2007 TOYOTA CAMRY Owners Manual

’07Camry_U (L/O 0608)
297
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
The brake assist system becomes opera-
tive after the vehicle has accelerated to
a speed in excess of approximately 10
km/h (6 mph). It stops operating when the
vehicle decelerates to a speed below
approximately 5 km/h (3 mph).
For an explanation of this system’s warn-
ing light, see “Service reminder indicators
and warning buzzers” on page 146 in Sec-
tion 1−6.
The brake pad wear limit indicators on
your disc brakes give a warning noise
when the brake pads are worn to where
replacement is required.
If you hear a squealing or scraping noise
while driving, have the brake pads
checked and replaced by your Toyota
dealer as soon as possible. Expensive ro-
tor damage can result if the pads are not
replaced when necessary.The vehicle identification number (VIN)
is the legal identifier for your vehicle.
This number is on the left top of the
instrument panel, and can be seen
through the windshield from outside.
This is the primary identification number
for your Toyota. It is used in registering
the ownership of your vehicle.
Brake pad wear limit
indicatorsYour Toyota’s identification—
—Vehicle identification
number

’07Camry_U (L/O 0608)
298
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
The vehicle identification number (VIN) is
also on the Certification Label.2.4 L 4cylinder (2AZFE) engine
3.5 L V6 (2GRFE) engine
The engine number is stamped on the
engine block as shown.
—Engine number

’07Camry_U (L/O 0608)
299
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Your new vehicle carries theft preven-
tion labels which are approximately 47
mm (1.85 in.) by 12 mm (0.47 in.).
The purpose of these labels is to reduce
the incidence of vehicle thefts by facilitat-
ing the tracing and recovery of parts from
stolen vehicles. The label is designed so
that once it is applied to a surface, any
attempt to remove it will result in destroy-
ing the integrity of the label. Transferring
these labels intact from one part to anoth-
er, will be impossible.
NOTICE
You should not attempt to remove the
theft prevention labels as it may vio-
late certain state or federal laws.
CAUTION
Do not modify the suspension/chassis
with lift kits, spacers, springs, etc. It
can cause dangerous vehicle handling
characteristics, resulting in loss of
control.
Theft prevention labels Suspension and chassis

’07Camry_U (L/O 0608)
300
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
This illustration indicates typical tire
symbols.
1. Tire size—F or det ails, see “— Ti re
size” on page 304.
2. DOT and Tire Identification
Number (TIN)—For details, see
“—DOT and Tire Identification
Number (TIN)” on page 303.
3. Uniform tire quality gra-
ding—For details, see “Uniform
tire quality grading” that follows.
4. The location of the tread wear
indicators—For details, see
“Checking and replacing tires” on
page 388.
5. Tire ply composition and mate-
rials—Plies mean a layer of rub-
ber−coated parallel cords. Cords
mean the strands forming the plies
in the tire.
6. Radial tires or biasply tires—A
radial tire has “RADIAL” on the
sidewall. A tire not marked with
“RADIAL” is a bias−ply tir e.
Tire information—
—Tire symbols (standard tire)

’07Camry_U (L/O 0608)
301
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
7. “TUBELESS” or “TUBE
TYPE”—A tubeless tire does not
have a tube inside the tire and air
is directly filled in the tire. A tube
type tire has a tube inside the tire
and the tube maintains the air
pressure.
8. Load limit at maximum cold tire
inflation pressure—For details,
see “Checking and replacing tires”
on page 388.
9. Maximum cold tire inflation
pressure—This means the pres-
sure to which a tire may be in-
flated. For details about recom-
mended cold tire inflation
pressure, see “Tires” on page 411.
10.Summer tire or all season
tire—An all season tire has “M+S”
on the sidewall. The tire not
marked with “M+S” is a summer
tire. For details, see “Types of
tires” on page 313.

’07Camry_U (L/O 0608)
302
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
This illustration indicates typical tire
symbols.
1. “TEMPORARY USE ONLY”—A
compact spare tire is identified by
the phrase “TEMPORARY USE
ONLY” molded into its sidewall.
This tire is designed for temporary
emergency use only. For details,
see “Compact spare tire” on page
344.
2. Tire size—F or det ails, see “— Ti re
size” on page 304.
3. DOT and Tire Identification
Number (TIN)—For details, see
“—DOT and Tire Identification
Number (TIN)” on page 303.
4. The location of the tread wear
indicators—For details, see
“Checking and replacing tires” on
page 388.
5. Load limit at maximum cold tire
inflation pressure—For details,
see “Checking and replacing tires”
on page 388.
—Tire symbols (compact spare tire)

’07Camry_U (L/O 0608)
303
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
6. Maximum cold tire inflation
pressure—This means the pres-
sure to which a tire may be in-
flated. For details about recom-
mended cold tire inflation
pressure, see “Tires” on page 411.
7. Tire ply composition and mate-
rials—Plies mean a layer of rub-
ber−coated parallel cords. Cords
mean the strands forming the plies
in the tire.
8. “TUBELESS” or “TUBE
TYPE”—A tubeless tire does not
have a tube inside the tire and air
is directly filled in the tire. A tube
type tire has a tube inside the tire
and the tube maintains the air
pressure.
9. Radial tires or biasply tires—A
radial tire has “RADIAL” on the
sidewall. A tire not marked with
“RADIAL” is a bias−ply tir e.
This illustration indicates typical DOT
and Tire Identification Number (TIN).
1. “DOT” symbol
2. Tire Identification Number (TIN)
3. Tire manufacturer ’s identification
mark
4. Tire size code
5. Manufacturer ’s optional tire type
code (3 or 4 letters)
6. Manufacturing week
7. Manufacturing yearThe “DOT” symbol certifies that the
tire conforms to applicable Federal
Motor Vehicle Safety Standards.
—DOT and Tire Identification
Number (TIN)

’07Camry_U (L/O 0608)
304
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
This illustration indicates typical tire
size.
1. Tire use (P=Passenger car,
T=Temporary use)
2. Section width (in millimeters)
3. Aspect ratio (tire height to section
width)
4. Tire construction code (R=Radial,
D=Diagonal)
5. Wheel diameter (in inches)
6. Load index (2 digits or 3 digits)
7. Speed symbol (alphabet with one
letter)1. Section width
2. Tire height
3. Wheel diameter1. Bead
2. Sidewall
3. Shoulder
4. Tread
5. Belt
6. Inner liner
7. Reinforcing rubber
8. Carcass
9. Rim lines
10.Bead wires
11. Chafer
—Tire size —Name of each section of tire
