2016 TOYOTA VENZA Owners Manual

6176-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73030U_(U) Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows
cold startability. Oils with a lower value before the W allow for easier
starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil when
the oil is at high temperature. An oil with a higher viscosity (one with a
higher value) may be better suited if the vehicle is operated at high
speeds, or under extreme load conditions.
How to read oil container label:
The International Lubricant Spec ification Advisory Committee
(ILSAC) Certification Mark is added to some oil containers to help
you select the oil you should use. Outside temperature

6186-1. Specifications
VENZA_OM_OM73030U_(U) Cooling system Capacity
2GR-FE engine With towing package: 10.9 qt. (10.3 L, 9.1 Imp.qt.)
Without towing package: 10.7 qt.
(10.1 L, 8.9 Imp.qt.)
1AR-FE engine 7.5 qt. (7.1 L, 6.2 Imp.qt.)
Coolant type Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-
silicate, non-amine, non-nitrite, and non-borate
coolant with long-life hybrid organic acid technol-
ogy
Do not use plain water alone.

6196-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73030U_(U) Ignition system
Electrical system
Rear differential (AWD models) Spark plug
Make DENSO
2GR-FE engine
1AR-FE engine
Gap FK20HR11
SK16HR11
0.043 in. (1.1 mm)
NOTICE■ Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.
Battery
Open voltage at
68  F (20  C): 12.6  12.8 V Fully charged
12.2  12.4 V Half charged
11 . 8  12.0 V Discharged
(Voltage is checked 20 minutes after the
engine and all the lights are turned off.)
Charging rates 5 A max.
Oil capacity 0.5 qt. (0.5 L, 0.4 Imp.qt.)
Oil type and viscosity Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent

6206-1. Specifications
VENZA_OM_OM73030U_(U) Automatic transaxle
* : The fluid capacity is a reference quantity. If replacement is necessary, con-
tact your Toyota dealer.
Transfer (AWD models) Fluid capacity
* 2GR-FE engine
1AR-FE engine 2WD models: 6.9 qt. (6.5 L, 5.7 Imp.qt.)
AWD models: 7.1 qt. (6.7 L, 5.9 Imp.qt.)
6.9 qt. (6.5 L, 5.7 Imp.qt.)
Fluid type Toyota Genuine ATF WS
NOTICE■ Automatic transaxle fluid type
Using transaxle fluid other than “Toyota Genuine ATF WS” may cause dete-
rioration in shift quality, locking up of your transaxle accompanied by vibra-
tion, and ultimately damage the transaxle of your vehicle.
Oil capacity 0.8 qt. (0.8 L, 0.7 Imp.qt.)
Oil type and viscosity Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent

6216-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73030U_(U) Brakes
* 1
: Minimum pedal clearance when depressed with a force of 112 lbf (500 N, 51
kgf) while the engine is running.
* 2
: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N,
30.6 kgf).
Steering Pedal clearance
* 1
1.1 in. (28 mm) Min.
Pedal free play 0.04
 0.12 in. (1.0
 3.0 mm)
Brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake adjustment
* 2
4
 6 clicks
Fluid type SAE J1703 or FMVSS No. 116 DOT 3
Free play Less than 1.2 in. (30 mm)

6226-1. Specifications
VENZA_OM_OM73030U_(U) Tires and wheels
Type A Tire size P245/50R20 102H
Tire inflation pressure
(Recommended cold tire
inflation pressure) Driving under normal conditions
Front tires:
32 psi (220 kPa, 2.2 kgf/cm 2
or bar)
Rear tires:
32 psi (220 kPa, 2.2 kgf/cm 2
or bar)
Driving at high speeds above 99 mph
(160 km/h) (in countries where such
speeds are permitted by law)
Add 3 psi (20 kPa, 0.2 kgf/cm 2
or bar)
to the front tires and rear tires. Never
exceed the maximum cold tire inflation
pressure indicated on the tire sidewall.
Wheel size 20  7 1/2 J
Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)

6236-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73030U_(U) Type B
Spare tire Tire size P245/55R19 103S
Tire inflation pressure
(Recommended cold tire
inflation pressure) Driving under normal conditions
Front tires:
32 psi (220 kPa, 2.2 kgf/cm 2
or bar)
Rear tires:
32 psi (220 kPa, 2.2 kgf/cm 2
or bar)
Driving at high speeds above 99 mph
(160 km/h) (in countries where such
speeds are permitted by law)
Add 3 psi (20 kPa, 0.2 kgf/cm 2
or bar)
to the front tires and rear tires. Never
exceed the maximum cold tire inflation
pressure indicated on the tire sidewall.
Wheel size 19  7 1/2 J
Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)
Tire size T165/90D18 107M
Tire inflation pressure
(Recommended cold tire
inflation pressure) 60 psi (420 kPa, 4.2 kgf/cm 2
or bar)
Wheel size 18 x 4T
Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)

6246-1. Specifications
VENZA_OM_OM73030U_(U) Light bulbs Light Bulbs Bulb
No. W Ty p e
Exterior Headlights
Vehicles with discharge headlights
Low and high beam
Vehicles with halogen headlights
Low beam
High beam 
 9005 35
55
60 A
B
C
Front turn signal lights
(vehicles with discharge headlights) 7444
NA 28 D
Front turn signal/parking lights
(vehicles with halogen headlights) 3457
NAK 30/8 D
Front side marker lights
Vehicle with discharge headlights
Vehicle with halogen headlights W5W
168 5
5 E
E
Front fog lights  55 B
Stop/tail and rear side marker lights 7443 21/5 E
Tail lights 194 3.8 E
Rear turn signal lights 7440A 21 D
Back-up lights 921 16 E
License plate lights W5W 5 E
