2007 TOYOTA CAMRY HYBRID Owners Manual

’07Camry hybrid_U (L/O 0610)
37
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
For vehicles sold in Canada
This device complies with RSS−210 of
Industry Canada. Operation is subject to
the following two conditions:
(1) This device may not cause interfer-
ence, and (2) this device must accept
any interference, including interference
that may cause undesired operation of
the device.
For vehicles sold in U.S.A.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, includ-
ing interference that may cause unde-
sired operation.
NOTICE:
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are
designed to provide reasonable protec-
tion against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed
and used in accordance with the instruc-
tions, may cause harmful interference to
radio communications. However, there is
no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interfer-
ence to radio or television reception,
which can be determined by turning the
equipment off and on, the user is en-
couraged to try to correct the interfer-
ence by one or more of the following
measures:Reorient or relocate the receiving an-
tenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet
on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
FCC WARNING:
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
For vehicles sold in Canada
Operation is subject to the following two
conditions:
(1) this device may not cause interfer-
ence, and (2) this device must accept
any interference, including interference
that may cause undesired operation of
the device.

’07Camry hybrid_U (L/O 0610)
38
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
DISABLING THE SMART KEY SYSTEM
The following functions can be disabled:
A function that allows you to lock/un-
lock the doors and open the trunk by
simply carrying a key
A function that causes the vehicle to
beep if keys are forgotten inside the
vehicle or trunk and a door is closed
A function that recalls the position of
the driver ’s seat and side rear view
mirror
A function that shifts the power supply
mode and starts the hybrid system
when the electronic key is in the ve-
hicle.
Warning lights and buzzers
For details, contact your Toyota dealer.
If the smart key system does not oper-
ate properly because of a system mal-
function, consult your Toyota dealer.
Make sure to bring all of the keys. They
may be necessary to repair the system. When you carry the registered key with
smart key system into the actuation area,
you can lock and unlock the side doors
without using the key. For further informa-
tion of actuation area, see “Smart key
system” on page 32 in this Section.
Locking operation
Push the lock button on the front out-
side door handle slowly and firmly. All
the doors lock simultaneously. At this
time one beep will be heard and turn
signal lights flash once.
For three seconds after the doors have
been locked, the doors cannot be un-
locked via the smart key system. This
feature allows the operator to confirm that
the doors are locked.
In the following cases, the doors cannot
be locked by pushing the lock button and
a beep will sound as an indicator.
Side doors—
—Locking and unlocking with
smart key system

’07Camry hybrid_U (L/O 0610)
39
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
When any of the doors are not secure-
ly closed. A beep will sound continu-
ously for 10 seconds.
When the lock button is pressed while
opening or closing the door. A beep
will sound continuously for 10 seconds.
When the hybrid system is not turned
off. A beep will sound continuously for
2 seconds.
When the key is left in the vehicle. A
beep will sound continuously for 2 sec-
onds.
When attempting to lock the doors with
the key near a window or a door han-
dle. A beep will sound continuously for
2 seconds.
The beep may not sound if the key is on
the instrument panel, on the package tray,
in the glove box or on the floor, etc.
The answerback function (the turn signal
flash and the beep) can be disabled. For
details, contact your Toyota dealer.Unlocking operation
Grasp the front outside door handle
(sensors are located on the underside
of the door handles). Only the driver’s
door unlocks when the driver ’s door
handle is grasped. All the doors unlock
when the front passenger ’s door handle
is grasped. At this time two beeps will
be heard and the turn signal lights
flash twice.
The doors may not unlock if the handle
is grasped too quickly. Be sure to confirm
that the doors are unlocked before pulling
the door handle. If the doors do not open
when the handle is pulled, return the han-
dle to its original position. Wearing gloves may slow response time.
For three seconds after the doors have
been locked, the doors cannot be re
−un-
locked via the smart key system.
The answerback function (the turn signal
flash and the beep) can be disabled. For
details, contact your Toyota dealer.
When you enter the entry function actua-
tion area, the interior and exterior lights
come on for about 15 seconds. After the
light comes on, all the side doors can be
unlocked by grasping the outside door
handle.
You have 60 seconds to open a door after
using the unlocking function. If a door is
not opened by then, all the doors will be
automatically locked again.
The automatic locking time can also be
set to 30 seconds. For details, contact
your Toyota dealer.
The doors may unlock if the key is within
the entry function actuation area and a
large amount of water splashes on the
door handle (for example, in the rain or
in a car wash).
When you enter the entry function actua-
tion area, the illuminated entry system will
be activated. (For further information, see
“Illuminated entry system” on page 127 in
Section 1 −5.)

’07Camry hybrid_U (L/O 0610)
40
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
SELECTING DOORS TO BE UNLOCKED
WITH ENTRY FUNCTION
The unlocking operation has 2 modes.
To change the mode, within 1 m (3 ft.)
of the vehicle press the lock switch and
the alarm, trunk opener or unlock
switch simultaneously for five seconds.
The “POWER” switch must be turned off.
When the mode is changed, the buzzer
will sound and an indicator is displayed on
the multi−information display as follows: Mode
Door to be
unlocked
Wirelessremotecontrol
buzzerIndicator
and meter buzzer
1All doors2 beeps
1 beep
2
Driver ’s
door only
(from
driver ’s
door
switch)
All doors
(from front
passenger ’
s door
switches)
3 beeps
1 beep
Repeating the above process allows you
to toggle between 1 and 2.
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
The front doors can be opened by pulling
the inside handle even if the lock knobs
are in the locked position.
CAUTION
Do not pull the inside handle of the
front doors while driving. The doors
will open and an accident may occur.
Toyota strongly recommends that all
children be placed in the rear seat of
the vehicle.
—Locking and unlocking with
inside lock knob

’07Camry hybrid_U (L/O 0610)
41
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Closing the door with the lock knob in the
lock position will also lock the door. Be
careful not to lock your keys in the ve-
hicle.
Doors cannot be locked when either front
door is open and the key is left in the
vehicle.
Driver’s side
Passenger’s side
Push the switch.
To lock: Push the switch down on the
right side.
To unlock: Push the switch down on the
left side.
All the doors lock or unlock simultaneous-
ly.
When the front doors are locked from the
outside or locked with the wireless remote
control function, the power door lock
switch will not work until either front door
is unlocked with the key, lock knob, or
wireless remote control function.
—Locking and unlocking with
power door lock switch

’07Camry hybrid_U (L/O 0610)
42
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Insert the mechanical key into the key-
hole and turn it.
To lock: Turn the key forward.
All the doors lock simultaneously with the
driver ’s door.
For three seconds after the doors have
been locked, the doors cannot be un-
locked via the smart key system. This
feature allows the operator to confirm that
the doors are locked.
To unlock: Turn the key backward.
Turning the key once will unlock the driv-
er’s door and twice in succession will un-
lock all the doors simultaneously.This double key turning operation to un-
lock all the doors can be changed to a
single key turning operation. For details,
contact your Toyota dealer.
When you unlock the doors, the illumi-
nated entry system will be activated. (For
further information, see “Illuminated entry
system” on page 127 in Section 1
−5.) AUTOMATIC DOOR LOCKING
You can select the following functions:
Locking linked with the shift position
All doors are automatically locked when
the selector lever is moved out of “P”
position.
Locking linked with vehicle speed
All doors are automatically locked when
the vehicle speed goes above about 20
km/h (12 mph).
You can set or cancel the automatic
door locking functions:
Be sure to apply the parking brake when
performing the following operations.
—Locking and unlocking door
with mechanical key —Automatic door locking and
unlocking functions

’07Camry hybrid_U (L/O 0610)
43
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
To select the locking linked with the
shift position:1. Close all doors and set the “POWER” switch at ON.
2. Shift the selector lever to the “P” posi- tion.
3. Within 10 seconds of turning the “POWER” switch on, press and hold
the driver’s side power door lock
switch in the lock position for 5 sec-
onds and then release.
The doors will be locked and unlocked
to indicate that the function is set.
To cancel the function, do the above op-
eration again. To select the locking linked with the
vehicle speed:
1. Close all doors and set the “POWER” switch at ON.
2. Shift the selector lever from “P” to the “N” position.
3. Within 10 seconds of turning the “POWER” switch on, press and hold
the driver’s side power door lock
switch in the lock position for 5 sec-
onds and then release.
The doors will be locked and unlocked
to indicate that the function is set.
To cancel the function, do the above op-
eration again. AUTOMATIC DOOR UNLOCKING
You can select the following functions:
Unlocking linked with the shift posi-
tion
All doors are automatically unlocked
when the selector lever is moved to
“P” position.
Unlocking linked with the “POWER”
switch
All doors are automatically unlocked
when the driver ’s door is opened within
10 seconds after the “POWER” switch
is set from ON to ACC or OFF.
You can set or cancel the automatic
door unlocking functions:
Be sure to apply the parking brake when
performing the following operations.

’07Camry hybrid_U (L/O 0610)
44
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
To select the unlocking linked with the
shift position:1. Close all doors and set the “POWER” switch at ON.
2. Shift the selector lever to the “P” posi- tion.
3. Within 10 seconds of turning the “POWER” switch on, press and hold
the driver’s side power door lock
switch in the unlock position for 5 sec-
onds and then release.
The doors will be locked and unlocked
to indicate that the function is set.
To cancel the function, do the above op-
eration again. To select the unlocking linked with the
“POWER” switch:
1. Close all doors and turn the “POWER” switch at ON.
2. Shift the selector lever from “P” to the “N” position.
3. Within 10 seconds of turning the “POWER” switch on, press and hold
the driver’s side power door lock
switch in the unlock position for 5 sec-
onds and then release.
The doors will be locked and unlocked
to indicate that the function is set.
To cancel the function, do the above op-
eration again.
Move the lock lever to the “LOCK”
position as shown on the label.
When the child −protector is locked, you
cannot open the rear door by the inside
door handle. We recommend using this
feature whenever small children are in the
vehicle.
—Rear door childprotectors
