Fuse
AB0119H01300
H01301
Airbag Sensor Assembly
ON
LA
(+)
(-)
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-481
637 Author
: Date
:
2001 AVALON (RM808U)
Does not light up, when ignition switch is turned to ACC or ON
1 Check ECU-B Fuse.
PREPARATION:
Remove the ECU-B fuse.
CHECK:
Check continuity of the ECU-B fuse.
OK:
Continuity
HINT:

Fuse may be burnt out even if it appears to be OK during
visual inspection.

If fuse is OK, install it.
NG Go to step 5.
OK
2 Prepare for inspection (See step 1 on page DI-475).
3 Check SRS warning light circuit.
PREPARATION:
(a) Connect negative (-) terminal cable to the battery.
(b) Turn the ignition switch to ACC or ON.
CHECK:
Measure the voltage between body ground and LA terminal of
the harness side connector of the airbag sensor assembly.
OK:
Voltage: 10 - 14 V
NG Check SRS warning light bulb or repair SRS
warning light circuit.
OK

H08325AB0119H11969H13045
P/T Squib (LH)
Side Airbag
Sensor (LH)
Side Squib (LH)P Squib
D Squib
Spiral
Cable
Front Airbag
Sensor (RH) Front Airbag
Sensor (LH)
P/T Squib (RH)
Side Squib (RH)Side Airbag
Sensor (RH)
ONAirbag
Sensor
Assembly
DI-482
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
638 Author
: Date
:
2001 AVALON (RM808U)
4 Does SRS warning light come on?
PREPARATION:
(a) Disconnect negative (-) terminal cable from the battery.
(b) Connect the airbag sensor assembly connector.
(c) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
(d) Turn the ignition switch to ACC or ON.
CHECK:
Check operation of the SRS warning light.
NO Check terminal LA of airbag sensor assembly.
If normal, replace airbag sensor assembly.
YES
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use simulation method to check.

- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-483
639 Author
: Date
:
2001 AVALON (RM808U)
5 Is new ECU-B fuse burnt out again?
NO Using simulation method, reproduce malfunc-
tion symptoms (See page IN-20).
YES
Check harness between ECU- B fuse and
SRS warning light.

H12005
Airbag Sensor Assembly
Tc
C6
E1
W-B19
P-B 56
1F 1IDriver Side J/B
LG-R
11 3A
3G3B 413
4
J/B No. 3LG-R 4Tc DLC2
LG-R
J/B No. 4
66
4A
4HLG-R
II2 22
LG-R
DLC1
EB
3Tc DI-484
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
640 Author
: Date
:
2001 AVALON (RM808U)
Tc Terminal Circuit
CIRCUIT DESCRIPTION
By connecting terminals Tc and E1 of the DLC1 the airbag sensor assembly is set in the DTC output mode.
The DTCs are displayed by blinking the SRS warning light.
WIRING DIAGRAM
DI1BQ-18

AB0117AB0118AB0119H11969H13046
LOCK ACC
ON
or
AB0118
R14305AB0119
H00030
ACCON
or
E1
Tc
(+) (-)
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-485
641 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION PROCEDURE
If the DTC is not displayed, do the following troubleshooting.
1 Does SRS warning light light up for approx. 6 seconds?
PREPARATION:
Check operation of the SRS warning light after ignition switch
is turned from LOCK position to ACC or ON position.
NO Check SRS warning light system (See page
DI-479).
YES
2 Check voltage between terminals Tc and E1 of DLC1.
PREPARATION:
Turn the ignition switch to ACC or ON.
CHECK:
Measure the voltage between terminals Tc and E1 of DLC1.
OK:
Voltage: 10 - 14 V
OK Go to step 4.
NG

AB0118
R14304AB0119
H00031
ACCON
orTc
(+)
(-)
AB0117 AB0118 AB0119H01302H01303
LOCK
ACCON
or
Airbag Sensor Assembly
Tc
DI-486
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
642 Author
: Date
:
2001 AVALON (RM808U)
3 Check voltage between terminal Tc of DLC1 and body ground.
CHECK:
Measure the voltage between terminal Tc of DLC1 and body
ground.
OK:
Voltage: 10 - 14 V
OK Check harness between terminal E1 of DLC1
and body ground.
NG
4 Check airbag sensor assembly.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Disconnect the airbag sensor assembly connector.
(d) Insert service wire into terminal Tc from back side as
shown in the illustration.
(e) Connect the airbag sensor assembly connector with ser-
vice wire.
(f) Connect negative (-) terminal cable to the battery.
(g) Turn the ignition switch to ACC or ON and wait at least for
20 seconds.
(h) Connect service wire of terminal Tc to body ground.
CHECK:
Check operation of the SRS warning light.
OK:
SRS waning light comes on.
NOTICE:
Pay due attention to the terminal connecting position to
avoid a malfunction.
OK Check harness between the airbag sensor as-
sembly and DLC1.
NG
Replace airbag sensor assembly.

AB0119H01304H01305
LOCKAirbag Sensor Assembly
Tc
(+)
(-)
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-487
643 Author
: Date
:
2001 AVALON (RM808U)
If the DTC is displayed without a DTC check procedure, perform the following
troubleshooting.
1 Check resistance between terminal Tc of airbag sensor assembly and body
ground.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Disconnect the airbag sensor assembly connector.
CHECK:
Check resistance between terminal Tc of the airbag sensor as-
sembly connector and body ground.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector.
OK
Replace airbag sensor assembly.

DI15Z-10
Supplemental Restraint System Check Sheet
Date Problem Occurred
Customer 's Name
Registration No.
Registration Year
Frame No.
Odometer Reading
Weather
Temperature
Vehicle Operation
Road Conditions
Details Of Problem
Vehicle Inspection and Repair
History Prior to Occurrence of
Malfunction (Including Supple-
mental Restraint System)
Diagnosis System Inspection
SRS Warning Light
Inspection
DTC Inspection1st Time
2nd Time
1st Time
2nd TimeInspector 's
Name
Fine Cloudy Rainy Snowy Other
Approx.
Starting Idling
Driving [ Constant speed Acceleration Deceleration
Other ]
Remains ON Sometimes Lights Up Does Not Light Up
Remains ON Sometimes Lights Up
Does Not Light Up
Normal Code Malfunction Code
Normal Code Malfunction Code[ Code. ]
[ Code. ]km
Miles //
//
// Date Vehicle Brought In
DI-348
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
504 Author
: Date
:
2001 AVALON (RM808U)
CUSTOMER PROBLEM ANALYSIS CHECK
