2013 SSANGYONG NEW ACTYON SPORTS Service Manual

01-190000-00

01-30000-00
Left viewRight view
Rear viewFront view
1. ENGINE LAYOUT

01-4
2. MAJOR COMPONENTS
Front view ▶
Vacuum pump
Oil filter assembly
Camshaft position sensor
Power steering pump pulley
Water pump pulley
Alternator pulley
Idler pulley No. 2
A/C compressor pulley
Auto tensioner
Idler pulley No. 1
Isolation damper
Rear view ▶
E-EGR valve
Fuel temperature sensor
Fuel HP pump assembly
Coolant temperature sensor
IMV valve Crankshaft position sensor
Oil pressure switch

01-50000-00
Right view ▶
Front exhaust gas temperature
sensor
Oil dipstick tube &
gauge assembly
E-VGT actuator
E-VGT turbocharger
Coolant screw plug
Oil drain plug
Left view ▶
Thermostat assembly
Variable swirl valve assembly
E-EGR valve
E-EGR solenoid valve
EGR cooler
Electronic throttle body
Oil cooler assembly

01-6
3. ENGINE COMPARTMENT LAYOUT
Do not work on the engine compartment while the engine, radiator, exhaust manifold, muffler or
catalytic converter is hot. Always turn the engine off and allow it to cool before starting the
maintenance.
Regularly check the engine oil level and add Ssangyong genuine engine oil if necessary.
Clean the dipstick with clean cloth so that any foreign materials cannot get into the engine. -
-
-
Power steering fluid
reservoirBrake fluid reservoir
Fuse & relay
Engine oil dipstick
gaugeWasher fluid
reservoir cap Engine oil filler cap
Air cleaner
Operating vehicle with insuffi cient amount of oil can damage the engine. Make sure the engine oil
level is correct and add oil if necessary.
Coolant reservoir

01-70000-00
1) Service Interval
2) Specification and Capacity
Engine oilSpecification Quality class: Ssangyong genuine engine oil (Total Quartz INEO ECS
5W 30, SK ZIC SY 5W 30) or oil Approved by MB Sheet 229.51
Capacity approx. 6.0 litter
Engine
coolantSpecification Ssangyong genuine coolant Anti-Freeze SYC-1025
Capacity approx. 8.5 litter
Severe condition
Frequent stop-and-go traffic, extended idling, short driving distance below 6 km, driving distance below
16 km when the outside temperature remains below freezing
Driving in a hilly or mountainous terrain, sandy, or dusty area
High load driving such as trailer towing
Taxi, patrol service or delivery service (extended idling and excessive driving with low speed) -
-
-
-
DescriptionDaily
inspectionWeekly
inspectionService interval
Engine oil & oil
filterInspection - EU Change every 20,000 km or 12 months
(The service interval should be shortened
under severe conditions)
General Change every 15,000 km or 12 months
(The service interval should be shortened
under severe conditions)
Coolant Inspection - Change every 200,000 km or 5 years
Air cleaner
element- Inspection Diesel EU Change every 20,000 km (The
service interval should be
shortened under severe
conditions)
General Clean every 7,500 km, change
every 15,000 km (The service
interval should be shortened
under severe conditions)
Gasoline Clean every 15,000 km, replace every
60,000 km (The service interval should be
shortened under severe conditions)
Fuel filter - - EU Change every 40,000 km (Draining water
from fuel filter: whenever replacing the
engine oil)
General Change every 45,000 km (Draining water
from fuel filter: whenever replacing the
engine oil)
