2008 TOYOTA TUNDRA Owners Manual

263
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
CAUTION
To avoid accidentally engaging the
cruise control, turn the system off
when it is not in use. Make sure the
“CRUISE” indicator light is off.
XS17023
SETTING THE CRUISING SPEED
5−speed models—The transmission must
be in the “D” position or the shift range
position must be in “4” (fourth range) or
“5” (fifth range) in “S” mode before you
set the cruising speed.
6 −speed models—The transmission must
be in the “D” position or the shift range
position must be in between “4” (fourth
range) and “6” (sixth range) in “S” position
before you set the cruising speed. Bring your vehicle to the desired speed,
push the lever down in the “
−SET” direc-
tion and release it. This sets the vehicle
at that speed. If the speed is not satisfac-
tory, tap the lever up for a faster speed,
or tap it down for a slower speed. Each
tap changes the set speed by 1.6 km/h
(1.0 mph). You can now take your foot off
the accelerator pedal.
If you need acceleration—for example,
when passing—depress the accelerator
pedal enough for the vehicle to exceed
the set speed. When you release it, the
vehicle will return to the speed set prior
to the acceleration.
CANCELLING THE CRUISE CONTROL
The cruise control may be temporarily
cancelled by the driver or by the system
itself under certain circumstances. Tempo-
rary cancellation allows the set cruising
speed to remain in memory.
The cruise control can be temporarily can-
celled by doing the following:
Pulling the lever in the “CANCEL” di-
rection and releasing it
Depressing the brake pedal
Under certain circumstances, the cruise
control is temporarily cancelled:

264
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
When vehicle speed falls below 40
km/h (25 mph)
When vehicle stability control is acti-
vated
When vehicle speed drops 16 km/h (10
mph) below the set speed, the cruise con-
trol is cancelled and the set speed is
erased from memory.
The “CRUISE” indicator light remains on
to indicate that the system is still in op-
eration.
To turn the cruise control off, press the
“ON −OFF” button. Make sure the
“CRUISE” indicator light is off.
If the cruise control automatically cancels
out other than for the above cases, have
your vehicle checked by your Toyota deal-
er at the earliest opportunity.
RESUMING THE CRUISE CONTROL
If the cruise control is temporarily can-
celled, the cruising speed can be resumed
by pushing the lever up in the “+ RES”
direction.
Vehicle speed must be above 40 km/h (25
mph). RESETTING TO A FASTER SPEED
Push the lever up in the “+RES” direction
and hold it. Release the lever when the
desired speed is attained. While the lever
is held up, the vehicle will gradually gain
speed.
However, a faster way to reset is to ac-
celerate the vehicle and then push the
lever down in the “−
SET” direction.
RESETTING TO A SLOWER SPEED
Push the lever down in the “ −SET” direc-
tion and hold it. Release the lever when
the desired speed is attained. While the
lever is held down, the vehicle speed will
gradually decrease.
However, a faster way to reset is to de-
press the brake pedal and then push the
lever down in the “− SET” direction.
Even if you downshift from “D” to “S” with
the cruise control on, engine braking will
not be enabled because the cruise control
is not cancelled. To decrease the vehicle
speed, reset to a slower speed with the
cruise control lever or depress the brake
pedal. If you use the brake pedal, cruise
control is cancelled. CRUISE CONTROL FAILURE WARNING
If the “CRUISE” indicator light flashes
when using the cruise control, press the
“ON
−OFF” button to turn the system off
and then press it again to turn it on.
If any of the following conditions then oc-
curs, there is some trouble in the cruise
control system.
The indicator light does not come on.
The indicator light flashes again.
The indicator light goes out after it
comes on.
If this is the case, contact your Toyota
dealer and have your vehicle inspected.

265
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Audio and handsfree phone systems
Reference 266
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Using your audio system 267
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Audio remote controls 295
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
AUX adapter 297
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Rear seat entertainment system 298
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 342
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Hands −free phone system 350
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For vehicle equipped with Navigation system, please refer to the sepa-
rate “Navigation System Owner’s Manual.”
SECTION 1 8

266
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
XS18005a
Type 1: AM·FM radio/compact disc player
(with compact disc changer controller)
XS18001a
Type 2: AM·FM radio/compact disc player
with changer (with XM Satellite Radio∗
controller)
XS18002a
Type 3: AM·FM radio/compact disc player
with changer (with XM  Satellite Radio∗
controller)
∗: Use of satellite radio requires XM tun-
er and service. Contact your Toyota
dealer for details.
NOTICE
To clean radio panel, wipe it with a
soft, lintfree cloth (for avoidance of
damage to radio panel’s paint).
Reference

267
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
This section describes some of the basic
features on Toyota audio systems. Some
information may not pertain to your sys-
tem.
Your audio system works when the engine
switch is in the “ACC” or “ON” position.
NOTICE
To prevent the battery from being dis-
charged, do not leave the audio sys-
tem on longer than necessary when
the engine is not running.
CAUTION
For vehicle sold in U.S.A. and
Canadas:
Part 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or modifi-
cations to this equipment will void
the user’s authority to operate this
device.
Laser products
Do not take this unit apart or at-
tempt to make any changes your-
self. This is an intricate unit that
uses a laser pickup to retrieve
information from the surface of
compact discs. The laser is care-
fully shielded so that its rays re-
main inside the cabinet. There-
fore, never try to disassemble the
player or alter any of its parts
since you may be exposed to la-
ser rays and dangerous voltages.
This product ut ilizes a laser. Use
of controls or adjustments or per-
formance of procedures other
than those specified herein may
result in hazardous radiation ex-
posure.
Using your audio system—
—Some basics

268
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
TURNING THE SYSTEM ON AND OFF
Push “PWR·VOL” to turn the audio system
on and off.
Push “AM”, “DISC·AUX”, “FM1”, “FM2”,
“AM·SAT”
∗ or “LOAD” to turn on that func-
tion without pushing “PWR·VOL”. To turn
on the compact disc player, a compact
disc must be loaded in the player.
You can turn on the compact disc player
by inserting a compact disc.
You can turn off the compact disc player
by ejecting the compact disc. If the audio
system was previously off, then the entire
audio system will be turned off when you
eject the compact disc. If the radio was
previously on, it will come on again.
∗: Use of satellite radio r equires XM
tuner and service. Contact your Toyota
dealer for details.
SWITCHING BETWEEN FUNCTIONS
Push “AM”, “DISC·AUX”, “FM1”, “FM2”,
“AM·SAT”
∗ or “LOAD” if the system is al-
ready on but you want to switch from one
function to another.
∗: Use of satellite radio r equires XM
tuner and service. Contact your Toyota
dealer for details. LISTENING TO THE XM
 SATELLITE
RADIO BROADCAST∗ (type 2 and type
3)
To listen to a satellite radio broadcast in
your vehicle, an additional genuine Toyota
satellite receiver and antenna (or equiva-
lents) must be purchased and installed. A
subscription to the XM
 Satellite Radio
service is also necessary.
How to subscribe to an XM
 Satellite
Radio
An XM
 Satellite Radio is a tuner de-
signed exclusively to receive broadcasts
provided under a separate subscription.
Availability is limited to the 48 contiguous
statesU.S. and 10 Canadian provinces. How to subscribe:
You must enter into a separate service
agreement with the XM
 Satellite Radio in
order to receive satellite broadcast pro-
gramming in the vehicle. Additional activa-
tion and service subscription fees apply
that are not included in the purchase price
of the vehicle and optional digital satellite
tuner. For complete information on sub-
scription rates and terms, or to subscribe
to the XM
 Satellite Radio, visit XM on
the web at www.xmradio.com
or call an
XM
’s Listener Care at 1 −800− 967−2346.
U.S.A.—
Visit on the web at www.xmradio.com
or
call 1 −800− 967−2346.
Canada—
Visit on the web at www.xmradio.ca
or call
1 −877− 438−9677.
The XM
 Satellite Radio is solely respon-
sible for the quality, availability and con-
tent of the satellite radio services pro-
vided, which are subject to the terms and
conditions of the XM
 Satellite Radio cus-
tomer service agreement.
Customers should have their radio ID
ready; the radio ID can be found by tun-
ing to “channel 000” on the radio. For
details, see “Displaying the radio ID” be-
low.

269
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
All fees and programming are the respon-
sibility of the XM
 Satellite Radio and are
subject to change.
Satellite t uner technology notice:
Toyota’s satellite radio t uners are awarded
Type Approval Certificates from XM
 Sat-
ellite Radio Inc. as proof of compatibility
with the services offered by the XM
 Sat-
ellite Radio.
Displaying the radio ID
Each XM
 tuner is identified with a unique
radio ID. You will need the radio ID when
activating XM
 service or when reporting
a problem.
If you select the “CH 000” using the
“TUNE·FILE” knob, the ID code of 8 al-
phanumeric characters appears. If you se-
lect another channel, display of the ID
code is canceled. The channel (000) alter-
nates the display between the radio ID
and the specific radio ID code.
∗: Use of satellite radio r equires XM
tuner and service. Contact your Toyota
dealer for details.
TONE AND BALANCE
For details about your system’s tone and
balance controls, see the description of
your own system. Tone
How good an audio program sounds to
you is largely determined by the mix of
the treble, midrange (JBL brand audio sys-
tem
∗ only), and bass levels. In fact, differ-
ent kinds of music and vocal programs
usually sound better with different mixes
of treble, midrange, and bass.
You can adjust sound characteristics. Dif-
ferent sound characteristics can be re-
corded for each audio source.
∗: If a JBL brand audio system is installed, the “JBL” logo is shown on
the panel.
Balance
A good balance of the left and right stereo
channels and of the front and rear sound
levels is also important.
Keep in mind that if you are listening to
a stereo recording or broadcast, changing
the right/left balance will increase the vol-
ume of one group of sounds while de-
creasing the volume of another. YOUR RADIO ANTENNA
To remove an antenna, carefully turn it
counterclockwise.
NOTICE
To prevent damage to the antenna,
make sure it is removed before driv-
ing your Toyota through an automatic
car wash.
YOUR COMPACT DISC PLAYER
(type 1)
When you insert a disc, gently push it in
with the label side up. The player will play
from track 1 through to the end of the
disc. Then it will play from track 1 again.
NOTICE
Never try to disassemble or oil any
part of the compact disc player. Do
not insert anything other than com-
pact discs into the slot.
8 cm (3 in.) compact disc singles
Your compact disc player does not need
an adaptor to play compact disc singles.
Compact disc singles are about 8 cm (3
in.) in diameter
−smaller than standard
discs.

270
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
After you eject a compact disc single, do
not insert a standard 12 cm (4.7 in.) disc
until “DISC” disappears from the display.
NOTICE
Do not use an adaptor for compact
disc singles—it could cause tracking
errors or interfere with the ejection of
compact discs.
YOUR COMPACT DISC PLAYER WITH
CHANGER (type 2 and type 3)
When you insert a disc, push the “LOAD”
button, wait for the load/eject status light
to turn green, then gently push the disc
in with the label side up. This compact
disc player can store up to six discs. The
player will play from track 1 through to
the end of the disc. Then it will play from
track 1 of the next disc.
The player is intended for use with 12 cm
(4.7 in.) discs only.
XS18007
NOTICE
Do not stack up two discs for in-
sertion, or it will cause damage to
the compact disc player or changer.
Insert only one compact disc into
slot at a time.
 Never try to disassemble or oil any
part of the compact disc player. Do
not insert anything other than com-
pact discs into the slot.
