2007 MERCEDES-BENZ S600 Owner's Manual

448 Controls in detailLoading and storingStorage compartmentsStorage compartments in the front pas-
senger compartment
Glove box
1Glove box lid release
2Unlocking glove box
3Locking glove box
The glove box can be unlocked and locked
with the mechanical key (
page 614).

Opening: Press glove box lid
release1.

Closing: Push the lid up.

Locking: Insert the mechanical key
into the glove box lock and turn it
clockwise to position3.

Unlocking: Insert the mechanical key
into the glove box lock and turn it coun-
terclockwise to position2.
Storage compartments in the front arm-
rest
1Storage tray/telephone compartment
2Storage compartment (not with rear
climate control system*)
Do not pile luggage or cargo higher than the
seat backs. Do not place anything on the
rear-window shelf.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs.
Parcel nets cannot secure hard or heavy ob-
jects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during

braking


vehicle maneuvers or


an accident.


449 Controls in detail
Loading and storing

Opening storage tray/telephone
compartment: Press button1 and
swing armrest to left or right side.

Opening storage compartment:
Press button2 and swing center arm-
rest upward.
Storage compartments below the front
seats

Opening: Pull tab1 upward and fold
cover2 forward.Eyeglasses compartment

Opening: Press mark1.

Closing: Swing eyeglasses compart-
ment upward until it engages.
Parcel net in front passenger footwellA small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.Warning!
G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net. In an accident, during hard
braking, or sudden maneuvers, they could
be injury to vehicle occupants.
The parcel net cannot protect transported
goods in the event of an accident.

450 Controls in detailLoading and storingStorage compartments in rear passen-
ger compartment
Armrest with integrated storage com-
partmentVehicles without control panel* in rear arm-
rest
Opening: Pull release catch1 and
swing the cover upward.
Vehicles with control panel* in rear armrest
Opening: Press button1 and swing
the cover upward.Storage compartment between rear
seats
Vehicles without rear center seat*
Opening: Pull handle1 backward in
direction of arrow.
!
Before storing the armrest in the backrest,
close the storage compartment cover.
!
Do not sit on or lean your body weight
against the armrest when it is folded down, as
you could otherwise damage it.

451 Controls in detail
Loading and storing
Rear storage box
Opening: Fold down rear center arm-
rest and swing down cover1.Ruffled storage pockets
Ruffled storage pockets 1 are located on
the back of the front seats.
!
Do not sit on or lean your body weight
against the armrest when it is folded down, as
you could otherwise damage it.
i
When the rear seats are in their basic posi-
tion, you can open the cover more easily.
Warning!
G
Do not place objects with a combined
weight of more than 4.4 lbs (2 kg) into the
ruffled storage pocket. Otherwise, the Occu-
pant Classification System OCS (
page 50)
may not be able to properly approximate the
occupant weight category.
The ruffled storage pocket is intended for
storing light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
ruffled storage pocket. In an accident, dur-
i n g h a r d b r a k i n g , o r s u d d e n m a n e u v e r s , t h e y
could be thrown around inside the vehicle
and cause injury to vehicle occupants.
The ruffled storage pocket cannot protect
transported goods in the event of an acci-
dent.

452 Controls in detailLoading and storingCup holders
Cup holder in front center console
1Mark
2Handle

Opening: Press mark1 on the front.

Closing: Fold cover in until it engages.

Removing: Pull cup holder out by pull-
ing silver handle2 upward in direction
of arrow.

Inserting: Press downward until it en-
gages. While doing so, make sure that
the word “Front” is in the proper instal-
lation position.
Cup holder in rear
Vehicles without control panel* in rear arm-
rest1Compartment for cup holder
Opening: Press mark1 on the front.
Warning!
G
In order to help prevent spilling liquids on
vehicle occupants and/or vehicle equip-
ment, only use containers that fit into the
cup holder. Use lids on open containers and
do not fill containers to a height where the
contents, especially hot liquids, could spill
during braking, vehicle maneuvers, or in an
accident. Liquids spilled on vehicle occu-
pants may cause serious personal injury.
Liquids spilled on vehicle equipment may
cause damage not covered by the
Mercedes-Benz Limited Warranty.
When not in use, keep the cup holders
closed. An open cup holder may cause injury
to you or others when contacted during
braking, vehicle maneuvers, or in an acci-
dent.
Keep in mind that objects placed in the cup
holder may come loose during braking, vehi-
cle maneuvers, or in an accident and be
thrown around in the vehicle interior.
Objects thrown around in the vehicle interi-
or may cause an accident and/or serious
personal injury.
i
You can remove the cup holder to clean it.
Only clean it using clear, lukewarm water.

453 Controls in detail
Loading and storing
Vehicles with control panel* in rear armrest1Compartment for cup holder
Opening: Press front of cup holder1.
Trunk
Storage spaces under trunk floor
You can fold back the front and rear parts
of the trunk floor.1Trunk floor
2Storage spaces
1Storage space
2Trunk floorCargo tie-down hooks
4 hooks are located in the trunk.

Carefully secure cargo by applying
even load on all hooks with rope of suf-
ficient strength to hold down the cargo.

454 Controls in detailLoading and storingRetaining hooks
Two hooks are located on the upper edge
of the trunk and can be used to attach car-
go items such as bags.
Pull tab1 of retaining hook2 down.
Parcel net in trunk
There is a pocket net on each side of the
right and left trunk side walls to secure
loads.Retainer for Operator’s Manual pouch
Use Velcro strap1 to fasten Operator’s
Manual pouch2 in place.
Umbrella holder
You can attach an umbrella to the trunk lid.1Umbrella holder
2Umbrella

Swing down holder1 in direction of
arrow.

Take umbrella2 out of holder 1.
!
Do not use the retaining hooks to tie down
cargo.
Warning!
G
Do not pull on the umbrella holder when you
are closing the trunk lid. You could other-
wise injure yourself on the trunk lid.i
You can purchase a suitable umbrella at any
authorized Mercedes-Benz Center.

455 Controls in detail
Useful features
Useful features
Sun visors
1Sun visor
2Vanity mirror cover
3Vanity mirror lamp
4Document holderGlare from front

Swing sun visor1 down.
Glare from front and sides

Disengage sun visor1 from the
mounting.

Pivot sun visor1 to the side.
Vanity mirror in sun visor

To use vanity mirror, lift up cover2.
Vanity mirror lamp3 comes on.
Document holder
You can use the plastic tab of document
holder4 to hold admission tickets, park-
ing passes, or similar items in place.
Vanity mirror in rear
Opening: Press mark1.
The vanity mirror swings down in the di-
rection of the arrow.

Closing: Swing vanity mirror up until it
engages.
Warning!
G
Do not use the vanity mirror while driving.
Keep the vanity mirrors in the sun visors
closed while vehicle is in motion. Reflected
glare can endanger you and others.
!
Close vanity mirror cover2 (if open) before
you disengage sun visor1 from the mounting
and pivot it to the side.
i
If you disengage sun visor1 from the
mounting, vanity mirror lamp2 will switch off.
