbag sensor assembly (LH)
malfunction
Side airbag sensor assembly (LH)

Airbag sensor assembly

Wire harness
Blink
B1156/B1157/
15
(DI-462)
Front airbag sensor (RH) malfunction
Front airbag sensor (RH)

Airbag sensor assembly

Wire harness
ON
B1158/B1159/
16
(DI-467)
Front airbag sensor (LH) malfunction
Front airbag sensor (LH)

Airbag sensor assembly

Instrument panel wire harness

Engine room main wire harness
ON
Nl
System normal-OFFNormal
(DI-475)
Voltage source drop
Battery

Airbag sensor assemblyON

- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-357
513 Author
: Date
:
2001 AVALON (RM808U)
HINT:

When the SRS warning light remains lit up and the DTC is the normal code, this means a voltage source
drops.
This malfunction is not stored in memory by the airbag sensor assembly and if the power source volt-
age returns to normal, the SRS warning light will automatically go out.

When 2 or more codes are indicated, the codes will be displayed in numeral order starting from the
lowest numbered code.

If a code not listed on the chart is displayed, the airbag sensor assembly is faulty.

DI1MX-12
Warning Light Check
P. DI-349
END
: Diagnostic steps permitting the use
of the TOYOTA hand-held tester.
P. DI-348
P. DI-349
Symptom SimulationNormal
DTC Check
Warning Light
ONMalfunction CodeWarning Light
Remains OFF
Circuit Inspection
Identification of Problem
Repair
Warning Light Check
P. DI-349
DTC Check (Read Past DTC)
Confirmation Test
Remains ON
Remains OFF
Clear DTC (Present and Past DTC)Items inside are titles of pages in this manual,
with the page number in the bottom portion. See the
pages for detailed explanations.
1
2
43
5
7
8
9
10
DTC Chart
11
6P. DI-355
P. IN-20 P. DI-362 to DI-484Remains OFF
Remains ON
Vehicle Brought to Workshop
Customer Problem Analysis
DTC Check (Read Present DTC)
Step 3, 4, 6, 8, 9, 11
P. DI-349
DTC Check (Read Past DTC)
P. DI-349
P. DI-349
P. DI-349
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-347
503 Author
: Date
:
2001 AVALON (RM808U)
SUPPLEMENTAL RESTRAINT SYSTEM
HOW TO PROCEED WITH TROUBLESHOOTING

DI1N1-10
H11973
Spiral Cable Accessory Meter
(Warning Light)Front Passenger Airbag Assembly
Side Airbag Assembly (RH)
Side Airbag Sensor
Assembly (RH)
Seat Belt Pretensioner (RH) Side Airbag Sensor
Assembly (LH)
Seat Belt
Pretensioner (LH)
Side Airbag Assembly (LH)Airbag Sensor Assembly Front Airbag Sensor (RH)
Steering Wheel Pad
(with Airbag)Front Airbag
Sensor (LH)
DI-358
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
514 Author
: Date
:
2001 AVALON (RM808U)
PARTS LOCATION

H11969
DI1MZ-1 1
R13006
DLC1
E1 Tc
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-349
505 Author
: Date
:
2001 AVALON (RM808U)
PRE-CHECK
1. SRS WARNING LIGHT CHECK
(a) Turn the ignition switch to the ACC or ON position and
check that the SRS warning light lights up.
(b) Check that the SRS warning light goes out after approx.
6 seconds.
HINT:

When the ignition switch is at ACC or ON and the SRS
warning light remains on or flashes, the airbag sensor as-
sembly has detected a malfunction code.

If, after approx. 6 seconds have elapsed, the SRS warn-
ing light sometimes lights up or the SRS warning light
lights up even when the ignition switch is OFF, a short in
the SRS warning light circuit can be considered likely.
Proceed to ºSRS warning light circuit malfunctionº on
page DI-479.
2. DTC CHECK (Using diagnosis check wire)
(a) Present troubles codes:
Output the DTC.
(1) Turn the ignition switch to the ACC or ON position
and wait for approx. 20 seconds.
(2) Using SST, connect terminals Tc and E1 of the
DLC1.
SST 09843-18020
NOTICE:
Pay due attention to the terminal connecting position to
avoid a malfunction.
(b) Past troubles codes:
Output the DTC.
(1) Using service wire, connect terminals Tc and E1 of
the DLC1.
SST 09843-18020
(2) Turn the ignition switch to the ACC or ON position
and wait for approx. 20 seconds.
NOTICE:
Pay due attention to the terminal connecting position to
avoid a malfunction.
