2016 TOYOTA VENZA adding oil

4844-3. Do-it-yourself maintenance
VENZA_OM_OM73030U_(U) Items Parts and tools
Engine oil level (  P. 493) • “Toyota Genuine Motor Oil” or
equivalent
• Rag or paper towel
• Funnel (used only for adding
engine oil)
Fuses (  P. 527) • Fuse with same amperage rating
as original
Radiator and condenser (  P. 499)
Tire inflation pressure (  P. 513) • Tire pressure gauge
• Compressed air source
Washer fluid (  P. 505) • Water
• Washer fluid containing antifreeze
(for winter use)
• Funnel (used only for adding
washer fluid)

4954-3. Do-it-yourself maintenance
4
Maintenance and care
VENZA_OM_OM73030U_(U) ■ Adding engine oil
If the oil level is below or near
the low level mark, add engine
oil of the same type as already in
the engine.
Make sure to check the oil type and prepare the items needed before
adding oil.
Remove the oil filler cap.
Add engine oil slowly, checking the dipstick.
Install the filler cap, turning it clockwise.Engine oil selection  P. 616
Oil quantity
(Low  Full) 1.6 qt. (1.5 L, 1.3 Imp. qt.)
Items Clean funnelSTEP 1
STEP 2
STEP 3

5
When trouble arises
5655-2. Steps to take in an emergency
VENZA_OM_OM73030U_(U) Stop the vehicle immediately.
The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Toyota dealer.
Have the vehicle inspected immediately.
Failing to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your Toyota dealer immediately.Warning light Warning light/Details
Charging system warning light
Malfunction in the vehicle’s charging system.
Low engine oil pressure warning light
Abnormal level of engine oil pressure.
This warning light may turn on if the level of engine oil
declines. The light should turn off after checking the oil
and adding oil if necessary.
Warning light Warning light/Details
Malfunction indicator lamp
Malfunction in:
• The emission control system;
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control system.
