If the washer does not work or the
message “LOW WASHER FLUID” ap-
pears on the multiinformation display,
the washer tank may be empty. Add
washer fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below the freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer ’s directions for how much to
mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the hybrid system and
light switch are off. Use bulbs with the
wattage ratings given in the table.
The stop/tail lights and high mounted stop-
light consist of a number of LEDs. If any
of the LEDs burn out, take your vehicle
to your Toyota dealer to have the light
replaced.
If two or more LEDs in a stop light burn
out, your vehicle may not conform to local
laws (SAE).
CAUTION
To prevent burning yourself, do not
replace the light bulbs while they
are hot.
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if
scratched or dropped. Hold a bulb
only by its plastic or metal case.
Do not touch the glass part of a
bulb with bare hands.
NOTICE
Only use a bulb of the listed type.
The inside of the lens of exterior lights
such as headlights may temporarily fog up
when the lens becomes wet in the rain or
in a car wash. This is not a problem
because the fogging is caused by the
temperature difference between the outside
and inside of the lens, just like the
windshield fogs up in the rain. However, if
there is a large drop of water on the
inside of the lens, or if there is water
pooled inside the light, contact your
Toyota dealer.
Adding washer fluidReplacing light bulbs—

’07Camry hybrid_U (L/O 0610)
374
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Light bulbsBulbNo.WTy p e
Headlights
(high)900560A
Headlights (low)—55B
Front side
marker lights—5C
Front turn
signal/parking
lights
3457NAK30/8D
Rear turn signal
lights—21D
License plate
lights—5C
Back −up lights92116C
Personal lights—5C
Interior light—8E
Door courtesy
lights1685C
Vanity lights—8C
Glove box light—1.2C
Trunk light—3.8C
A: HB3 halogen bulbs
B: H11 halogen bulbs
C: Wedge base bulbs (clear)
D: Wedge base bulbs (amber)
E: Double end bulbs If the front turn signal/parking, side
marker, tail or backup lights, or high
mounted stoplight burns out, contact
your Toyota dealer.
NOTICE
Do not try to replace the front turn
signal/parking, side marker, tail, back
up light and high mounted stoplight
bulbs by yourself. You may damage
the vehicle.
—Front turn signal/parking,
side marker, tail and backup
lights, and high mounted
stoplight

’07Camry hybrid_U (L/O 0610)
375
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Low beam (outside)High beam
(inside)
1. Open the hood. Turn the bulb basecounterclockwise to the front of the
vehicle as shown.
The above illustration shows the left −hand
headlight.2. Unplug the connector while depress- ing the lock release.
If the connector is tight, wiggle it.3. Plug in a new bulb into the connec- tor and install it into the mounting
hole.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.
—Headlights

’07Camry hybrid_U (L/O 0610)
376
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
—Rear turn signal lights

’07Camry hybrid_U (L/O 0610)
377
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)

’07Camry hybrid_U (L/O 0610)
379
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
SPECIFICATIONS
Specifications
Dimensions and weights380
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Engine 380
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel 381
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Traction motor 381
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Hybrid battery 381
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Service specifications 382
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Tires 385
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Fuses 386
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
SECTION 8

’07Camry hybrid_U (L/O 0610)
380
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Model:2AZ− FXE
Type:
4 cylinder in line, 4 cycle, gasoline
Bore and stroke, mm (in.):
88.5 96.0 (3.48 3.78)
Displacement, cm
3 (cu. in.):
2362 (144.1)
Dimensions and weights
Overall length mm (in.)
Overall width mm (in.)
Overall height
∗ mm (in.)
Wheelbase mm (in.)
Front tread mm (in.)
Rear tread mm (in.)
Vehicle capacity weight
(occupants + luggage) kg (lb.)
∗: Unladen vehicle 1470 (57.9) 4805 (189.2)
1820 (71.7)
2775 (109.3)
1575 (62.0)
1565 (61.6)
410 (900)
Engine

’07Camry hybrid_U (L/O 0610)
381
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Fuel type:Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): 65 (17.2, 14.3) Type:
Permanent magnet synchronous motor
Maximum output: 105 kW
Maximum torque: 270 N·m (27.5 kgf·m, 199 ft·lbf) Type:
Nickel −Metal hydride battery
Voltage: 7.2 V/module
Capacity: 6.5 Ah
Quantity: 34 modules
Overall voltage: 244.8 V
Fuel Traction motorHybrid battery
