568
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the engine switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
The side turn signal lights consist of a
number of LEDs. If any of the LEDs burn
out, take your vehicle to your Toyota deal-
er to have the light replaced.
CAUTION
To prevent burning yourself, do not
replace the light bulbs while they
are hot.
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if
scratched or dropped. Hold a bulb
only by its plastic or metal case.
Do not touch the glass part of a
bulb with bare hands.
NOTICE
Only use a bulb of the listed type.
The inside of the lens of exterior lights
such as headlights may temporarily fog up
when the lens becomes wet in the rain or
in a car wash. This is not a problem
because the fogging is caused by the
temperature difference between the outside
and inside of the lens, just like the
windshield fogs up in the rain. However, if
there is a large drop of water on the
inside of the lens, or if there is water
pooled inside the light, contact your
Toyota dealer. Light bulbsBulb
No.WTy p e
Headlights
(high beam)900565A
Headlights
(low beam)—55B
Front fog lights914545C
Par k i ng and fr ont
side marker lights1685D
Front turn
signal/parking
lights4157NAK27/8E
Rear turn signal
lights3157A27/8E
Stop/tail and rear
side marker lights315727/8D
Back −up lights92118D
License plate
lights1684.9D
High mounted
stoplight and
cargo lamps92118D
Interior lights—5D
Replacing light bulbs—
572
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
XS73011a
1. Remove the bolts and cover.
XS73030
2. Turn the bulb base counterclockwise
and remove it.
If the connector is tight, wiggle it.
XS73031
3. Pull the bulb out of the base. Install a new bulb.
—Front fog lights
