2007 TOYOTA CAMRY ECO mode

’07Camry_U (L/O 0608)
39
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
SELECTING DOORS TO BE UNLOCKED
WITH ENTRY FUNCTION
The unlocking operation has 2 modes.
To change the mode, within 1 m (3 ft.)
of the vehicle press the lock switch and
the alarm, trunk opener or unlock
switch simultaneously for five seconds.
The ignition must be turned off.
When the mode is changed, the buzzer
will sound and an indicator is displayed on
the multi−information display as follows:Mode
Door to be
unlocked
Wireless
remote
control
buzzerIndicator
and meter
buzzer
1All doors2 beeps
1 beep
2
Driver ’s
door only
(from
driver ’s
door
switch)
All doors
(from front
passenger ’
s door
switch)
3 beeps
1 beep
Repeating the above process allows you
to toggle between 1 and 2.
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
The front doors can be opened by pulling
the inside handle even if the lock knobs
are in the locked position.
CAUTION
Do not pull the inside handle of the
front doors while driving. The doors
will open and an accident may occur.
Toyota strongly recommends that all
children be placed in the rear seat of
the vehicle.
—Locking and unlocking with
inside lock knob

’07Camry_U (L/O 0608)
41
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Push the switch.
To lock: Push the switch down on the
right side.
To unlock: Push the switch down on the
left side.
All the doors lock or unlock simultaneous-
ly.
When the front doors are locked from the
outside or locked with the wireless remote
control transmitter, the power door lock
switch will not work until either front door
is unlocked with the key, lock knob, or
wireless remote control transmitter.AUTOMATIC DOOR LOCKING
You can select the following functions:
Locking linked with the shift position
(automatic transmission models only)
All doors are automatically locked when
the selector lever is moved out of “P”
position.
Locking linked with vehicle speed
All doors are automatically locked when
the vehicle speed goes above about 20
km/h (12 mph).
You can set or cancel the automatic
door locking functions:
Be sure to apply the parking brake when
performing the following operations.
To select the locking linked with the
shift position:
1. Close all doors and set the ignition
switch to ON.
2. Shift the selector lever to the “P” posi-
tion.3. Within 10 seconds of setting the igni-
tion switch to ON, press and hold the
driver’s side power door lock switch in
the lock position for 5 seconds and
then release.
The doors will be locked and unlocked
to indicate that the function is set.
To cancel the function, do the above op-
eration again.
To select the locking linked with the
vehicle speed:
1. Close all doors and set the ignition
switch to ON.
2. Automatic transmission models on-
ly—Shift the selector lever from “P” to
the “N” position.
3. Within 10 seconds of setting the igni-
tion switch to ON, press and hold the
driver’s side power door lock switch in
the lock position for 5 seconds and
then release.
The doors will be locked and unlocked
to indicate that the function is set.
To cancel the function, do the above op-
eration again.
—Automatic door locking and
unlocking functions

’07Camry_U (L/O 0608)
42
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
AUTOMATIC DOOR UNLOCKING
You can select the following functions:
Unlocking linked with the shift posi-
tion (automatic transmission models
only)
All doors are automatically unlocked
when the selector lever is moved to
“P” position.
Unlocking linked with the driver ’s
door
All doors are automatically unlocked
when the driver ’s door is opened within
10 seconds after the ignition switch is
set from ON to ACC or OFF.
You can set or cancel the automatic
door unlocking functions:
Be sure to apply the parking brake when
performing the following operations.To select the unlocking linked with the
shift position:
1. Close all doors and set the ignition
switch to ON.
2. Shift the selector lever to the “P” posi-
tion.
3. Within 10 seconds of setting the igni-
tion switch to ON, press and hold the
driver’s side power door lock switch in
the unlock position for 5 seconds and
then release.
The doors will be locked and unlocked
to indicate that the function is set.
To cancel the function, do the above op-
eration again.To select the unlocking linked with the
driver ’s door:
1. Close all doors and set the ignition
switch to ON.
2. Automatic transmission models on-
ly—Shift the selector lever from “P” to
the “N” position.
3. Within 10 seconds of setting the igni-
tion switch to ON, press and hold the
driver’s side power door lock switch in
the unlock position for 5 seconds and
then release.
The doors will be locked and unlocked
to indicate that the function is set.
To cancel the function, do the above op-
eration again.

’07Camry_U (L/O 0608)
130
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
To defog or defrost the rear window,
push the switch.
The ignition switch must be set at ON.
The thin heater wires on the inside of the
rear window will quickly clear the sur-
faces. An indicator light will illuminate to
indicate the defogger is operating.
On some models, heater panels in the
outside rear view mirrors will also quickly
clear the surfaces.
Push the switch once again to turn the
defogger off.
The system will automatically shut off
when the operation time has been com-
pleted. The operation time is between 15
minutes and 1 hour depending on the am-
bient temperature and vehicle speed.
CAUTION
Since the mirror surfaces can get hot
do not touch them when the defogger
switch is on.
Make sure you turn the defoggers off
when the surfaces are clear. Leaving the
defoggers on for a long time could cause
the battery to discharge, especially during
stop−and−go driving. The defoggers are
not designed for drying rain water or for
melting snow.
If the outside rear view mirrors are heavi-
ly coated with ice, use a spray de−icer
before operating the switch.
NOTICE
When cleaning the inside of the rear
window, be careful not to scratch or
damage the heater wires or connec-
tors.
With manual air conditioning controls
only—
When any of the following conditions oc-
curs, the indicator light on the switch may
flash and a motor sound may be heard.
This does not indicate a malfunction.
The ignition is set at ON after the bat-
tery is reconnected
Engine starting and stopping is re-
peated at short intervals
The engine is started with the low volt-
age battery

’07Camry_U (L/O 0608)
136
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Each time you push the “DISP” button,
the display toggles through the follow-
ing information.
1. Outside temperature
2. Driving range
3. Average fuel consumption
4. Driving distance
5. Average vehicle speed
6. Cruise information off
7. Zoom display of odometer and trip me-
ter
The display will return to the outside tem-
perature display with pushing and holding
the “DISP” button for 1 second.
The displayed values in the cruise infor-
mation display indicate general driving
conditions. Accuracy varies with driving
habits and road conditions.
When the ignition switch is on, the last
previously used mode displayed just be-
fore the ignition switch is off will appear.
—Outside temperature and cruise information

’07Camry_U (L/O 0608)
145
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
(o)
This message is to remind the driver to
change the engine oil.
Change the engine oil as soon as pos-
sible.
If the driving range after the previous oil
change reaches 8000 km (5000 miles), the
message appears with the master warning
light and a warning tone sounds. The
message stays on with the ignition switch
on.
The engine oil maintenance data must be
reset after the engine oil change. See
“Resetting the engine oil maintenance
data” below for the procedure to reset the
system.Resetting the engine oil maintenance
data
The engine oil maintenance data must be
reset after replacement of the engine oil.
Reset the data by the following procedure:
1. Turn off the engine with the trip meter
A reading shown.
For details, see “—Odometer and two trip
meters” on page 138 in this Section.
2. The ignition switch must be set at ON
while holding down the trip meter reset
knob. A message “OIL MILEAGE
RESET MODE” will appear on the
display.
3. Hold down the knob at least 5 sec-
onds. A message “COMPLETE” will ap-
pear, then the message “OIL MILEAGE
RESET” goes off.(p)This message appears when the washer
fluid level becomes very low.
Fill the tank as soon as possible.
The message appears with the master
warning light a warning tone sounds.
(q)
This message appears when the driver ’s
door is opened with the ignition switch
turned off and the moon roof opened.
When you leave your vehicle, be sure to
close the moon roof.
The message appears with the master
warning light and a warning tone sounds.

’07Camry_U (L/O 0608)
159
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
When the key is in the vehicle, press-
ing the “ENGINE START STOP” switch
(engine switch) allows you to start and
stop the engine or choose at the ACC,
ON, or ignition switch off.
When the brake pedal is not depressed,
pressing the “ENGINE START STOP”
switch changes the ignition switch mode
as follows. Press the “ENGINE START
STOP” switch slowly and firmly.First time—ACC (accessory) mode (illu-
minate amber)
Accessories such as the radio operate.
Second time—ON mode (illuminate am-
ber)
All accessories on.
Third time—Power off (indicator light
off)
Pressing the “ENGINE START STOP”
switch again returns the ignition switch to
ACC.If a buzzer sounds and the master
warning light comes on for 5 seconds
when pressing the “ENGINE START
STOP” switch, this indicates that the key
is not in the vehicle. The “KEY IS NOT
DETECTED” message will also appear on
the multi−information display.
If the brake pedal is depressed, the in-
dicator light will turn green, regardless
of which mode is selected. When the
indicator light is green, pressing the
“ENGINE START STOP” switch once
starts the engine. (For starting tips, see
“How to start the engine” on page 316
in Section 3.)
Ignition switch
(with smart key system)

’07Camry_U (L/O 0608)
160
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
When the engine switch is changed from
ON (with the engine off) to off and then
changed to ACC, “DEPRESS THE BRAKE
PEDAL” is appeared on the multi−informa-
tion display.
If the amber indicator light on the
“ENGINE START STOP” switch blinks, this
indicates a malfunction of the push start
system. Turn off the engine immediately
and contact your Toyota dealer.
It is not a malfunction if the needle on all
meters and gauges move slightly when the
ignition switch is set at ACC, ON or when
the engine starts.
NOTICE
Do not leave the ignition switch at
ON if the engine is not running. The
battery will discharge and the ignition
could be damaged.
When the battery is disconnected or
run down, the push button start function
memorizes the current mode. After you
reconnect, replace, or recharge the bat-
tery, the memorized mode is selected au-
tomatically. In any of these cases, turn off
the engine if the engine comes on.
