2007 TOYOTA CAMRY HYBRID Owners Manual

’07Camry hybrid_U (L/O 0610)
125
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The “POWER” switch must be set at ON.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out. See “Replacing light
bulbs” on page 373 in Section 7−3.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the 12 volt battery from
being discharged, do not leave the
switch on longer than necessary when
the hybrid system is turned off.
Emergency flashers

’07Camry hybrid_U (L/O 0610)
126
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
To adjust the brightness of the instru-
ment panel lights, turn the knob.
With the knob turned fully clockwise, the
intensity of the instrument cluster lights
will not be reduced even when the tail
lights/headlights are turned on.Without moon roof
With moon roof
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when the illu-
minated entry system acts. For details,
see “Illuminated entry system” on page
127 in this Section.
Instrument panel light control Interior light

’07Camry hybrid_U (L/O 0610)
127
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
FRONT PERSONAL LIGHTS
To turn on the front personal light,
push the lens. To turn it off, push the
lens once again.REAR PERSONAL LIGHTS (vehicles with
moon roof)
To turn on the rear personal light, push
the switch. To turn it off, push the
switch once again.
By gently adjusting the shade of the rear
personal light, you can change the direc-
tion of the light to suit your preference.
When either of the rear side doors is
opened, the light on that side turns on
automatically. Closing the rear side doors
will turn the lights off.The interior light and the “POWER”
switch light come on and remain on for
about 15 seconds when you carry the
registered key into the entry function
actuation area. For further information
of entry function actuation area, see
“Smart key system” on page 32 in Sec-
tion 12.
If all the doors are closed and the
“POWER” switch is set at ACC or ON, the
lights will fade out.
If all the doors are locked, the lights will
fade out.
To prevent the 12 volt battery being dis-
charged, all of the lights will automatically
turn off when the “POWER” switch is
turned off, and the door is left opened for
about 20 minutes.
When any of the doors are unlocked with
wireless remote control function or me-
chanical key, the lights will come on and
remain on for about 15 seconds before
fading out.
When any of the doors are opened, the
lights will come on and remain on for
about 15 seconds before fading out.
Personal lights
Illuminated entry system

’07Camry hybrid_U (L/O 0610)
128
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
If all the doors are closed, when the
“POWER” switch is turned off, the lights
will come on and remain on for about 15
seconds.
This feature can be disabled and the dura-
tion of the lighting can be changed. For
details, ask your Toyota dealer.
To turn on the windshield wipers, move
the lever to the desired setting.
The “POWER” switch must be set at ON.Lever position
Operation
Position 1Intermittent operation
Position 2Low speed operation
Position 3High speed operation
Position 4Single sweep operation
Position 5Washer on
Rotating the band on the lever lets you
adjust the wiper time interval when the
wiper lever is in the intermittent position
(position 1). Twist the band upward to
increase the time between sweeps, and
downward to decrease it.
To spray washer fluid, pull the lever
toward you.
If the windshield wipers are off, they will
operate a couple of times after the washer
sprays.
For instructions on adding washer fluid,
see “Adding washer fluid” on page 373 in
Section 7 −3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
Windshield wipers and washer

’07Camry hybrid_U (L/O 0610)
129
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
When waxing your vehicle, make sure that
the washer nozzles do not become
blocked. If a nozzle becomes blocked,
contact your Toyota dealer to have the
vehicle serviced.
NOTICE
If a nozzle becomes blocked, do not
try to clear it with a pin or other
object. The nozzle will be damaged.
To defog or defrost the rear window,
push the switch.
The “POWER” switch must be set at ON.
The thin heater wires on the inside of the
rear window will quickly clear the sur-
faces. An indicator light will illuminate to
indicate the defogger is operating.
Heater panels in the outside rear view
mirrors will also quickly clear the sur-
faces.
Push the switch once again to turn the
defogger off.The system will automatically shut off
when the operation time has been com-
pleted. The operation time is between 15
minutes and 1 hour depending on the am-
bient temperature and vehicle speed.
CAUTION
Since the mirror surfaces can get hot
do not touch them when the defogger
switch is on.
Make sure you turn the defoggers off
when the surfaces are clear. Leaving the
defoggers on for a long time could cause
the 12 volt battery to discharge, especially
during stop−
and−go driving. The defoggers
are not designed for drying rain water or
for melting snow.
If the outside rear view mirrors are heavi-
ly coated with ice, use a spray de −icer
before operating the switch.
NOTICE
When cleaning the inside of the rear
window, be careful not to scratch or
damage the heater wires or connec-
tors.
Rear window and outside rear
view mirror defoggers

’07Camry hybrid_U (L/O 0610)
130
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)

’07Camry hybrid_U (L/O 0610)
131
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Gauges, Meters and Service reminder indicators
Fuel gauge132
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Engine coolant temperature gauge 132
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel economy meter 133
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Multi −information display 134
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Service reminder indicators and warning buzzers 150
. . . . . . . . . . . . . .
SECTION 1 6

’07Camry hybrid_U (L/O 0610)
132
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
The gauge indicates the approximate
quantity of fuel remaining in the tank
when the “POWER” switch is set at ON.
Nearly full—Needle at “F”
Nearly empty—Needle at “E”
It is a good idea to keep the tank over
1/4 full.
If the fuel level approaches “E” or the low
fuel level warning light comes on, fill the
fuel tank as soon as possible.
On inclines or curves, due to the move-
ment of fuel in the tank, the fuel gauge
needle may fluctuate or the low fuel level
warning light may come on earlier than
usual.If the fuel tank is completely empty, the
malfunction indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.The gauge indicates the engine coolant
temperature when the “POWER” switch
is set at ON. The engine operating tem-
perature will vary with changes in
weather and engine load.
1. Red zone
2. Blue zone
If the needle moves into the red zone,
your engine is too hot. If your vehicle
overheats, stop your vehicle and allow the
engine to cool.
Fuel gauge Engine coolant temperature
gauge
