2020 MITSUBISHI OUTLANDER PHEV Owner's Manual (in English)

When the warning display appears, the BSWdoes not operate normally because there are
some malfunctions in the system or the sen- sor. Have the vehicle inspected at aMITSUBISHI MOTORS Authorized Service
Point as soon as possible.NOTEz When the warning display appears, the BSW
will be deactivated.When the sensor is temporarily
not available
When the warning display appears, the sensor
is temporarily not available for some reason
such as the environmental condition or in-
crease of the sensor temperature. When the
warning display does not disappear after waiting for a while, contact a MITSUBISHI
MOTORS Authorized Service Point.
When there are foreign objects
on the sensor
When the warning display appears, the sensor
cannot detect a vehicle travelling side by side or an approaching vehicle, because foreignobjects, such as dirt, snow or ice, adhere to
the bumper surface around the sensor. Remove dirt, freezing or foreign material on the bumper surface around the sensor.
When the warning display does not disappear after having cleaned the sensor, contact a
MITSUBISHI MOTORS Authorized Service
Point.
Rear Cross Traffic Alert
(RCTA)*
The Rear Cross Traffic Alert (RCTA) is an
aid system for backing up. When the RCTA
system detects vehicles approaching from
sides while your vehicle is reversing, the Blind Spot Warning lamps in the outside rear-view mirrors on both sides will blink and a
buzzer will sound to alert the driver. A warn- ing message will also appear on the informa-
tion screen of the multi-information display.
Rear Cross Traffic Alert (RCTA)*
7-852**(20(1Starting and driving7

:ARN,NGzBefore using the RCTA, read this entire
section to fully understand the limitations
of this system. Failure to follow instruc-
tions could result in an accident.:ARN,NGz Never rely solely on the RCTA when
backing up. The RCTA is an aid system.
It is not a substitute for your safe and careful driving. Always check visually be-
hind and all around your vehicle for other vehicles, persons, animals or obstructions.
The performance of the RCTA may vary depending on driving, traffic and/or sur-rounding conditions.NOTEz The Blind Spot Warning lamps in the outside
rear-view mirrors on both sides will blink, even when only one vehicle is approachingfrom one side.Detection areas
The detection area is shown as illustrated.
CAUT,ONz In certain situations, the RCTA may not de-
tect a vehicle in the detection areas. Some of
these situations include:
Rear Cross Traffic Alert (RCTA)*
7-862**(20(1Starting and driving7

CAUT,ON

How to operate the LDW
The indication on the information screen ofthe multi-information display changes as fol-
lows depending on the state of the system.
To turn on/off the LDW
NOTEz The LDW is turned on when the vehicle is
shipped from the factory.
z The currently selected LDW setting (on or
off) is stored even when the operation mode
of the power switch is put in OFF.
To turn on the LDW, press the LDW switch.
The “LDW” indicator will appear on the in- formation screen of the multi information
display and the system is placed in the ‘ON state’.
To turn off the LDW, press the LDW switch.
The “LDW” indicator on the information
screen of the multi information display will
then go out and the system is placed in the
‘OFF state’.
To return the LDW to the ‘ON state’, press
the LDW switch again.
Standby state
In the standby mode, the system is capable of
recognizing the lane in which your vehicle is positioned and issuing audible warning when
your vehicle goes out of the lane.
The system automatically shifts from the ‘ON state’ to the ‘standby state’ if all of the
following conditions are simultaneously met. The “LDW” indicator in the information dis-
play changes to
indicator (green).
z The vehicle speed is approximately
65 km/h (40 mph) or higher.
z The turn-signal lever is not operated.
z The hazard lamp is not activated.
z Environmental conditions are adequate
for the system to recognize the lane markings on both sides.
z The system has been placed in the ‘ON
state’.
Lane Departure Warning (LDW)*
7-882**(20(1Starting and driving7

NOTEzThe system stays in the “ON” state for ap-
proximately 7 seconds after the hazard lamp
has stopped flashing or the turn-signal lever has returned to the home position.
Lane departure warning
A buzzer sounds intermittently and indication
of “LANE DEPARTURE” appears in the in-
formation display,
indicator flashing in
amber when your vehicle is about to leave or has left the lane in the standby mode.
NOTEz If the warning continues for approximately 3
seconds or more, the system switches to the standby mode before the warning stops.NOTEz If the lane markers are only on one side of
the road, the LDW will operate only for the
appropriate side where the lane marker is drawn.System problem warning
If a problem occurs with the system, a visual
warning specific to the type of the problem is given together with an audible alarm.
Too hot or cold sensor
The alarm shown below is displayed if the
system becomes temporarily unavailable due to a too high or low temperature of the sen-
sor.
If the temperature of the sensor reaches the predetermined value, the system automatical- ly recovers the normal state.
If the alarm continues showing, there is a
possibility that the LDW has a malfunction. Contact a MITSUBISHI MOTORS Author-
ized Service Point for inspection of the sys- tem.
Windscreen is dirty
The alarm shown below is displayed if the
system becomes temporarily unavailable due to dirt on the windscreen at the sensor por-
tion.
After having cleaned the windscreen, the sys- tem will automatically return to operation.
If the alarm continues showing, there is a
possibility that the sensor has a malfunction.
Contact a MITSUBISHI MOTORS Author-
ized Service Point for inspection of the sen-
sor.
LDW deactivation due to fault
The alarm shown below is displayed if the
LDW goes into a non-initialized state due to a fault.
If this happens, please contact a
MITSUBISHI MOTORS Authorized Service
Point for inspection of the system.
Lane Departure Warning (LDW)*
7-892**(20(1Starting and driving7

NOTEzIf the sensor or its surrounding area reaches
an extremely high temperature when parking the vehicle under a blazing sun, the “LDW
SERVICE REQUIRED” message may ap-
pear.
If the message remains even after the tem- perature of the sensor or its surrounding area
has been in range, please contact a MITSUBISHI MOTORS Authorized Serv-
ice Point.CAUT,ONz LDW has its performance limitations. Do
not over-rely on the system.
z LDW is not designed to lessen risks associ-
ated with not looking ahead carefully (atten-
tion drawn to something on the side, absent-
mindedness, etc.) or poor visibility caused
by bad weather etc. Keep steering your vehi-
cle correctly and drive safely.
z The system may not operate correctly in the
following conditions. If required, set the LDW switch to “OFF.”CAUT,ON

CAUT,ON

2.Lightly press the multi information dis-
play switch to select “
”
(Speed Limit Display function setting).
3. Press and hold the multi information dis-
play switch for approximately 2 seconds or more to switch from ON (display on)
to OFF (display off), or from OFF to
ON.
The setting is changed to the selected
condition.Tyre pressure monitoring
system (TPMS)
The tyre pressure monitoring system (TPMS)
uses tyre inflation pressure sensors (A) on the wheels to monitor the tyre inflation pressures.
The system only indicates when a tyre is sig-
nificantly under-inflated.
The base tyre pressure can be set at desired
value by the driver with the reset function ex- ecution. (The low pressure warning thresholdis set based on the reset.)
The tyre inflation pressure sensor IDs for two
sets of tyres can be registered by a
MITSUBISHI MOTORS Authorized Service
Point, and the valid ID set can be switched by
the Multi-information display switch (It’s beneficial in case of seasonal tyre change be-
tween summer tyre and winter tyre.)NOTEz The tyre pressure monitoring system
(TPMS) is not a substitute for regularlychecking tyre inflation pressures.
Be sure to check the tyre inflation pressures as described in “Tyres” on page 11-09.
z The tyre inflation pressure sensor (B) is in-
stalled in the illustrated location.
