2008 TOYOTA TUNDRA Owners Manual

375
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
Dial
Turn the “AUDIO/CONTROL” knob until
the number that you want to dial is dis-
played and push the knob. After that, do
the one of the following:
Push the off−hook switch.
Push the talk switch and say “Dial”.
Turn the “AUDIO/CONTROL” knob until
“Dial” is displayed and push the knob.
Delete
1. Turn the “AUDIO/CONTROL” knob until the dial number that you want to delete
is displayed and push the knob.
2. Push the talk switch and say “Delete”, or turn the “AUDIO/CONTROL” knob
until “Delete” is displayed and push the
knob.
“Delete. Push the talk switch and say
confirm. Otherwise, say go back” is heard. 3. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the
knob.
“Deleted.” is heard. Store
1. Turn the “AUDIO/CONTROL” knob until the dial number that you want to regis-
ter is displayed and push the knob.
2. Push the talk switch and say “Store”, or turn the “AUDIO/CONTROL” knob
until “Store” is displayed and push the
knob.
“Store. Push the talk switch and say
confirm. Otherwise, say go back.” is
heard. 3. Follow voice guidance instructions, or turn the “AUDIO/CONTROL” knob until
“Confirm” is displayed and push the
knob.
Next, input a voice tag.
For further details, see page 366.
The system may not function in the follow-
ing cases:
If there is no incoming history.
If the phone book is locked.
INFORMATION
 Up to five incoming calls can be
stored in the system.
 When five incoming calls are stored
in memory, the oldest incoming call
is deleted to make room in memory
for new calls.

376
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
If the cellular phone is not registered, this
system cannot be used. See page 356 for
registering a cellular phone. Make sure
that “BT” is displayed and get the cellular
phone ready to use.
There are 3 way to make a phone call
with this system.
Speed dial
A phone call can be made with a preset
button in which a phone number is regis-
tered. See page 372 for setting the preset
buttons.
Dial by Name
The system dials the numbers correspond-
ing to the spoken names registered in the
system.
Dial by Number
The system dials to the spoken numbers.
To make a phone call
Push the off −hook switch to turn the
hands −free system on. To speed dial
1. Push the preset button where the de- sired number is set. The name or tele-
phone number is displayed.
2. Push the off −hook switch to dial.
To dial by Name 1. Push the talk switch and say “Dial by name”.
“Dial by name. Please push the talk
switch and say the stored name, or say
list names.” is heard and “Dial by Name”
is displayed.
2. Push the talk switch and say “XXXX”, or turn the “AUDIO/CONTROL” knob
until the phone name that you want to
dial is displayed and push the knob. When using a voice command:
“XXXX Push the off
−hook switch to dial.
Otherwise, push the talk switch and say
dial, or go back.” is heard. After that, do
the one of the following:
Push the off −hook switch.
Push the talk switch and say “Dial”.
Turn the “AUDIO/CONTROL” knob until
“Dial” is displayed and push the knob.
When using the knob:
It calls the number.
The system may not function in the follow-
ing cases:
If there is no number registered in the
preset button.
If the system does not recognize the
voice command.
—Making a phone call

377
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
INFORMATION
The phone numbers registered in
the phone book can be retrieved.
 The system does not recognize that
the voice tag is not registered in
the registered cellular phone. For
details about voice tags, see “To
add entry” on page 366.
 A shortcut to “Dial by name” is
available. Push the talk switch and
say “Dial XXX (name you want to
dial)”.
To dial by Number
1. Push the talk switch and say “Dial by Number”.
“Dial by number. Please push the talk
switch and say the number.” is heard and
“Dial by Num” is displayed. 2. Push talk switch and say “XXXX”.
“Push the off −hook switch to dial.
Otherwise, push the talk switch and say
dial, go back, or delete.” is heard.
To dial the number, do the one of the
following:
Push the off −hook switch.
Push the talk switch and say “Dial”.
Turn the “AUDIO/CONTROL” knob until
“Dial” is displayed and push the knob.
If the number exceeds 24 digits, the sys-
tem may not function properly.
INFORMATION
 The system can recognize single
digits from zero to nine, # (pound),
∗ (star), and + (plus). Numbers that
are ten or greater are not recog-
nized.
 To speed up input, it is a good idea
to group all digits into a continuous
string. However, you can enter each
digit individually or group digits to-
gether in preferred string lengths.
The display corresponding to each op-
eration appears on the screen as fol-
lows:
Input operation—
You say: “Nine, nine, five”
Voice output: “995 push the offhook
switch to dial. Otherwise, push the
talk switch and say dial, go back, or
delete.”
Display: “995”
You say: “Seven, three, four”
Voice output: “734 push the offhook
switch to dial. Otherwise, push the
talk switch and say dial, go back, or
delete.”

378
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
Display “995734”
Repeat the above procedure until the
entire number that you want to dial is
input.
Go back operation—
You say: “Go back”
Voice output: “Go back, the last
numbers entered have been removed.
Push the talk switch and continue
adding numbers otherwise say dial,
go back, or delete.”
Display: “995”
Repeating the above operation deletes
the last digits in reverse order of in-
put.
Delete operation—
You say: “Delete”
Voice output: “Deleted. The entire
number to dial has been deleted.
Please push the talk switch and say
the number.”
Display: “Dial by Num”
The display will return to the initial
screen that allows a number to be
input.Cancel operation—
Do either one of the following:
Push the onhook switch at anytime
during the operation.
 Push the talk switch and say
“Cancel” after the beep at anytime
during the operation except while a
call in connected.When receiving a phone call, a ring tone
is audible and the system changes into
the telephone mode.
When receiving a phone call, the display
is as follows. The display differs depend-
ing on whether or not the vehicle is in
motion.
When the vehicle is stopped:
Number, name, or “Incoming” is displayed.
When the vehicle is in motion:
“Incoming“ is displayed.
Do either one of the following:
Pushing the off −hook switch allows you
to talk on the phone.
Pushing the on −hook switch refuses
the call.
To adjust the ring volume, push “+” or “ −”
on the steering volume controls. Volume
adjustment cannot be done using the au-
dio system.
Repeatedly pushing “ −” on the steering
volume controls mutes the ring.
When receiving an international phone
call, the name of the party may not be
displayed correctly depending on the cellu-
lar phone.
—Receiving a p hone call

379
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
To transfer a call to the phone:
The received call can be transferred from
the hands−free system to the cellular
phone that is connected to Bluetooth
. For
details, refer to the user’s guide for the
cellular phone. While talking on the phone, the display is
as follows. The display differs depending
on whether or not the vehicle is in motion.
When the vehicle is stopped:
Number is displayed.
When the vehicle is in motion:
“Talking“ is displayed.
When the call is finished, push the on
−
hook switch.
In the following situations, your voice may
not reach the party.
Talk alternately with the other party on
the phone. If you talk at the same
time, the voice may not reach each
other. (It is not a malfunction.)
Keep the volume of receiving voice
down. Otherwise, echo is coming up.
When you talk on the phone, speak
clearly towards the microphone.
When driving on a rough road.
When driving at high speeds.
When the window is open.
When the air conditioning vents face
the microphone.
When the sound of the air conditioning
fan is loud. To transfer a call from the phone:
Pushing the off
−hook switch while talking
on the cellular phone that is connected to
Bluetooth
 allows you to talk hands −free.
To transfer a call to the phone:
The call can be transferred from the
hands −free system to the phone that is
connected to Bluetooth
. For details, refer
to the user’s guide for the cellular phone.
—Talking on the phone

380
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)

381
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Air conditioning system
Manual air conditioning system
Controls 382
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . .
Air flow selector settings 386
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating tips 386
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Automatic air conditioning system Controls 390
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Air flow selector settings 394
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating tips 394
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Instrument panel and rear vents 397
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioning filter 398
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
SECTION 1 9

382
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
1. Fan speed selector
2. “A/C” button
3. Air intake selector
4. Temperature selector (passenger side
temperature control)
5. Air flow selector
6. Temperature selector (driver side temperature control)
Manual air conditioning system—
—Controls
XS19019
