Press the piston down all the way, and
turn the release valve clockwise as far as
possible.
& CAUTION (1) Use only the jack included with the vehicle and use it only for changing a wheel and for installing snow chains. (2) Position the jack on a hard, level surface. (3) To extend this type of jack to its full length, con­tinue jacking until the jack stops and can be ex­tended no further. (4) Follow jacking instructions to ensure safe opera­tion. (5) No one should stay in the vehicle while the jack is used. (6) Raise the vehicle so tyre just clears the ground. It is dangerous to raise the vehicle any higher. (7) Never get under the vehicle while using the jack. Avoid jarring the raised vehicle or leaving it sup­ported on the jack for any long time. Both are very dangerous. (8) Do not start or run the engine while the vehicle is on the jack.
257

Downloaded from www.Manualslib.com manuals search engine HATATOIMENPITEITA FOR EMERGENCIES
Varapyora HN23A-B
Koska on mahdotonta tietaa milloin kumi saattaa puhjeta, tarkastakaa varap­
yoran ilmanpaine Iyhyin valiajoin var-
mistaaksenne etta se on aina
kayt-tovalmis hatatilanteissa. Va-
rapyoraa sailytetaan matkatavaratilan
lattialevyn alia; pyoran irrottamiseksi
loysatkaa ja irrottakaa sita
kiinnittava
siipimutteri .
Varapyoraa sailytetaan takaoven.
ulkopuolella.
Varkauden estamiseksi
toinen varapyo­
ramutteri on lukkomutteri (1).
Lukkomutteri irrotetaan asettamalla
virta-avain lukkosylinteriin ja vetamalla mutterin suoja pois avaimen ollessa viela
siina.
Loysenna sitten varapyoran
mutterit pyoramutteriavaimella .
HUOM Tyonna kampi (2) pyoranmutteria­
vaimeen (3) ja loysenna mutterit. Irrota
sitten varapyora.
258
1
13Eoo19 13EOO2O
73E002 3
Spare wheel EN23A·B
Check the air pressure of the spare tyre
frequently and make sure it is ready for emergency use at any time. Maintaining the spare wheel at the high­
est spe cified air pressure will ensure that it can always be used under any condi­tions (city/high-speed driving, varying
load weight. etc .) .
The spare wheel is stored on the outside of the back door.
To prevent theft. one of the spare wheel nuts is a lock nut (1).
To remove the lock nut. insert the igni­tion key into the lock cylinder, pulling
the nut cover with the key still in it toward you and off.
Then loosen the spare
wheel nuts with the wheel nut wrench.
NOTE Insert the bar (2) into the wheel nut wrench (3) to loose the wheel nuts. And then remove the spare wheel.

Downloaded from www.Manualslib.com manuals search engine HATATOIMENPITEITA, -' " ' FOR EMERGENCIES , \, '
Lukkomutteriasennetaantakaisin paikal­
leen asettamalla mutterin suoja paikal-
leen avaimen ollessa lukkosylinterissa ,
painamalla
mutterin suoja lukkomutte­riin niin syvalle kuin mahdollist ja lukit­
semalla se sitten irrottamalla avain.
Rengasrikon kohdatessa
73E0021
HN 24AOE
Rengasr ikon kohdatessa suorittakaa ennen renkaan vaihtamista
seuraavat varotoimenpiteet:
pysakbikaa aJoneuvo tasais
elle alustalle, mahdollisimman suo­
jaan muulta liikenteelta , ja niin, ettei muu liikenne tai ajoneuvon
osat aiheuta teille ja matkustajillenne vaaraa rengasta vaihtaes­
sanne.
(1) Noudattakaa kyseisen alueen tallaisia tapauksia koskevia
saadbksia kytkemalla varoitusnelivilkun paalle, pystyt­
tamalla
varoituskolmion, vilkkuvalon ym. sopivan matkan
paahan ajoneuvosta. Kaikkien matkustajien tulee nousta
ajoneuvosta.
73EOO22
To reinstall the lock nut, replace the nut cover with the key still in the lock cylin­der, pressing the nut cover onto the lock nut as far as it will go, then lock it by removing the key.
If a tyre is punctured EN24AOD
If a tyre must be changed due to a puncture , do so only after
first following every precaution for safety: parking the vehicle in
a place where it is not a traffic hazard or dangerous to you and
your vehicle's occupants, on a flat surface , and in such a way that you will not be injured by any part of the vehicle while changing the tyre.
(1) Comply with local regulations concerning the protection of broken-down vehicle by switching on the hazard warning flashers, setting up a warning triangle, flashing signal lamp,
etc., at an adequate distance from the vehicle. Have all
passengers leave the vehicle.
259

Downloaded from www.Manualslib.com manuals search engine HATATOIMENPITEITA FOR EMERGENCIES
(2) Tybntiikiiii ajoneuvo tukevalle, ta­
saiselle alustalle ja vetiikiiii pysii­
kbintijarru piiiille.
Jottei ajoneuvo vierisi nostettaessa , asettakaa sopi­vat tuet sen pybriin (A) eteen joka on vinosti vastapiiiitii vaihdettavaa pybriiii (8). (3) Ottakaa varapybrii , nosturi , nosturin
kahva ja pybriinnavan suojuksen
avain esille.
(4) Asettakaa varapybrii ajoneuvon aile
Iii helle nosturia. Tiimii auttaa pie­nentiimiiiin vaaraa, jos nosturi sat­tuu luiskahtamaan paikaltaan.
(5) Irrottakaa pybriinnavan suojus sitii
varten olevalla avaimella .
c-Ajoneuvo jossa on teriispybriit 0-Ajoneuvo jossa on alumiinipybriit
260
B
73W081
73W521
(2) Position the vehicle on a flat, hard
surface and apply the parking brake.
To prevent the vehicle from rolling when it is raised on the jack, chock the wheel (A) diagonally opposite to that being changed (8). (3) Get the spare wheel, jack, jack han­dle and wheel cap wrench ready.
(4) Place the spare wheel under the
vehicle body near the jack; this
helps to minimize danger should the
jack slip off position .
(5) Use the wheel cap wrench to re­
move the cap from the wheel.
c-Vehicles with steel wheels 0-Vehicles with aluminium wheels

Downloaded from www.Manualslib.com manuals search engine HATATOIMENPITEITA ' FOR EMERGENCIES
(6) Loysiitkiiii pyoriinmutterit pyoriin­mutteriavaimella. Alkiiii irrottako
niitii vielii.
(7) Tarkistakaa osasta "Ajoneuvon nostaminen" sopiva nostokohta mahdollisimman liihellii vioittunutta pyoriiii. sijoittakaa nosturi siihen ja
nostakaa ajoneuvoa. kunnes pyorii tulee hieman irti maasta . (8) Irrottakaa pyoriinmutterit avaimella
tai kiisin . Ottakaa sitten pyorii irti.
(9) Vetiikiiii kiekkopyoriiii itseiinne
kohti.
(10)lrrottakaa keskisuojuksen kiinnitin (E) kiekkopyoriistii .
73E0048
(6) Loosen the wheel nuts with the
wheel nut wrench. Do not remove
the wheel nuts yet . (7) Refer to the section entitled "Jacking up the vehicle" to select a
jacking point near the flat tyre at which to position the jack and then raise the vehicle until the tyre is slightly off the ground.
(8) Remove the wheel nuts with the
wheel nut wrench or by hand. then
take the wheel off. (9) Pull the disk wheel toward you.
(10)Remove the centre ca p
mounting fixture (E) from the disk wheel.
261

Downloaded from www.Manualslib.com manuals search engine HATATOIMENPITEITA FOR EMERGENCIES
(11 )Puhdistakaa muta jne laakeripin­nalta tai pybriin kiinnitysreiistii. Asentakaa nyt vararengas.
(12)Asentakaa keskisuojuksen kiinnitin vaihtorenkaaseen. Tybntiikiiii kiin­nitin laattoineen (G) oikeassa suh­
tees sa vastaaviin pybriin loviin (F).
262
HUOM Etupybrien pybriinsuojuksen ki inni­tin on kullanvarinen , takapybrien hopeanvarinen .
73E0037
73E0043
(11 )Clean away any mud, etc. on the hub surface or in the installation holes in the wheel, and then mount the spare tyre.
(12)lnstall the centre cap mounting fix­
ture to the replacement tyre. Insert the fixture with its tabs (G) is in alignment with corresponding notches (F) of the wheel.
NOTE
The wheel cap mo' ~ting fixture for
front wheel is gol. c" '''ri while that for rear Whl::e,,, is silver-coloured.

Downloaded from www.Manualslib.com manuals search engine HATATOIMENPITEITA FOR EMERGENCIES
(13)Teriispyorillii varustetuissa ajuneu­voissa asetetaan pyoriinmuttorit niin ettii niiden kartiomalliset piiiit ovat
sisiiiinpiiin. Sen jiilkeen ne ki­ristetiiiin kiisin, kunnes pyorii on kiinni.
Alumiinipyorillii varustetuissa ajoneu­
voissa kiristetiiiin pyoriinmuttorit viiliai­
kaisesti kunnes niiden laippaosa kosket­
taa pyoriiii . Niiin mutterit kiinnittyviit.
& VAROITUS Alkaa koskaan oljytko pyoranmut­tereita koska bljy saa ne loysty­maan.
(14 )Laskekaa ajoneuvo varovasti alas ja tiukatkaa sitten jokainen mut-teri vuorollaan miiiiriitiukkuuteen.
Miiiiriitiukkuus 10 -12 kgm (100 -120 Nm)
73E0038
73E0039
(13)On vehicles with steel wheels , in­stall the wheel nuts with their ta­pered ends facing inward, then
tighten by hand until the wheel is no longer loose.
On vehicles
with aluminium wheels temporarily tighten the wheel nuts until their flange section cames into contact with the wheel so that they may no longer become loose.
& CAUTION Never apply oil to either wheel bolts or nuts as it will cause them to loosen.
(14)Lower the vehicle slowly and then
alternately tighten the nuts until each nut has been tightened to the
specified torque.
Tightening torque 10 to 12 kgm (100 to 120 Nm, 72 to 87 ft.lbs .)
263

Downloaded from www.Manualslib.com manuals search engine HATATOIMENPITEITA FOR EMERGENCIES
& VAROITUS Ei saa koskaan yrittaa kiristaa muttereita jalalla tai Dutkella, koska silloin mutterit kiristyvat liikaa.
(15)Laske ka a nostu ri alas ja irro tta kaa se. Laittakaa nosturi ja tyhj ennyt re n gas siiiloon. Korj auttakaa rengas mahdolli­
s im man nopeasti .
(16)Tarkastakaa re nkaa n ilm anpain e. 11-manpainearvot niikyvat taulukosta.
& VAROITUS (1) Renkaan vaihdosta noin 1000 km ajon jalkeen kiristakaa pyoranmutterit uudelleen. (2) Joe ohjauspyora varisee ajon aikana renkaan vaih­don jalkeen, tarkastuttakaa renkaan tasapaino MITSUBISHI-huoltoliikkeessa. (3) Turvallisuuden tahden valttakaa kayttamasta erityyppisia renkaita tai ajoneuvoonne sopimatto­mia renkaita.
264
& CAUTION Never use extra force by your foot to the wheel nut wrench or a pipe extension as you can overtighten the
nut.
(15)Lower and remove the jack and sto re th e jack an d flat ty re
wheel. Have the flat tyre re pair ed as soon as possibl e.
73MOOO9
(16)Check tyre infl ation pressure . Th e inflation pres sure specification is shown on the lab el app earing inside of the d river's d oor .
& CAUTION (1) After changing the tyre. drive the vehicle approximately 1000 km (621 miles) and retighten the wheel nuts to make sure that they are not loose. (2) If the steering wheel vibrates when driving after change of the tyre, have the tyre checked for bal­ance at your MITSUBISHI dealer. (3) For the safety of your vehicle, be sure to avoid mixing one type of tyre with another type or using tyros of the size other than the specified size.
