2007 MERCEDES-BENZ S600 Owner's Manual

224 Control systemsCOMAND vehicle menuActivating easy-entry/exit feature
Use this function to activate and deacti-
vate the easy-entry/exit feature
(page 328).
The following settings are available for the
easy-entry/exit feature:

Select “Vehicle”.
The main area is active.

Selecting “Easy Entry/Exit Feature”
menu: Slide omp or rotate ymz.

Confirming selection: Press n.
or

Select “Vehicle”
“Vehicle”
“Easy
Entry/Exit Feature”.

Confirming selection: Press n.
A selection list appears.
The current setting is indicated by a
dotR.
i
The components and operating principles of
COMAND can be found on (
page 79).
OFF
The easy-entry/exit
feature is deactivated.
Steering Column
& Seat
Both the steering col-
umn and the driver’s
seat are moved.
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the easy-en-
try/exit feature is activated.
To cancel seat/steering wheel movement,
do one of the following:

Press seat adjustment switch
(page 319).


Move steering column stalk
(page 330).


Press one of the memory position but-
tons or the memory button M
(page 337).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

225 Control systems
COMAND vehicle menu

Selecting a setting: Slide qmr or
rotateymz.

Confirming selection: Press n.
Setting interior ambient lighting
You can adjust the brightness of the interi-
or lighting on a scale of “0” (off) to “5”
(bright).
Select “Vehicle”.
The main area is active.

Selecting “Interior Ambient Light”
menu: Slide omp or rotate ymz.

Confirming selection: Press n.

Adjusting brightness: Slide omp or
rotate ymz.

Confirming selection: Press n.
or

Select “Vehicle”
“Vehicle”
“Interi-
or Ambient Light”.

Adjusting brightness: Slide qmr or
rotate ymz.

Confirming selection: Press n.
i
The components and operating principles of
COMAND can be found on (
page 79).

226 Control systemsCOMAND vehicle menuSetting interior lighting delayed switch-off
Use this function to set whether and how
long you would like the interior lighting to
remain lit during darkness after you have
removed the SmartKey from the starter
switch.
You can select:

“0 sec.”, the delayed switch-off feature
is deactivated


“15 sec.”, “30 sec.”, “45 sec.”, or
“60 sec.”, the delayed switch-off fea-
ture is activated

Select “Vehicle”.
The main area is active.

Selecting “Interior Lighting Delayed
Switch-off” menu: Slide omp or
rotateymz.

Confirming selection: Press n.
A selection list appears.
The current setting is indicated by a
dotR.

Selecting length of time: Slide qmr
or rotate ymz.

Confirming selection: Press n.
or

Select “Vehicle”
“Vehicle”
“Interi-
or Lighting Delayed Switch-off”.
A selection list appears.
The current setting is indicated by a
dotR.

Selecting length of time: Slide qmr
or rotate ymz.

Confirming selection: Press n.
i
The components and operating principles of
COMAND can be found on (
page 79).

227 Control systems
COMAND vehicle menu
Extending or retracting rear window sunshade
This function is used to extend or retract
the rear sunshade.
Select “Vehicle”.
The main area is active.

Selecting “Rear-window Sunshade”
function: Slide omp or rotate ymz.

Extending or retracting rear window
sunshade: Press n.
or

Select “Vehicle”
“Vehicle”

“Rear-window Sunshade”.

Confirming selection: Press n.
Trunk opening-height restriction on/off
You can select whether the trunk lid should
open fully or only to the height of the roof.
Select “Vehicle”.
The main area is active.

Selecting “Trunk Opening-height Re-
striction” function: Slide omp or
rotateymz.

Confirming selection: Press n.
or
i
The components and operating principles of
COMAND can be found on (
page 79).
i
If you operate the rear-window sunshade via
COMAND or by using the favorite button
(
page 216), this takes precedence over the
buttons for the rear window sunshade in the rear
doors (
page 456).
i
You can program this function using the fa-
vorite button (
page 216).
i
At temperatures below -4°F (-20°C), the
rear window sunshade is switched off.
i
The components and operating principles of
COMAND can be found on (
page 79).


228 Control systemsCOMAND vehicle menu
Select “Vehicle”
“Vehicle”
“Trunk
Opening-height Restriction”.
A checkmark appears when the trunk
opening-height restriction is switched
on.

Confirming selection: Press n.
Switching on/of the tow-away alarm
To prevent triggering the tow-away alarm
feature (
page 76), switch off the
tow-away alarm before towing the vehicle,
or when parking on a surface subject to
movement, such as a ferry or auto train.

Select “Vehicle”.
The main area is active.

Selecting “Tow-away Alarm” func-
tion: Slide omp or rotate ymz.

Confirming selection: Press n.or

Select “Vehicle”
“Vehicle”

“Tow-away Alarm”.
A checkmark appears when the
tow-away alarm is switched on.

Confirming selection: Press n.
i
The components and operating principles of
COMAND can be found on (
page 79).
i
You can program the tow-away alarm func-
tion (page 216) using the favorite button in the
center console.
When you press the favorite button, you can
switch the functions on or off.


229 Control systems
COMAND automatic climate control
COMAND automatic climate control
You can operate the automatic climate
control via COMAND or via the buttons on
the front and rear* automatic climate con-
trol panel (
page 424).
The following automatic climate control
functions can be operated via COMAND:The automatic climate control menu is
called up via the climate control settings.
Climate control settings with functions
(submenus)1Temperature, left
2Air distribution, left
3Air volume, left
4Central menu, climate control
5Air volume, right
6Air distribution, right
7Temperature, right
i
The components and operating principles of
COMAND can be found on (
page 79).
Warning!
G
When operating the automatic climate con-
trol, the air that enters the passenger com-
partment through the air vents can be very
hot or very cold (depending on the set tem-
perature). This may cause burns or frostbite
to unprotected skin in the immediate area of
the air vents.
Always keep sufficient distance between un-
protected parts of the body and the air
vents. If necessary, use the air distribution
adjustment (
page 230) to direct the air to
air vents in the vehicle interior that are not
in the immediate area of unprotected skin.
Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pages
and pages in the “Controls in detail” part
(page 424) Otherwise the windows could
fog up, impairing visibility and endangering
you and others.
Function
Page
Temperature
230
Air distribution
230
Air volume
230
Switching off cooling (“AC
OFF”)
231
Central climate control (“Mono”)
232
Footwell temperature
232
Air flow from air vents
233
Rear climate control*
234

230 Control systemsCOMAND automatic climate controlSetting temperature
Use the temperature controls %$
(page 426) in the center console or
COMAND climate control settings to sepa-
rately adjust the air temperature on each
side of the passenger compartment.

Select climate control settings
Tem-
perature, left or right and then
pressn.

Changing temperature: Slide qmr or
rotate ymz.

Exiting menu: Press n, back
buttonL in the center console
(page 80) or slideomp.
The setting is saved.
Adjusting air distribution
You can adjust the air distribution sepa-
rately for the driver’s and front passenger’s
side.
Select climate control settings
Air
distribution, left or right.

Changing air distribution:
Rotateymz.
The symbol for air distribution changes.
The direction and size of the arrows
represent the air distribution.

Exiting menu: Press n, back
buttonL in the center console
(page 80) or slideomp.
The setting is saved.
Adjusting air volume
Use buttonsQ (
page 426) in the cen-
ter console or COMAND climate control
settings to separately adjust the air vol-
ume on each side of the passenger com-
partment.

Select climate control settings
Air
volume, left or right.
i
When you change the air distribution, the au-
tomatic function of the climate control system is
switched off.
i
When you change the air volume, the auto-
matic function of the climate control system is
switched off.

231 Control systems
COMAND automatic climate control

Changing air volume: Slide qmr or
rotate ymz.

Exiting menu: Press n, back
buttonL in the center console
(page 80) or slideomp.
The setting is saved.
Central climate control menu via
COMAND
The central climate control menu is in the
center of the climate control settings.
When the automatic climate control is
switched on, you will see “on” in the cen-tral menu. The following functions can only
be operated in the central climate control
menu via COMAND:

Select climate control settings
Cen-
tral menu.Switching cooling on or off
The cooling function, only operational
when the engine is running, cools the vehi-
cle interior down to the selected tempera-
ture. The cooling function also
dehumidifies the air in the vehicle interior,
thus preventing the windows from fogging
up.
The “AC
OFF” function is used to permanent-
ly switch off the cooling function of the au-
tomatic climate control system.
Function
Page
Switching off cooling (“AC
OFF”)
231
Central climate control (“Mono”)
232
Footwell temperature
232
Air flow from air vents
233
Rear climate control
234
i
Condensation may drip out from underneath
the vehicle. This is normal and not an indication
of a malfunction.Warning!
G
If you turn off the cooling function, the
vehicle will not be cooled when weather
conditions are warm. The windows can fog
up more quickly. Window fogging may
impair visibility and endanger you and
others.
