Page 217 of 705

216 Control systemsCOMAND system settingsCanceling during the first or second part
of individualization
Select “Cancel”.
A prompt appears asking whether you
really do want to cancel.
Select “Yes” or “No”.
If you select “Yes”, individualization will
be canceled. The data from the part at
which you exited is not saved.
If you select “No”, the part at which you
stopped begins again.
Deleting existing individualization data
Select “Vehicle” “System Settings”
“Voice Control” “Delete individu-
alization”.
A prompt appears asking whether you
really do want to delete.
Select “Yes” or “No”.
The individualization data will either be
deleted or not, depending on your se-
lection.
Setting the system language
Select “Vehicle” “System Settings”
“Language”.
The language list appears. A dot R in-
dicates the current setting.
Changing setting: Select desired lan-
guage.
The language is set.
Assigning the favorite button
1Favorite buttonYou can assign the following predefined
functions to the favorite buttonP:
“Rear Window Sunshade”
You can use the favorite button to ex-
tend or retract the rear window sun-
shade. This is the default setting.
“Display OFF”
You can use the favorite button to
switch the COMAND display on or off.
“Tow-away Alarm”
You can use the favorite button to acti-
vate or deactivate the tow-away
alarm*.
“Repeat Navigation Command”
You can use the favorite button to re-
call the last command issued by the
navigation system.
Select “Vehicle” “System Settings”
“Favorite”.
The list of predefined functions appears.
The dot R in front of the list entry indi-
cates the current setting.
Page 218 of 705

217 Control systems
COMAND system settings
Changing setting: Rotate ymz and
select desired function.
Saving setting and exit the menu:
Press n.
Bluetooth settings
General information about Bluetooth
Bluetooth technology is the standard for
short-range wireless data transmission of
up to approximately 10 meters. Bluetooth
can be used to exchange vCards or make
calls using a headset.
Activate or deactivate Bluetooth
Select “Vehicle” “System Settings”
“Services” “Deactivate Blue-
tooth”.
You have activated or deactivated Blue-
tooth. A checkmark appears when
Bluetooth is deactivated.Connecting Bluetooth devices
It is possible to establish a Bluetooth con-
nection between COMAND and the follow-
ing types of device:
Mobile phone (only for transferring
business cards)
Headset
Laptop / PDA
You can connect up to twelve devices to
COMAND but only one device can be ac-
tive at a time.
The connection process includes search-
ing for the device and its subsequent au-
thorization.Calling up the Bluetooth device list and
searching for devices
Calling up the list: Select “Vehicle”
“System Settings” “Services”
“Search for Bluetooth devices”.
When you call up the list for the first
time after switching on COMAND, the
search for devices in the reception
range starts automatically. You will see
a display to this effect.
The device list appears after a short
while.
Canceling search:
Select “Cancel”.
The second time you call up the list, and
each time thereafter, the device list ap-
pears immediately if COMAND has not
been switched off and on again in the
meantime.
Starting search manually:
select “Update”.
i
To connect a Bluetooth device, the Blue-
tooth function must be activated in COMAND
and in the device concerned. The Bluetooth de-
vice must also be set to “visible” or “findable” in
order for COMAND to find and display it. For the
setting procedures, please see the operating in-
structions for the Bluetooth device.
Page 219 of 705

218 Control systemsCOMAND system settingsThe device list can contain the following
devices:
All detected devices, whether autho-
rized or not.
All authorized devices, whether detect-
ed or not.
1Authorized and detected device – de-
vice and padlock symbol are the same
color
2Device which was not detected, but
which has been authorized in the past
– device and padlock symbol are differ-
ent colors (the device may be switched
off or not in the vehicle, for example)
3Newly detected device - not yet autho-
rized (no symbol)Displaying details of a Bluetooth device
Call up Bluetooth device list
(page 217).
Select desired device.
Select “Details”.
The detailed display for this device ap-
pears.
Closing detailed display: Slide qmr
or press n.Authorizing a Bluetooth device
Call up Bluetooth device list
(page 217).
Select unauthorized device.
Select “Authorize”.
The input menu for the passkey ap-
pears.
i
If the device list already contains twelve au-
thorized devices, you must revoke authorization
for one of the authorized devices. Then you must
switch this device off and then restart the
search. Any new devices for which you would like
to search will otherwise not appear in the list.
i
The passkey is any one to sixteen-digit num-
ber which you can set yourself. You must enter
the same number in COMAND and also in the de-
vice to be authorized.
i
On devices which do not have an input key-
pad (e.g. headsets), the passkey is predeter-
mined. In this case, it is not necessary to enter
the number on the device itself. You will usually
find the passkey in the operating instructions for
the device.
Page 220 of 705

219 Control systems
COMAND system settings
Entering passkey into COMAND:
Select the digits one by one.
Deleting digits: Select ) and briefly
press n.
Canceling entry into COMAND:
select “Back”.
Confirming entry into COMAND:
Select?.
If necessary, enter the same passkey
into the Bluetooth device (see the op-
erating instructions for the device).
The device is authorized.De-authorizing a Bluetooth device
Call up Bluetooth device list
(page 217).
Select authorized device.
Select “De-authorize”.
A prompt appears asking whether you
really want to de-authorize this device.
Select “Yes” or “No”.
If you select “Yes”, the device will be
de-authorized.
Reset
Select “Vehicle” “System Settings”
“Reset”.
A prompt appears asking whether you
really want to reset.
Select “Yes” or “No”.
If you select “Yes” another prompt will
appear asking whether you really want
to reset.
Select “Yes” or “No”.
If you select “Yes”, COMAND will be re-
set and restarted.
i
If you de-authorize a device which has been
authorized in the past and which is not detected
in the search, this device will no longer be dis-
played in the device list.
Devices which have been authorized in the past
but which are not detected in the search are ei-
ther not switched on or not in the vehicle.
i
You can reset COMAND back to its factory
settings.
In this case, all personal data (e.g. address book
entries, entries in the destination memory and
the list of last destinations of the navigation sys-
tem), among other things, is deleted.
Page 221 of 705

220 Control systemsCOMAND vehicle menuIn this menu, you can program the follow-
ing vehicle functions:
Setting night security illumination
(Exterior Lighting Delayed Switch-off)
Use this function to set whether and how
long you would like the exterior lighting to
illuminate during darkness after exiting the
vehicle and all doors closed.
The exterior lighting automatically goes
out after the delayed switch-off time has
expired.
You can select:
“0 sec.”, the delayed switch-off feature
is deactivated
“15 sec.”, “30 sec.”, “45 sec.”, or
“60 sec.”, the delayed switch-off fea-
ture is activated
Select “Vehicle”.
The main area is active.
Selecting “Exterior Lighting Delayed
Switch-off” menu: Slide omp or
rotateymz.
Confirming selection: Press n.
Selecting length of time: Slide qmr
or rotate ymz.
Confirming selection: Press n.
or
Select “Vehicle” “Vehicle” “Exte-
rior Lighting Delayed Switch-off”.
A selection list appears.
The current setting is indicated by a
dotR.
Function
Page
Exterior Lighting Delayed
Switch-off
220
Locator Lighting
221
Exterior Mirror Convenience Set-
tings
222
Automatic Locking
223
Easy Entry/Exit Feature
224
Interior Ambient Light
225
Interior Lighting Delayed
Switch-off
226
Rear Window Sunshade
227
Trunk Opening-height Restriction
227
Tow-away Alarm
228
i
The components and operating principles of
COMAND can be found on (
page 79).
i
You can reactivate this function within
10 minutes by opening a door.
Page 222 of 705

221 Control systems
COMAND vehicle menu
Selecting length of time: Slide qmr
or rotate ymz.
Confirming selection: Press n.
To activate night security illumination:
Select delayed switch-off period (see
above).
Turn the exterior lamp switch to
position* before turning off the en-
gine.
Locator lighting on/off
With the locator lighting feature activated
and the exterior lamp switch in position
*(
page 346), the following lamps will
switch on during darkness when the vehi-
cle is unlocked from the outside:
Parking lamps
Tail lamps
License plate lamps
Front fog lamps
Door entry lamps in the mirror
Side marker lamps
The locator lighting switches off when the
driver’s door is opened.If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after approxi-
mately 40 seconds.
Select “Vehicle”.
The main area is active.
Selecting “Locator Lighting” func-
tion: Slide omp or rotate ymz.
Confirming selection: Press n.
Switching locator lighting on or off:
Press n.
or
i
The components and operating principles of
COMAND can be found on (
page 79).
Page 223 of 705

222 Control systemsCOMAND vehicle menu
Select “Vehicle” “Vehicle” “Loca-
tor Lighting”.
A checkmark appears when the locator
lighting is switched on.
Confirming selection: Press n.
To activate locator lighting:
Make sure the function “Locator Light-
ing” is set.
Turn the exterior lamp switch to
position* when exiting the vehicle.
Exterior mirror convenience settings
In the “Exterior Mirror Convenience Set-
tings” menu, you can switch the following
exterior mirror functions on or off:
Exterior mirrors automatically fold in
when the vehicle is locked
Exterior mirror on front passenger’s
side automatically tilts downward
when the vehicle is reversing
Select “Vehicle”.
The main area is active.
Selecting “Exterior Mirror Conve-
nience Settings” menu: Slide omp or
rotate ymz.
Confirming selection: Press n.
Selecting “Fold in automatically
when locking” or “Lower mirror
when reversing”: Rotateymz.
Confirming selection: Press n.
Slide omp to exit.
or
i
The components and operating principles of
COMAND can be found on (
page 79).
Page 224 of 705
223 Control systems
COMAND vehicle menu
Select “Vehicle” “Vehicle” “Exte-
rior mirror Convenience Settings”.
A selection list appears.
Selecting a function: Slide qmr or
rotateymz.
A checkmark appears in the corre-
sponding box when the option has
been selected.
Confirming selection: Press n.
Slide omp to exit.
Automatic locking on/off
Use this function to activate or deactivate
the automatic central locking
(page 313). With the automatic central
locking system activated, the vehicle is
centrally locked at vehicle speeds of ap-
proximately 9 mph (15 km/h).
Select “Vehicle”.
The main area is active.
Selecting “Automatic Locking” func-
tion: Slide omp or rotate ymz.
Switching automatic locking on or
off: Press n.
or
Select “Vehicle” “Vehicle” “Auto-
matic Locking”.
A checkmark appears when automatic
locking is switched on.
Confirming selection: Press n.
Slide omp to exit.
i
The components and operating principles of
COMAND can be found on (
page 79).
