’07Camry_U (L/O 0608)
4
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
1. Headlight, turn signal and front fog
light switches
2. Wiper and washer switches
3. Theft deterrent system/engine
immobilizer system indicator light
4. Clock
5. “AIRBAG ON” and “AIRBAG OFF”
indicator lights and front passenger ’s
seat belt reminder light
6. Emergency flasher switch
7. Audio system or navigation system
including audio system (For the
navigation system, see the separate
“Navigation System Owner ’s Manual”.)
8. Rear window and outside rear view
mirror defogger switch
9. Air conditioning controls
10. Tire pressure warning system reset
switch
11. AUX adapter
12. Power outlet
13. Auxiliary boxes
14. Ignition switch
15. Power rear view mirror control switches With manual air conditioning controls
’07Camry_U (L/O 0608)
5
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
1. Headlight, turn signal and front fog
light switches
2. Wiper and washer switches
3. Theft deterrent system/engine
immobilizer system indicator light
4. Clock
5. “AIRBAG ON” and “AIRBAG OFF”
indicator lights and front passenger ’s
seat belt reminder light
6. Emergency flasher switch
7. Audio system or navigation system
including audio system (For the
navigation system, see the separate
“Navigation System Owner ’s Manual”.)
8. Air conditioning controls
9. Tire pressure warning system reset
switch
10. Rear window and outside rear view
mirror defogger switch
11. AUX adapter
12. Power outlet
13. Auxiliary boxes
14. Ignition switch (with smart key system)
15. Ignition switch
(with key cylinder type ignition switch)
16. Power rear view mirror control switches With automatic air conditioning controls
’07Camry_U (L/O 0608)
414
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
7. STOP 10 A: Stop lights, high mounted
stoplight, shift lock control system,
multiport fuel injection system/sequen-
tial multiport fuel injection system, main
body ECU, anti−lock brake system, ve-
hicle stability control system, traction
control system, brake assist system,
electronic throttle control system
8. TI&TE 30 A: No circuit
9. AM1 7.5 A: Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system
10. A/C 7.5 A: Air conditioning system
11. PWR 25 A: Power windows
12. DOOR NO.2 25 A: Main body ECU
13. S/ROOF 30 A: Electric moon roof
14. TAIL 15 A: Front side marker lights,
tail lights, rear side marker lights, li-
cense plate lights, front turn signal/
parking lights
15. PANEL 7.5 A: Navigation system, seat
heaters, emergency flashers, air condi-
tioning system, audio system, clock,
glove box light, instrument panel lights,
steering switches
16. ECU IG NO.1 10 A: Main body ECU,
electric moon roof, tire pressure warn-
ing system, electric cooling fans, auto
anti−glare inside rear view mirror17. ECU IG NO.2 7.5 A: Anti−lock brake
system, vehicle stability control system,
traction control system, brake assist
system, shift lock control system, auto-
matic transmission, cruise control sys-
tem
18. A/C NO.2 10 A: Air conditioning sys-
tem, rear window defogger
19. WASH 10 A: Windshield wipers and
washer
20. S HTR 20 A: Seat heaters
21. GAUGE NO.1 10 A: Emergency flash-
ers, back−up lights, charging system
22. WIP 25 A: Windshield wipers and
washer
23. H LP LVL 7.5 A: No circuit
24. INJ 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, starting system
25. IGN 10 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, theft deterrent system, SRS
airbag system, steering lock system,
front passenger occupant classification
system, smart key system, electronic
throttle control system
26. GAUGE NO.2 7.5 A: Gages and me-
ters, multi−information display, clock27. ECU ACC 7.5 A: Clock, main body
ECU, shift lock control system, outside
rear view mirror, smart key system
28. CIG 20 A: Power outlet
29. PWR OUTLET 20 A: Power outlet
30. RADIO NO.2 7.5 A: Audio system,
navigation system
31. MIR HTR 10 A: Outside rear view mir-
ror defoggers
32. POWER 30 A: Power windows
33. P/SEAT 30 A: Power seats
