2007 NISSAN 350Z Engine Mechanical Workshop Manual

CAMSHAFT
EM-81
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z
In cases of removing/installing or replacing camshaft and valve-
related parts, or of unusual engine conditions due to changes in
valve clearance (found malfunctions during stating, idling or causing
noise), perform inspection as follows:
1. Remove rocker covers (right and left bank). Refer to EM-40, "
ROCKER COVER" .
2. Measure the valve clearance as follows:
a. Set No. 1 cylinder at TDC of its compression stroke.

Rotate crankshaft pulley clockwise to align timing mark
(grooved line without color) with timing indicator.

Make sure that intake and exhaust cam nose on No. 1 cylin-
der (engine front side of right bank) are located as shown in
the figure.

If not, turn crankshaft one revolution (360 degrees) and align
as shown in the figure.
b. Use a feeler gauge, measure the clearance between valve lifter
and camshaft.
Valve clearance:
Unit: mm (in)
*: Approximately 80°C (176°F)
SEM713A
: Timing mark (grooved line without color)
PBIC4966E
SEM418G
SEM139D
Items Cold Hot * (reference data)
Intake 0.26 - 0.34 (0.010 - 0.013) 0.304 - 0.416 (0.012 - 0.016)
Exhaust 0.29 - 0.37 (0.011 - 0.015) 0.308 - 0.432 (0.012 - 0.017)

EM-82
CAMSHAFT
Revision: 2006 November2007 350Z

By referring to the figure, measure the valve clearances at
locations marked “×” as shown in the table below (locations
indicated in the figure).

No. 1 cylinder at compression TDC
c. Rotate crankshaft by 240 degrees clockwise (when viewed from engine front) to align No. 3 cylinder at
TDC of its compression stroke.
NOTE:

To align cylinder No. 3 with the compression top dead center,
place matching marks (A) on the crankshaft pulley (1) side
and on the cylinder block side at a point 240° (b) counter-
clockwise from the compression top dead center using the
hex head of the crankshaft pulley bolt as a guide.
Measuring position (right bank) No. 1 CYL. No. 3 CYL. No. 5 CYL.
No. 1 cylinder at
compression TDCEXH×
INT×
Measuring position (left bank) No. 2 CYL. No. 4 CYL. No. 6 CYL.
No. 1 cylinder at
compression TDCINT×
EXH×
PBIC2054E
PBIC4984E

CAMSHAFT
EM-83
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z

By referring to the figure, measure the valve clearances at
locations marked “×” as shown in the table below (locations
indicated in the figure).

No. 3 cylinder at compression TDC
d. Rotate crankshaft by 240 degrees clockwise (when viewed from engine front) to align No. 5 cylinder at
TDC of its compression stroke.
NOTE:

To align cylinder No. 5 with the compression top dead center,
place matching marks (A) on the crankshaft pulley (1) side
and on the cylinder block side at a point 240° (b) counter-
clockwise from the compression top dead center using the
hex head of the crankshaft pulley bolt as a guide.
Measuring position (right bank) No. 1 CYL. No. 3 CYL. No. 5 CYL.
No. 3 cylinder at
compression TDCEXH×
INT×
Measuring position (left bank) No. 2 CYL. No. 4 CYL. No. 6 CYL.
No. 3 cylinder at
compression TDCINT×
EXH ×
PBIC2055E
PBIC4984E

EM-84
CAMSHAFT
Revision: 2006 November2007 350Z

By referring to the figure, measure the valve clearances at
locations marked “×” as shown in the table below (locations
indicated in the figure).

No. 5 cylinder at compression TDC
3. If the measured values are out of the standard, perform adjustment. Refer to EM-84, "
ADJUSTMENT" .
ADJUSTMENT

Perform adjustment depending on selected head thickness of valve lifter.
1. Measure the valve clearance. Refer to EM-80, "
INSPECTION" .
2. Remove camshaft. Refer to EM-72, "
REMOVAL" .
3. Remove valve lifters at the locations that are out of the standard.
4. Measure the center thickness of removed valve lifters with a
micrometer.
5. Use the equation below to calculate valve lifter thickness for replacement.
Measuring position (right bank) No. 1 CYL. No. 3 CYL. No. 5 CYL.
No. 5 cylinder at
compression TDCEXH×
INT×
Measuring position (left bank) No. 2 CYL. No. 4 CYL. No. 6 CYL.
No. 5 cylinder at
compression TDCINT×
EXH ×
PBIC2056E
KBIA0057E
Valve lifter thickness calculation: t = t1 + (C1 – C2 )
t = Valve lifter thickness to be replaced
t
1= Removed valve lifter thickness
C
1= Measured valve clearance
C
2= Standard valve clearance:
Intake : 0.30 mm (0.012 in)*
Exhaust : 0.33 mm (0.013 in)*
*: Approximately 20°C (68°F)

CAMSHAFT
EM-85
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z

Thickness of new valve lifter can be identified by stamp marks
on the reverse side (inside the cylinder).
Stamp mark 788T indicates 7.88 mm (0.3102 in) in thickness.
Available thickness of valve lifter: 27 sizes with range 7.88 to 8.40 mm (0.3102 to 0.3307 in) in steps of
0.02 mm (0.0008 in) (when manufactured at factory). Refer to EM-138, "
Available Valve Lifter" .
6. Install selected valve lifter.
7. Install camshaft. Refer to EM-77, "
INSTALLATION" .
8. Manually turn crankshaft pulley a few turns.
9. Make sure that the valve clearances for cold engine are within the specifications by referring to the speci-
fied values. Refer to EM-80, "
INSPECTION" .
10. Install all removal parts in the reverse order of removal. Refer to EM-77, "
INSTALLATION" .
11. Warm up the engine, and check for unusual noise and vibration.
KBIA0119E

EM-86
OIL SEAL
Revision: 2006 November2007 350Z
OIL SEALPFP:00100
Removal and Installation of Valve Oil SealNBS0000V
REMOVAL
1. Remove camshaft relating to valve oil seal to be removed. Refer to EM-72, "CAMSHAFT" .
2. Remove valve lifters. Refer to EM-72, "
CAMSHAFT" .
3. Turn crankshaft until the cylinder requiring new oil seals is at TDC. This will prevent valve from dropping
into cylinder.
4. Remove valve collet.

Compress valve spring with valve spring compressor, attach-
ment, adapter (SST). Remove valve collet with magnet hand.
CAUTION:
When working, take care not to damage valve lifter holes.
5. Remove valve spring retainer, valve spring and valve spring seat.
6. Remove valve oil seal using valve oil seal puller (SST).
INSTALLATION
1. Apply engine oil on new valve oil seal joint and seal lip.
2. Using valve oil seal drift (SST), press fit valve oil seal to height
“H” shown in the figure.
NOTE:
Dimension “H”: Height measured before valve spring seat instal-
lation
3. Install in the reverse order of removal after this step.
PBIC1803E
PBIC0884E
Intake and exhaust : 14.3 - 14.9 mm (0.563 - 0.587 in)
PBIC0802E

OIL SEAL
EM-87
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z
Removal and Installation of Front Oil SealNBS0000W
REMOVAL
1. Remove the following parts:

Undercover

Drive belts: Refer to EM-12, "DRIVE BELTS" .

Radiator cooling fan assembly: Refer to CO-21, "COOLING FAN" .

Crankshaft pulley: Refer to EM-53, "TIMING CHAIN" .
2. Remove front oil seal using suitable tool.
CAUTION:
Be careful not to damage front timing chain case and crank-
shaft.
INSTALLATION
1. Apply engine oil to both oil seal lip and dust seal lip of new front oil seal.
2. Install front oil seal.

Install front oil seal so that each seal lip is oriented as shown
in the figure.

Using suitable drift, press-fit until the height of front oil seal is
level with the mounting surface.
–Suitable drift: outer diameter 60 mm (2.36 in), inner diameter
50 mm (1.97 in).
CAUTION:

Be careful not to damage front timing chain case and
crankshaft.

Press-fit straight and avoid causing burrs or tilting oil
seal.
3. Install in the reverse order of removal after this step.
Removal and Installation of Rear Oil SealNBS0000X
REMOVAL
1. Remove transmission assembly. Refer to MT-18, "TRANSMISSION ASSEMBLY" (M/T models) or AT-
242, "TRANSMISSION ASSEMBLY" (A/T models).
2. Remove clutch cover and clutch disk (M/T models). Refer to CL-16, "
CLUTCH DISC, CLUTCH COVER" .
3. Remove flywheel (M/T models) or drive plate (A/T models). Refer to EM-107, "
CYLINDER BLOCK" .
PBIC2931E
SEM715A
PBIC2931E

EM-88
OIL SEAL
Revision: 2006 November2007 350Z
4. Remove rear oil seal with a suitable tool.
CAUTION:
Be careful not to damage crankshaft and cylinder block.
INSTALLATION
1. Apply new engine oil to new rear oil seal joint surface and seal lip.
2. Install rear oil seal so that each seal lip is oriented as shown.

Press in rear oil seal to the position as shown.

Using suitable drift, press-fit until the height of front oil seal is
level with the mounting surface.
–Suitable drift: outer diameter 100 mm (3.94 in), inner diameter
85 mm (3.35 in).
CAUTION:

Be careful not to damage crankshaft and cylinder block.

Press-fit oil seal straight to avoid causing burrs or tilting.
3. Install in the reverse order of removal after this step.
PBIC2932E
SEM715A
SBIA0281E
LBIA0454E
