2007 TOYOTA CAMRY Owners Manual

’07Camry_U (L/O 0608)
121
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Automatic light cut off system
Position 1—
The lights automatically turn off when the
driver ’s door is opened after the ignition
switch is set to off.
Position 2 or “AUTO” position with the
headlights on—
The lights automatically turn off after 30
seconds when any of the doors or trunk
lid is opened and closed after the ignition
switch is set to off.
The lights can be turned off immediately
by pushing the lock switch on the wireless
remote control transmitter with all the
doors locked and the trunk lid closed.
The time period before the lights turn off
can be changed. For details, ask your
Toyota dealer.
If any of the doors or trunk lid is kept
open, the lights automatically turn off after
20 minutes.
To turn on the lights again, set the ignition
switch at ON or actuate the headlight
switch. If you are going to park for over
one week, make sure the knob is in the
“DRL OFF” position.NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime Running Light (DRL) system
The Daytime Running Light (DRL) system
can make it easier for others to see the
front of your vehicle during the day. The
DRL system can be helpful in many differ-
ent driving conditions, but they can be
especially helpful in the short periods after
dawn and before sunset.
The DRL system will make your headlights
come on at a reduced brightness when:
The ignition is on with the engine run-
ning.
The light switch is in the “AUTO” posi-
tion with the headlights off or position
1.
The parking brake is released.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
position 1.
Twist the knob to position 2 to turn the
headlights to full intensity for night driving.
To turn off the DRL system, twist the knob
to the position 3 (“DRL OFF”) or turn the
ignition switch off.
The daytime running light system can be
disabled. For details, contact your Toyota
dealer.

’07Camry_U (L/O 0608)
122
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
even when the headlights are off.TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The ignition switch must be set at ON.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out. See “Replacing light
bulbs” on page 400 in Section 7−3.HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
The tail light indicator (green light) on the
instrument panel will tell you that the tail
lights are on.
Position 2—Headlights and all of the
above
Position 3 (“AUTO”)—Headlights and all of
the lights in the position 1
They automatically turn on or off depend-
ing on the darkness of the surroundings.
Headlights and turn signals
(for Canada)

’07Camry_U (L/O 0608)
123
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Manually twist the knob to the position 2
to turn on the headlights if they are need-
ed immediately when entering a dark tun-
nel, parking structure, etc.
When the tail lights/headlights are turned
on, the brightness of the instrument clus-
ter will be reduced slightly unless the in-
strument panel light control knob is turned
fully clockwise.
However, the brightness of the instrument
cluster will not be reduced in daytime
even when the tail lights/headlights are
turned on.
The automatic light control sensor is on
the top of the instrument panel.
Do not place anything on the instrument
panel, and/or do not affix anything on the
windshield to block this sensor.
If you feel that the automatic light control
comes into operation too early or too late,
have the sensor adjusted by your Toyota
dealer.Automatic light cut off system
Position 1—
The lights automatically turn off when the
driver ’s door is opened after the ignition
switch is set to off.
Position 2 or position 3 with the head-
lights on—
The lights automatically turn off after 30
seconds when any of the doors or trunk
lid is opened and closed after the ignition
switch is set to off.
The lights can be turned off immediately
by pushing the lock switch on the wireless
remote control transmitter with all the
doors locked and the trunk lid closed.
The time period before the lights turn off
can be changed. For details, ask your
Toyota dealer.
If any of the doors or trunk lid is kept
open, the lights automatically turn off after
20 minutes.
To turn on the lights again, set the ignition
switch at ON or actuate the headlight
switch. If you are going to park for over
one week, make sure the light switch is
in the “OFF” position.

’07Camry_U (L/O 0608)
124
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime Running Light (DRL) system
The Daytime Running Light (DRL) system
can make it easier for others to see the
front of your vehicle during the day. The
DRL system can be helpful in many differ-
ent driving conditions, but they can be
especially helpful in the short periods after
dawn and before sunset.
The DRL system will make your headlights
come on at a reduced brightness when:
The ignition is on with the engine run-
ning.
The knob is in the “OFF” position,
position 1 or position 3 with the head-
lights off.
The parking brake is released.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
position 1.
Twist the knob to position 2 to turn the
headlights to full intensity for night driving.
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “OFF”.

’07Camry_U (L/O 0608)
125
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The ignition switch must be set at ON.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out. See “Replacing light
bulbs” on page 400 in Section 7−3.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.
Emergency flashers

’07Camry_U (L/O 0608)
126
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
To adjust the brightness of the instru-
ment panel lights, turn the knob.
With the knob turned fully clockwise, the
intensity of the instrument panel lights will
not be reduced even when the tail lights/
headlights are turned on.To turn on the front fog lights, twist
the band of the headlight and turn sig-
nal switch lever. They will come on
only when the headlights are on low
beam.
Front fog light indicator light on the instru-
ment panel will tell you that the front fog
lights are on.Without moon roof
With moon roof
Instrument panel light control Front fog lights Interior light

’07Camry_U (L/O 0608)
127
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when the illu-
minated entry system acts. For details,
see “Illuminated entry system” on page
128 in this Section.
FRONT PERSONAL LIGHTS
To turn on the front personal light,
push the lens. To turn it off, push the
lens once again.REAR PERSONAL LIGHTS (vehicles with
moon roof)
To turn on the rear personal light, push
the switch. To turn it off, push the
switch once again.
By gently adjusting the shade of the rear
personal light, you can change the direc-
tion of the light to suit your preference.
When either of the rear side doors is
opened, the light on that side turns on
automatically. Closing the rear side doors
will turn the lights off.
Personal lights

’07Camry_U (L/O 0608)
128
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
The interior light and ignition switch
light will come on when any of the
doors are opened. After all the doors
are closed, the lights remain on for
about 15 seconds before fading out.
Without theft deterrent system—When any
of the front doors are unlocked, the lights
will come on and remain on for about 15
seconds before fading out.
With theft deterrent system—When any of
the doors are unlocked, the lights will
come on and remain on for about 15 sec-
onds before fading out.
If all the doors are closed, when the igni-
tion switch is turned off, the lights will
come on and remain on for about 15 sec-
onds.
If all the doors are closed and the ignition
switch is set at ACC or ON, the lights will
fade out.
If all the doors are locked, the lights will
fade out.
To prevent the battery being discharged,
all of the lights will automatically turn off
the key removed (vehicles with key cylin-
der−type ignition switch) or the ignition is
turned off (vehicles with smart key sys-
tem), and the door is left opened for
about 20 minutes.This feature can be disabled and the dura-
tion of the lighting can be changed. For
details, ask your Toyota dealer.
ILLUMINATIONS OF ENTRY FUNCTION
(vehicles with smart key system)
The interior light and ignition switch light
come on and remain on for about 15 sec-
onds when you carry the registered key
into the entry function actuation area. For
further information of entry function actua-
tion area, see “Smart key system” on
page 30 in Section 1−2.
To turn on the windshield wipers, move
the lever to the desired setting.
The ignition switch must be set at ON.
Lever position
Operation
Position 1Intermittent operation
Position 2Low speed operation
Position 3High speed operation
Position 4Single sweep operation
Position 5Washer on
Illuminated entry system Windshield wipers and washer
