2001 TOYOTA AVALON Service Repair Manual

Q05726
AX03O-04
Q04733
O-Ring
- AUTOMATIC TRANSAXLEDIRECT CLUTCH SPEED SENSOR
AX-3
1293 Author
: Date
:
2001 AVALON (RM808U)
DIRECT CLUTCH SPEED SENSOR
ON-VEHICLE REPAIR
1. REMOVE AIR CLEANER ASSEMBLY
2. DISCONNECT DIRECT CLUTCH SPEED SENSOR
CONNECTOR
3. REMOVE DIRECT CLUTCH SPEED SENSOR
(a) Remove the bolt and direct clutch speed sensor.
(b) Remove the O-ring from the direct clutch speed sensor.
4. INSTALL DIRECT CLUTCH SPEED SENSOR
(a) Coat a new O-ring with ATF and install it to the direct
clutch speed sensor.
(b) Install the direct clutch speed sensor with the bolt.
Torque: 11 N´m (110 kgf´cm, 8 ft´lbf)
5. CONNECT DIRECT CLUTCH SPEED SENSOR CON-
NECTOR
6. INSTALL AIR CLEANER ASSEMBLY

Q00394
SST
AX03S-05
Q06348
SST
Q00238
SST AX-14
- AUTOMATIC TRANSAXLEDIFFERENTIAL OIL SEAL
1304 Author
: Date
:
2001 AVALON (RM808U)
DIFFERENTIAL OIL SEAL
ON-VEHICLE REPAIR
1. REMOVE FRONT DRIVE SHAFT
(See page SA-16)
2. REMOVE SIDE GEAR SHAFT OIL SEAL
Using SST, pull out the oil seal.
SST 09308-00010
3. INSTALL LEFT SIDE GEAR SHAFT OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal.
SST 09223-15020, 09350-32014 (09351-32130)
Oil seal depth: 0 ± 0.5 mm (0 ± 0.02 in.)
(b) Coat the lip of the oil seal with MP grease.
4. INSTALL RIGHT SIDE GEAR SHAFT OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal.
SST 09316-60010 (09316-00010)
Oil seal depth: 0 ± 0.5 mm (0 ± 0.02 in.)
(b) Coat the lip of the oil seal with MP grease.
5. INSTALL FRONT DRIVE SHAFT
(See page SA-24)
6. CHECK TRANSAXLE FLUID LEVEL
(See page DI-160)

AX0KB-01
D07772
Radio Assembly with Heater Control & Accessory Assembly Except Taiwan Spec.:
Lower Instrument Panel
Sub-assembly
Lower No. 4 Instrument
Panel Sub-assembly
Hood Lock
Release Lever
Radio Tuner Opening
Covers with Heater
Console & Accessory
Assembly Taiwan Spec.:Taiwan Spec.:
Center Instrument Cluster Finish Panel
Sub-assemblyNo. 2 Instrument Panel
Under Cover Sub-assembly
Front Ash Receptacle Assembly
Upper Console Panel
Sub-assembly
Console Box Plate
Front Console Box
Assembly
Upper Rear Console
Panel Sub-assembly
Clip
Shift Control
Cable
Floor Shift Lever Assembly
12 (120,9)
Rear Console Box Assembly
RH Cowl Side Trim
RH Scuff Plate
N´m (kgf´cm, ft´lbf) : Specified torqueRH Cowl Side Trim
RH Scuff Plate
AX-20
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
1310 Author
: Date
:
2001 AVALON (RM808U)
FLOOR SHIFT ASSEMBLY
COMPONENTS

D08001
Cover
Control Position
Indicator Plate
Slide CoverShift Lever Knob
Compression Spring
Shift Lever Knob Button
Shift Lever Knob
Cover
O/D Main
Switch Cover Shift Lever Knob Sleeve
Lower Position Indicator Housing
Detent Rod
Compression
Spring Manual Detent
Spring
Shift Lock
Release Button
SpringCushion
Shift Lock Control Unit
O/D Main Switch Grooved Pin
Collar
Shift Lever Plate
Shift Lever Sub-assembly
Bulb
Spring Nut
Indicator Light Wire
Control Shaft Cap


Apply MP grease
Precoated part

 Non-reusable part
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
AX-21
1311 Author
: Date
:
2001 AVALON (RM808U)

D07989
AX0KD-01
D07988
2
4
3
1
2
D07990
D07221
D07991
AX-24
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
1314 Author
: Date
:
2001 AVALON (RM808U)
DISASSEMBLY
1. REMOVE O/D MAIN SWITCH TERMINAL
(a) Remove the connector from the shift lever plate.
(b) Remove the secondary locking device.
(c) Release the looking lug of the terminals 2 and 4, and pull
the terminals out from the rear.
(d) Separate the O/D main switch wire harness from the 2
clamps.
2. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY
(a) Side the shift lever knob cover.
(b) Remove the 2 screws and shift lever knob sub-assembly.
NOTICE:
Pay attention not to apply unnatural load onto O/D main
switch wire harness.
3. DISASSEMBLE SHIFT LEVER KNOB
SUB-ASSEMBL Y
(a) Using a small screwdriver, remove the O/D main switch
cover.
(b) Using a small screwdriver, remove the O/D main switch
from the shift lever knob.

D07992
D07220
D07222
D07239
D07225
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
AX-25
1315 Author
: Date
:
2001 AVALON (RM808U)
(c) Insert a small screwdriver into the position in the illustra-
tion and disengage the claw.
(d) Remove the shift lever knob button and compression
spring.
4. REMOVE INDICATOR LIGHT
(a) Remove the indicator light from the lower position indica-
tor housing.
(b) Remove the cap and bulb from the indicator light wire.
5. REMOVE LOWER POSITION INDICATOR HOUSING
Remove the 4 screws and lower position indicator housing.
6. DISASSEMBLE LOWER POSITION INDICATOR
HOUSING
(a) Remove the control position indicator plate.
(b) Remove the shift lock release button and spring.
(c) Remove the slide cover.
7. REMOVE SHIFT LOCK CONTROL UNIT
Remove the 2 screws and shift lock control unit assembly.

D07224
D07223
D07999
D07993
AX-26
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
1316 Author
: Date
:
2001 AVALON (RM808U)
8. REMOVE MANUAL DETENT SPRING
Remove the screw and manual detent spring.
9. REMOVE SHIFT LEVER KNOB SLEEVE
10. REMOVE GROOVED PIN
Secure the room for the pin to be released by using the vice and
etc. as shown in the illustration, and hit the grooved pin with a
hammer and pull the grooved pin out.
NOTICE:

Hit and pull the pin out gradually.

Do not damage the shift lever sub-assembly.
11. REMOVE DETENT ROD, COMPRESSION SPRING
12. REMOVE SHIFT LEVER SUB-ASSEMBLY
(a) Using a screwdriver, pry and push up the spring nut.
(b) Using nippers, cut the spring nut off it.
(c) Remove the control shaft and shift lever sub-assembly.

D07994
D07995
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
AX-27
1317 Author
: Date
:
2001 AVALON (RM808U)
13. REMOVE CUSHION
Remove the 2 screws and 2 cushion.
14. REMOVE COLLAR
Using a screwdriver and hammer, remove the 4 collars.
