2001 TOYOTA AVALON door lock

Z07425
Wire harness side:
12 123 45
67 891011
Z05732
Warning Light
Ignition
Switch
Battery
1
I14605
Warning Light
Ignition
Switch
Battery
1 2
- BODY ELECTRICALCOMBINATION METER
BE-61
1665 Author
: Date
:
2001 AVALON (RM808U)
22. INSPECT LIGHT FAILURE SENSOR CIRCUIT
Disconnect the connector from the sensor and inspect the con-
nector on the wire harness side, as shown.
Tester connectionConditionSpecified condition
1 - GroundConstantContinuity*
2 - GroundConstantContinuity*
9 - GroundConstantContinuity*
10 - GroundConstantContinuity*
11 - GroundConstantContinuity
12 - GroundConstantContinuity*
3 - GroundLight control switch OFFNo voltage
3 - GroundLight control switch TAIL or HEADBattery positive voltage
4, 8 - GroundIgnition switch LOCK or ACCNo voltage
4, 8 - GroundIgnition switch ONBattery positive voltage
7 - GroundStop light switch OFFNo voltage
7 - GroundStop light switch ONBattery positive voltage
*: There is resistance because this circuit is grounded through
the bulb.
If the circuit is as specified, replace the sensor.
If the circuit is not as specified, inspect the circuits connected
to other parts.
23. INSPECT OPEN DOOR WARNING LIGHT
Disconnect the connector from the door courtesy switch, and
ground terminal 1 on the wire harness side connector and
check that the warning light lights up.
If the warning light does not light up, inspect the bulb or wire har-
ness.
24. INSPECT DOOR COURTESY SWITCH
(See page BE-31)
25. INSPECT SEAT BELT WARNING LIGHT
(a) Disconnect the connector from the terminals buckle
switch and ground terminal on the wire harness side con-
nector as shown in the illustration.
(b) Turn the ignition switch ON and check that the warning
light lights up.
If the warning light does not light up, check the bulb circuit.

BE0D3-03
I12840
Garage Door Opener
Enjine Room Junction Block

ECU-B Fuse
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
BE-169
1773 Author
: Date
:
2001 AVALON (RM808U)
LOCATION

BE0I2-03
I12527
Front Personal Light
Vanity LightInterior Light Assembly
Door Courtesy LightDoor Courtesy Switch
Door Courtesy Light
Door Courtesy Switch
Driver Side Junction Block

DOME Fuse

Body ECU
Rear Interior Light Assembly
Luggage Compartment Light
BE-30
- BODY ELECTRICALINTERIOR LIGHT SYSTEM
1634 Author
: Date
:
2001 AVALON (RM808U)
INTERIOR LIGHT SYSTEM
LOCATION

BE1EH-01
I03433
Not turned
Unlock
I13485
1
2
I13334
I04020
1
- BODY ELECTRICALLUGGAGE COMPARTMENT DOOR OPENER SYSTEM
BE-125
1729 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT LUGGAGE COMPARTMENT DOOR KEY
LOCK AND UNLOCK SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
Not turned-No continuity
UNLOCK1 - 2Continuity
If continuity is not as specified, replace the switch.
2. INSPECT LUGGAGE COMPARTMENT DOOR OPEN-
ER MAIN SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF-No continuity
ON1 - 2Continuity
If continuity is not as specified, replace the switch.
3. INSPECT LUGGAGE COMPARTMENT DOOR OPEN-
ER CANCEL SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF-No continuity
ON1 - 2Continuity
If continuity is not as specified, replace the switch.
4. INSPECT LUGGAGE COMPARTMENT DOOR OPEN-
ER MOTOR OPERATION
Connect positive (+) lead to the terminal 1 and negative (-) lead
to the opener motor body, and check that the motor operateds.
If operation is not as specified, replace the lock.

BE1EG-01
I13482
Driver Side Junction Block

OPENER Fuse
Luggage Compartment Main Switch
Luggage Compartment Cancel Switch
Luggage Compartment Door
Unlock Motor
BE-124
- BODY ELECTRICALLUGGAGE COMPARTMENT DOOR OPENER SYSTEM
1728 Author
: Date
:
2001 AVALON (RM808U)
LUGGAGE COMPARTMENT DOOR OPENER SYSTEM
LOCATION

BE212-01
BE-88
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
1692 Author
: Date
:
ADJUSTMENT
ENABLING/DISABLING AUTO DOOR LOCK FUNCTION
(a) To disable auto door lock:
(1) Enter the vehicle and shut all doors.
(2) Insert the key into the ignition cylinder and turn it to
the ON position (not ACC).
(3) Open the driver's door and keep it open.
(4) Turn the key to the LOCK position and remove it
from the ignition cylinder.
(5) Insert the key into the ignition cylinder and remove
it. Repeat this operation three more times. (End this
step with the key out of the ignition cylinder.)
(6) Push the ºUNLOCKº button on the driver's door
master switch 5 times within 10 seconds. Wait at
least 10 seconds and shut the driver's door.
(7) Verify auto lock operation has been disabled by
starting the engine, putting the vehicle into a gear
and releasing the brake pedal.
(b) To enable auto door lock:
Follow the same sequence as above, except step 6. In step 6,
push the ºLOCKº button on the driver's door master switch 5
times within 10 seconds. Wait at least 10 seconds and shut the
driver 's door.

I12841
UNLOCKLOCK1 2 3 4 5 6
BE1DY-02
I12842
LOCK
UNLOCK1 2 3 4 5 6
I12843
UNLOCK
1 2 3 4 5 6
I12844
UNLOCK
1 2 3 4 5 6
I07301
LOCK
BE-82
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
1686 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. Driver 's door:
INSPECT DOOR KEY LOCK AND UNLOCK SWITCH
CONTINUITY
Switch positionTester connectionSpecified condition
LOCK3 - 5Continuity
OFF-No continuity
UNLOCK3 - 6Continuity
If continuity is not as specified, replace the switch.
2. Passenger 's Door:
INSPECT DOOR KEY LOCK AND UNLOCK SWITCH
CONTINUITY
Switch positionTester connectionSpecified condition
LOCK2 - 4Continuity
OFF-No continuity
UNLOCK1 - 4Continuity
If continuity is not as specified, replace the switch.
3. Driver 's Door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)3 - 4Continuity
If continuity is not as specified, replace the switch.
4. Passenger 's Door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)3 - 4Continuity
If continuity is not as specified, replace the switch.
5. Rear LH Door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)1 - 2Continuity
If continuity is not as specified, replace the switch.

I07302
LOCK
I12845
UNLOCK
LOCK
UNLOCKLOCK
22
11
I12846
UNLOCK
LOCK
UNLOCK
LOCK
6565
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
BE-83
1687 Author
: Date
:
2001 AVALON (RM808U)
6. Rear RH Door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)3 - 4Continuity
If continuity is not as specified, replace the switch.
7. Driver 's Door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (-) lead to terminal 2, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
8. Passenger 's door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
5 and the negative (-) lead to terminal 6, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
