2007 MERCEDES-BENZ S600 Owner's Manual

96 Control systemsCOMAND FM/AM radioSelecting channels using the channel
list
Select “Audio”
“Audio”
“FM/AM
Radio”
“WB”
“Channel”.
or

Press n when the main area is select-
ed.
The channel list appears. The dotR in
front of a list entry indicates the cur-
rently selected channel.

Select channel by rotating ymz or
slidingqmr and press n.
Saving stationsYou have the following options:


Saving stations manually


Saving stations using Autostore
Saving stations manually
Option 1

Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.

Select “Radio ”
“Save Station”.
Option 2

Press n when the main area is select-
ed.
Option 3

Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.

Select “Presets”.
All three of these will call up a station
preset screen. The dot R in front of a
preset position indicates that the cur-
rently selected station is saved there.

Selecting a preset position:
Slideqmr or rotate ymz.
Saving a station to a selected preset po-
sition
If you have called up the station preset
screen using option 1:

Press n briefly.
In options 2 and 3:

Press and hold n until you hear a sig-
nal.
The station is saved.
i
If you enter a frequency in the AM waveband
which is outside the frequency range, COMAND
tunes in to the next lowest frequency.
i
This function is only available for Weather
Band.
i
Twenty stations can be saved in each wave-
band except for Weather Band.


97 Control systems
COMAND FM/AM radio
Saving using autostore
Option 1
Press n when the main area is select-
ed.

Select “Autostore”.
Option 2

Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.

Select “Presets”
“Autostore”.
Option 3

Select “Audio”
“Audio”
“FM/AM
Radio”
“Radio”
“Save Station”

“Autostore”.
Station name display
1Station name display
Switching the station name display
on/off: Select “Audio”
“Audio”

“FM/AM Radio”
“FM”
“Radio”

“Show Station Info”.The display is switched on or off, de-
pending on the previous setting. When
the display is switched on, a check-
mark appears in front of the
“Show Station Info” menu item.
i
This function is not available for Weather
Band. The Autostore function saves receivable
stations as presets in order of their reception
quality. All stations saved manually in the preset
memory will be lost if COMAND finds 20 sta-
tions. If COMAND finds less than 20 stations, for
example 9, then the stations saved in preset po-
sitions 1 – 9 will be over written.
i
In the FM waveband, COMAND can show
the name of the station currently tuned in. Sta-
tion name display 1 can only be seen when it is
switched on and if the station transmits a name.

98 Control systemsCOMAND satellite radio* (USA only)Submenu overviewIntroduction to Satellite radio
Sirius Satellite Radio provides 100 chan-
nels, so called streams, of digital-quality
radio, among others music, sports, news,
and entertainment free of commercials.
Sirius Satellite Radio uses a fleet of high-power satellites to broadcast 24
hours per day, coast-to-coast, in the con-
tiguous US.
This diverse, satellite-delivered program-
ming is available for a monthly subscrip-
tion fee.
For more information and service availabil-
ity call the Sirius Service Center
(
page 103), or go to
www.siriusradio.com.
i
The components and operating principles of
COMAND can be found on (
page 79).
Sat Radio
Presets
Info
Category
Sound
Channel List
Station presets
Show program info
Select category
Treble
Save Channel
Bass
Channel Entry
Balance/Fader
Service
3D Sound
i
A subscription to Sirius satellite radio ser-
vice provider is required for the satellite radio op-
eration described in this chapter. Contact an
authorized Mercedes-Benz Center for details
and availability for your vehicle.
i
Satellite radio service may be unavailable or
interrupted from time to time for a variety of rea-
sons, such as environmental or topographic con-
ditions and other things we can’t control. Service
might also not be available in certain places
(e.g., in tunnels, parking garages, or within or
next to buildings) or near other technologies. In
such situations, the satellite radio’s main menu
shows the “Acquiring signal...” screen. At this
point, the radio’s functions are restricted to
manual channel number entry (
page 101) and
service info display (
page 103).

99 Control systems
COMAND satellite radio* (USA only)
Switching to satellite radio
Select “Audio”
“Audio”
“Sat Ra-
dio”.
or

Press the M shortcut button once or
twice. The Satellite radio menu appears
if it was the last active radio mode.
The screen which then appears de-
pends on the activation status of the
satellite radio service.
The following options are possible:

Satellite radio service is not activat-
ed


Only the preview channel is activat-
ed


Satellite radio service is fully acti-
vatedSatellite radio service is not activated
The telephone number of the Sirius Service
Center and the twelve-digit electronic seri-
al number (SIRIUS-ID) of the particular re-
ceiver are displayed.
This information is required when calling
the Sirius Service Center for an activation
request.

Closing screen: Press n.Only the preview channel is activated
The satellite radio preview channel ap-
pears.
Satellite radio service is fully activated
The main satellite radio menu appears. You
will hear the channel last tuned in, provid-
ed that it can be received.
i
Credit card information is also required for
your application. The activation process takes
approximately 5 to 10 minutes after calling the
Sirius Service Center.
i
If only the preview channel is activated, you
cannot tune in another channel. If you try to do
this, you will see the screen described in the sec-
tion “Satellite radio service is not activated”
(
page 99).

100 Control systemsCOMAND satellite radio* (USA only)Main satellite radio menu
1Main area with channel display
2Preset position of selected channel
3Selected channel
4Selected program category
5Sound settings
6To select program category
7Channel number of selected channel
8Other channel information
9Preset options
aSatellite radio options
Selecting program category
Select “Audio”
“Audio”
“Sat Ra-
dio”
“Category”.
The category list appears.

Select category by rotating ymz or
sliding qmr and press n.
When selecting a channel using the
channel search function or the channel
list, you have access to the channels
you subscribe to and which are includ-
ed in the selected category.
Tuning in channels
You have the following selection options:

The channel search function


The channel presets


The manual channel number entry


The channel list
i
Main area 1 can show all channels includ-
ed in your subscription. Which channels are
shown depends on the selected program catego-
ry 4.
Note that categories and channels shown in illus-
trations are dependent on programming content
delivered by the service provider. Programming
content is subject to change.
Therefore, channel and categories shown in illus-
trations and descriptions contained in this man-
ual may differ from the channels and categories
delivered by the service provider.
i
The channels are categorized. Categories al-
low you to tune to stations broadcasting a cer-
tain type of program.
i
If only the preview channel is activated, only
certain categories are available on the list. Which
categories these are depend on the service pro-
vider.
i
When you select the category “All Chan-
nels”, you have access to all the channels you
subscribe to, regardless of category, when you
are tuning in a channel using the channel search
function or the channel list.

101 Control systems
COMAND satellite radio* (USA only)
Tuning in channels using channel
search function
Slide omp or rotate ymz when the
main area is selected.
Depending on the direction in which
the controller is being pressed or rotat-
ed, the system searches upward or
downward and stops at the next receiv-
able channel.
Tuning in channels using channel pre-
sets

Select “Audio”
“Audio”
“Sat Ra-
dio”
“Presets”.
or

Press n when the main area is select-
ed.
The preset menu appears. The dotR
in front of a preset position indicates
that this is the channel currently select-
ed and being listened to.

Select station preset and briefly
pressn.
COMAND tunes in the corresponding
channel as long as it is included in your
subscription and is still available.
If the channel is not included in your
subscription, you will see the message
described in the section “Satellite radio
service is not activated” (
page 99).If the channel is no longer available or
only the preview channel is activated,
you will see the message “Invalid Chan-
nel”.

Closing message: Press n.
Tuning in channels using manual chan-
nel number entry

Select “Audio”
“Audio”
“Sat Ra-
dio”
“Sat Radio”
“Channel Entry”.
The menu for manual channel number
entry appears.

Exiting menu without making an en-
try: Press L back button in the cen-
ter console (
page 80).

Increase or decreasing number:
Slide qmr or rotate ymz.

Selecting next number: Slideomp.
i
This function is not possible when only the
preview channel is activated. If you try to tune in
a channel in this instance, you will see the
screen described in the section “Satellite radio
service is not activated” (
page 99).
i
Which channels are found by the channel
search function depends on which channels you
have subscribed to and the program category
you have selected (
page 100).
i
This function is not possible when only the
preview channel is activated. If you try to tune in
a channel in this instance, you will see the
screen described in the section “Satellite radio
service is not activated” (
page 99).


102 Control systemsCOMAND satellite radio* (USA only)
Confirming channel entry: Press n.
Further operation depends on whether
the selected channel number is valid or
if the channel is included in your sub-
scription.
Channel number is valid and channel is
included in subscription
COMAND tunes in the channel entered.
Channel number is invalid
You will see the message “Invalid Chan-
nel”.

Closing message: Press n.
Channel number is valid but channel is
not included in subscription
You will see the screen described in the
section “Satellite radio service is not acti-
vated” (
page 99).

Closing display: Press n.Tuning in channels using the channel
list

Select “Audio”
“Audio”
“Sat Ra-
dio”
“Sat Radio”
“Channel List”.
The channel list appears. The dotR in
front of a list entry indicates the cur-
rently selected channel.

Select channel by rotating ymz or
slidingqmr and press n.
Saving channels
Option 1
Select “Audio”
“Audio”
“Sat Ra-
dio”
“Sat Radio”
“Save Channel”.Option 2

Press n when the main area is select-
ed.
Option 3

Select “Audio”
“Audio”
“Sat Ra-
dio”
“Presets”.
All three of these will call up a preset
menu. The dot R in front of a preset
position indicates that this is the chan-
nel currently selected and being lis-
tened to.

Selecting a preset position:
Slideqmr or rotate ymz.
i
The contents of the channel list depends on
which channels are included in your subscription
and which program category you have selected
(
page 100). If only the preview channel is acti-
vated, the channel list contains only the preview
channel.
i
There are twenty preset positions available.


103 Control systems
COMAND satellite radio* (USA only)
Saving a channel to a selected preset
position
If you have called up the channel preset
screen using option 1:
Press n briefly.
In options 2 and 3:

Press and hold n until you hear a sig-
nal.
The channel is saved.
Show program info
Select “Audio”
“Audio”
“Sat Ra-
dio”
“Info”.
You will see a screen that may contain the
following information:


Selected program category


Selected channel


Artist of the track currently being
played


Name of current track

Closing screen: Slide omp or
pressn.
Channel update
The service provider may conduct a chan-
nel update.
During the update, the message “Updating
channels...” will appear on the display.
No functions can be operated in satellite
radio mode during the update.
Calling Sirius Service Center
Select “Audio”
“Audio”
“Sat Ra-
dio”
“Sat Radio”
“Service”.
The telephone number of the Sirius
Service Center and the twelve-digit
electronic serial number (SIRIUS-ID) of
the particular receiver are displayed.

Closing screen: Slide omp or
pressn.
i
If the program provider does not offer any in-
formation, the “Info” menu item cannot be se-
lected.
i
The program provider determines what in-
formation is displayed on the screen. COMAND
shows no more than two lines per item of infor-
mation. If an item of information is too long,
COMAND shortens it.
i
It may be necessary to call the Sirius Service
Center if, for example:


You want to cancel the subscription or
re-subscribe at a later date


You forget to pay the bill


You sell the car to another person
