2007 MERCEDES-BENZ S600 Owner's Manual

344 Controls in detailLighting
Turn the exterior lamp switch to *.
With the SmartKey in starter switch po-
sition 1 or the KEYLESS-GO*
start/stop button pressed once, only
the parking lamps will switch on and off
automatically.
When the engine is running, the low
beam headlamps, the tail and parking
lamps, the license plate lamps, and the
side marker lamps will switch on and
off automatically.Daytime running lamp mode

Turn exterior lamp switch to
positionM or*.
When the engine is running, the low
beam headlamps are switched on. In
low ambient light conditions, the fol-
lowing lamps will switch on additional-
ly:

tail and parking lamps


license plate lamps


side marker lamps
For nighttime driving you should turn the
exterior lamp switch to positionB to
permit activation of the high beam head-
lamps.
Canada only
The daytime running lamp mode is manda-
tory and therefore in a constant mode.
When the engine is running, and you shift
from a driving position to positionN orP,
the low beam headlamps will switch off
with a 3-minute delay.When the engine is running, and you


turn the exterior lamp switch to
positionC, the parking lamps
switch on additionally.


turn the exterior lamp switch to
positionB, the manual headlamp
mode has priority over the daytime run-
ning lamp mode.
The corresponding exterior lamps
switch on (
page 622).
USA only
By default, the daytime running lamp mode
is deactivated. Activate the daytime run-
ning lamp mode using the control system,
see “Daytime driving lamps mode on/off
(USA only)” (
page 255).
When the engine is running, and you turn
the exterior lamp switch to position C
orB, the manual headlamp mode has
priority over the daytime running lamp
mode.
The corresponding exterior lamps switch
on (
page 622).
i
The front fog lamps and rear fog lamp can-
not be switched on manually with exterior lamp
switch in position*. To activate the fog
lamps, turn exterior lamp switch to
positionB and pull the exterior lamp switch
to first or second stop (
page 345).

345 Controls in detail
Lighting
Fog lampsFront fog lamps

Switch on the low beam headlamps
(page 343).

Pull out exterior lamp switch to first
stop.
The front fog lamps are switched on.
The green indicator lamp‡ in the
lamp switch comes on (
page 342).

Push in the exterior lamp switch.
The front fog lamps are switched off.
The green indicator lamp‡ in the
lamp switch goes out (
page 342).
Rear fog lamp (driver’s side only)

Switch on the front fog lamps
(page 345).

Pull out exterior lamp switch to second
stop.
The rear fog lamp is switched on.
The yellow indicator lamp† in the
lamp switch comes on (
page 342).

Push in the exterior lamp switch to first
stop.
The rear fog lamp is switched off.
The green indicator lamp‡ in the
lamp switch goes out (
page 342).
The front fog lamps remain lit.
Warning!
G
In low ambient lighting or foggy conditions,
only switch from position * to B with
the vehicle at a standstill in a safe location.
Switching from * to B will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.i
Fog lamps will operate with the parking
lamps and/or the low beam headlamps on. Fog
lamps should only be used in conjunction with
low beam headlamps. Consult your State or
Province Motor Vehicle Regulations regarding
permissible lamp operation.
i
Fog lamps cannot be switched on with exte-
rior lamp switch in position *. For switching
on the fog lamps, turn exterior lamp switch to po-
sition B.
i
If so equipped, the front fog lamps will also
switch on.

346 Controls in detailLightingLocator lighting and night security illu-
mination
Locator lighting and night security illumi-
nation are described in the COMAND vehi-
cle section under “Setting locator lighting”
(page 221) and “Setting night security il-
lumination” (
page 220).
Headlamp cleaning system
1Headlamp washer button

Switch on the ignition (
page 315).

Press button1.
The headlamps are cleaned with a
high-pressure water jet.For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system”
(
page 498).
Combination switch
1High beam
2High beam flasher
Switching on high beams
Turn exterior lamp switch to
positionB or to*
(page 342).

Push the combination switch in the
direction1.
The high beam indicatorA on the
instrument cluster comes on.
i
The headlamps are automatically cleaned if,
at the same time,


the engine is running


the lights are switched on


the windshield wipers have wiped the wind-
shield with washer fluid 15 times
When you switch off the ignition or press
button1, the automatic function is reset and
will start counting the next time from the begin-
ning.

347 Controls in detail
Lighting
High beam flasher
Pull the combination switch briefly in
the direction2.
Corner-illuminating lamps
The corner-illuminating lamps improve illu-
mination of the area in the direction into
which you are turning.
Corner-illuminating lamps will operate
with:

the engine running


during darkness


the headlamps switched on
Switching on corner-illuminating lamps

Depending on whether you are turning
left or right, switch on the left or right
turn signal (
page 342).The respective corner-illuminating
lamp comes on and illuminates the
area in the direction into which you are
turning.Switching off the corner-illuminating
lamps
The combination switch for the turn signal
resets automatically after major steering
wheel movements. This will switch off the
corner-illuminating lamps if they were acti-
vated by switching on the left or right turn
signal.
If the turn signal should stay on after mak-
ing the turn, the turn signal and corner-illu-
minating lamp can be switched off by
returning the combination switch to its
original position.
i
The corner-illuminating lamps function is not
available at a vehicle speed above 25 mph
(40 km/h).
i
The corner-illuminating lamps will come on
automatically up to a speed of approximately
25 mph (40 km/h) depending on the steering
angle, even if you did not switch on either turn
signal. If the corner-illuminating lamps came on
automatically, they will also go out automatically
depending on the steering angle.
i
If you have switched on the turn signal for
one side but turn the steering wheel in the other
direction, the corner-illuminating lamp lights up
on the side of the turn signal.
i
The corner-illuminating lamps temporarily
light up on both sides of the vehicle if you turn
the steering wheel in one direction and then in
the other direction shortly thereafter.
i
When you shift the automatic transmission
in reverse gearR, the inverse corner-illuminating
lamp comes on automatically depending on the
steering direction and steering angle.
The turn signal has no influence on the corner-il-
luminating lamp on the outside of the curve.
i
If you are driving faster than 25 mph
(40 km/h) when activating the turn signal indica-
tor, the corner-illuminating lamp function is
switched off.
i
The corner-illuminating lamp may remain lit
for a short time. The corner-illuminating lamp
lights up for no more than 20 seconds with the
vehicle standing still. It is then switched off even
if the turn signal is still switched on or you have
turned the steering wheel to full lock.

348 Controls in detailLightingHazard warning flasher
The hazard warning flasher can be
switched on at all times, even with the
SmartKey removed from the starter switch
or with the SmartKey with KEYLESS-GO*
removed from the vehicle.
The hazard warning flasher is automatical-
ly switched on if

an air bag has been triggered


S 600 and USA only: you brake the ve-
hicle strongly at a speed of more than
50 mph (70 km/h) and bring it to a
complete stop.
1Hazard warning flasher switch

Switching on: Press hazard warning
flasher switch.
All turn signals will flash.

Switching off: Press hazard warning
flasher switch again.
Interior lighting
i
With the hazard warning flasher activated
and the combination switch set for either left or
right turn, only the respective left or right turn
signals will operate when the SmartKey in the
starter switch is in position1 or2 or the
KEYLESS-GO* start/stop button (
page 317) is
pressed once or twice.
i
If the hazard warning flasher was activated
automatically, also press hazard warning flasher
switch 1 to switch off the hazard warning flash-
er.
i
When you lock the vehicle from the outside,
the interior lighting is switched off. As soon as
one of the interior lighting buttons inside the ve-
hicle is pressed, however, the selected lamp
comes on and all of the lamps inside the vehicle
that are not switched on via a button are activat-
ed.
If you do not lock the vehicle, all lamps will be
switched off after 30 minutes. When you open
the door, you can still use the lighting for the
storage compartment, glove box and vanity mir-
ror without in the starter switch in position1 or2
or the KEYLESS-GO* start/stop button
(
page 317) pressed once or twice.

349 Controls in detail
Lighting
Interior lighting in the front
The controls are located in the overhead
control panel.
1Left reading lamp on/off
2Rear interior lamps on/off
3Front interior lighting on/off
4Interior lighting control
5Right reading lamp on/offAutomatic control

Deactivating: Press button4.
The OFF indicator lamp next to the but-
ton comes on.
The interior lighting remains switched
off in darkness, even when you:

unlock the vehicle


remove the SmartKey from the
starter switch


open a door


open the trunk

Activating: Press button4.
The interior lighting switches on in
darkness when you:

unlock the vehicle


remove the SmartKey from the
starter switch


open a door


open the trunkThe interior lighting switches off auto-
matically following an adjustable time
delay (
page 226).
Manual control

Switching on/off front interior light-
ing: Press button 3.

Switching on/off rear interior light-
ing: Press button 2.

Switching on/off front reading
lamps: Press button 1 or 5.
The reading lamps are integrated into
the interior rear view mirror.

Ambient lighting: the brightness of
the ambient lighting is adjusted via
COMAND (
page 79).
!
Leaving an interior light switch in the ON po-
sition for extended periods of time with the en-
gine turned off could result in a discharged
battery.
i
If the door remains open, the interior lighting
switches off automatically after approximately
5minutes.
An interior lamp switched on manually does not
go out automatically.

350 Controls in detailLightingInterior lighting in the rear
1Rear interior lamp
2Button
3Reading lamp
Press button2.
You can switch the lamps on/off in
succession as follows:

reading lamp3 and rear interior
lamp1 on


only reading lamp3 on


reading lamp3 off
Courtesy lighting
For better orientation in the dark, courtesy
lamps will illuminate the interior of your ve-
hicle as follows:
With parking lamps switched on:

the door handles


the driver and passenger footwells
With the SmartKey in the starter switch
position1:


the door handles


the center console
Door entry lamps
For better orientation in the dark, the cor-
responding door entry lamps will switch on
in darkness when you open a door and the
automatic control is activated.The door entry lamps switch off when the
corresponding door is closed.
Trunk lamp
The trunk lamp switches on if the trunk is
opened.
If the trunk remains open, the trunk light-
ing switches off automatically after ap-
proximately 10 minutes.
i
If you turn the SmartKey in the starter
switch to position0 and switch off the exterior
headlamps, the door handle lamps will remain lit
for approximately 5 minutes.
i
If you turn the SmartKey in the starter
switch to position0 and switch off the exterior
headlamps, the door entry lamps will remain lit
for approximately 5 minutes.
i
The interior lighting is factory-set to auto-
matic mode (
page 349).
The setting selected for the interior lighting is
used for the trunk lighting as well.

351 Controls in detail
Windshield wipers
Windshield wipers
Combination switch1Switching on windshield wipers
2Single wipe
Wiping with windshield washer fluid

Switch on the ignition (
page 315).
Switching on/off windshield wipers
Turn the combination switch to the de-
sired position depending on the inten-
sity of the rain.
MWindshield wipers off
USlow intermittent wiping
(rain sensor operation low sen-
sitivity)
VFast intermittent wiping
(rain sensor operation low sen-
sitivity)
uSlow continuous wiping
tFast continuous wiping
!
If the windshield wipers leave smears on the
windshield after the car has been driven through
an automatic car wash, then wax or other resi-
due is on the windshield. Shortly after washing
the car in an automatic car wash, clean the wind-
shield with windshield washer fluid
(
page 352).
!
Do not operate the wipers when the wind-
shield is dry. Dust that accumulates on a wind-
shield might scratch the glass and/or damage
the wiper blades when wiping occurs on a dry
windshield. If it is necessary to operate the wip-
ers in dry weather conditions, always operate
the wipers with windshield washer fluid
(
page 352).
!
If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.


For safety reasons, stop the vehicle in a safe
location,

turn off the engine by turning the
SmartKey to position0 and withdraw
SmartKey from starter switch
or


turn off the engine by pressing the
KEYLESS-GO* start/stop button
(page 317) and open the driver’s door
(with the driver’s door open, starter
switch is in position0, same as with
SmartKey removed from starter switch)
before attempting to remove any blockage.


Remove blockage.


Turn the windshield wipers on again.If the windshield wipers fail to function at all in
combination switch position u,


set the combination switch to the next high-
er wiper speed


have the windshield wipers checked at the
nearest authorized Mercedes-Benz Center
