2007 MERCEDES-BENZ S600 Owner's Manual

Page 505 of 705

MERCEDES-BENZ S600 2007 W221 Owners Manual 504 OperationTires and wheelsTire and Loading Information
Your vehicle is equipped with either the
Tire and Loading Information placard
(Example A) or the Vehicle Tire Information
placard (Example

Page 506 of 705

MERCEDES-BENZ S600 2007 W221 Owners Manual 505 Operation
Tires and wheels
Seating capacity
The seating capacity gives you important
information on the number of occupants
that can be in the vehicle. Observe front
and rear seating capacity.

Page 507 of 705

MERCEDES-BENZ S600 2007 W221 Owners Manual 506 OperationTires and wheelsStep 3
Subtract the combined weight of the
driver and passengers from XXX kilo-
grams or XXX lbs.
Step 4

The resulting figure equals the avail-
able amount of cargo an

Page 508 of 705

MERCEDES-BENZ S600 2007 W221 Owners Manual 507 Operation
Tires and wheels
The higher the weight of all occupants, the
less cargo and luggage load capacity is
available.
For more information, see “Trailer tongue
load” (
page 508).
Examp

Page 509 of 705

MERCEDES-BENZ S600 2007 W221 Owners Manual 508 OperationTires and wheelsCertification label
Even after careful determination of the
combined weight of all occupants, cargo
and the trailer tongue load (if applicable)
(page 508) as to not ex

Page 510 of 705

MERCEDES-BENZ S600 2007 W221 Owners Manual 509 Operation
Tires and wheels
Recommended tire inflation pressure
Your vehicle is equipped with either the
Tire and Loading Information placard
(Example A) or the Vehicle Tire Information
placard

Page 511 of 705

MERCEDES-BENZ S600 2007 W221 Owners Manual 510 OperationTires and wheelsPlacard (Example B)
1Vehicle Tire Information placard with
recommended cold tire inflation
pressures
Placard (Example B) lists the recommend-
ed cold tire inflation pres

Page 512 of 705

MERCEDES-BENZ S600 2007 W221 Owners Manual 511 Operation
Tires and wheels
Checking tire inflation pressure
Regularly check your tire inflation pressure
at least once a month.
Check and adjust the tire inflation
pressure when the tires are co
