2006 LEXUS RX330 Owners Manual

EXTERIOR EQUIPMENT
124
HOOD
1. To open the hood, pull the hood lock release lever under
the driverside instrument panel. The hood will spring up
slightly.
2. Insert your fingers under the hood, push up the
auxiliary catch lever and lift the hood.
Before closing the hood, check to see that you have not
forgotten any tools, rags, etc. Then lower the hood and make
sure it locks.
CAUTION
Before driving, be sure that the hood is closed and
securely locked. Otherwise, the hood may open
unexpectedly while driving and an accident may occur.

EXTERIOR EQUIPMENT
125
FUEL TANK CAP
This indicates that the fuel filler door is on the left side of
your vehicle.
1. To open the fuel filler door, push the switch.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or allow open flames
when refuelling. The fumes are flammable.
 When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.

EXTERIOR EQUIPMENT
126
2. To remove the fuel tank cap, turn the cap
counterclockwise by 90 degrees (to the pressure point
1), and then turn it a additional 30 degrees (to point 2).
Pause slightly before removing it.
It is not unusual to hear a slight swoosh when the cap is
opened.
3. The removed cap can be stored on the back side of the
fuel filler door.
Position the cap so that the hooks point to the left and right, and
set it in the receptacle on the back side of the door.
When installing the cap, turn the cap clockwise until you
hear a click. When you hear the click, the cap is fully
closed.
If the cap is not tightened securely, the malfunction indicator
lamp comes on. Make sure the cap is tightened securely.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.

EXTERIOR EQUIPMENT
127
CAUTION
Make sure the cap is installed securely to prevent fuel
spillage in the event of an accident.
 Use only a genuine Lexus fuel tank cap for
replacement. It is designed to regulate fuel tank
pressure.
NOTICE
To prevent damage to the cap, apply force only in the
turning direction to the cap. Do not pull or pry it.
In case the opener is not actuated
Open the auxiliary box in the luggage compartment, pull
the manual lever.
This is used in case the fuel filler door cannot be opened due
to a discharged battery or other trouble.

EXTERIOR EQUIPMENT
128
MOON ROOF (normal type)
1Open2Close
To slide open the moon roof, push the slide control switch
toward the back. The moon roof will open and stop
partway 45 mm (1.8 in.) from the fully opened position.
When you push the switch once again, the moon roof will
fully open. To stop partway , push either side of the slide
control switch.
As driving with the moon roof opened fully will cause wind
throbs, we recommend you to drive with the moon roof partway
45 mm (1.8 in.) from the fully opened position. The sunshade can be opened or closed manually. However,
if you open the moon roof, the sunshade will be opened with
the moon roof.
To close the moon roof, push the slide control switch
toward the front. The moon roof will fully close. To stop
partway, push the either side of the slide control switch.

EXTERIOR EQUIPMENT
129
1Tilt up2Tilt down
To tilt up the moon roof, push the “TILT” switch on the rear
side. The moon roof will fully tilt up. To stop partway, push
either side of the “TILT” switch.
To tilt down the moon roof, push the “TILT” switch on the
front side. The moon roof will fully tilt down. To stop
partway, push either side of the “TILT” switch. To operate the moon roof, the
ignition key must be in the “ON”
position.
If the moon roof is left open when you turn the ignition key to
the “ACC” or “LOCK” position and open the driver’s door, a
buzzer will remind you to close the moon roof.
Retained accessory power operation: Even if the ignition
key is turned to the “ACC” or “LOCK” position, the moon roof
can be operated until either front door is opened (or for 43
seconds).

EXTERIOR EQUIPMENT
130
Operating the moon roof from outside the
vehicle
The moon roof can be operated using an ignition key.*NOTE:
* This feature can be deactivated.
Ask your Lexus dealer for details.
 Close Open
Insert the ignition key into the key hole on the driver’s
door. To close the moon roof: Turn the key in the locking direction
and hold it.
After the doors are locked, the moon roof begins to close. To
stop in the middle, return the key.
To open the moon roof: Turn the key in the unlocking
direction and hold it.
After the door is unlocked, the moon roof begins to open. To
stop in the middle, return the key.
The moon roof also can be opened using the wireless remote
control. For details, see page 22.
Jam protection function

If something gets caught between the moon roof and frame
during slide closing operation, the moon roof stops and
opens half way.
 If something gets caught between the moon roof and frame
during tilting down operation, the moon roof stops and
opens fully.
If the moon roof receives a strong impact, this function may
work even if nothing is caught.

EXTERIOR EQUIPMENT
131
If the moon roof does not operate
automatically
If the moon roof does not operate automatically or jam
protection function does not operate correctly, you should
normalize the moon roof.
To normalize the moon roof, push and hold the slide control
switch toward the front or “TILT” switch on the rear side. The
moon roof will tilt up and down, then slide open and close. After
the slide close operation, release the switch.
Make sure that the moon roof opens and closes automatically.
If the moon roof cannot be operated properly, have it checked
by your Lexus dealer.
CAUTION
To avoid serious personal injury, you must do the
following.
 While the vehicle is moving, always keep the heads,
hands and other parts of the bodies of all occupants
away from the roof opening. Otherwise, they could
be seriously injured if the vehicle stops suddenly or
if the vehicle is involved in an accident.
 Before you close the moon roof, always make sure
there is nobody around the moon roof. You must also
make sure nobody places his or her head, hands and
other parts of the body in the roof opening. If
someone’s neck, head or hands get caught in the
closing roof, it could result in death or serious injury.
When anyone closes the moon roof, first make sure
it is safe to do so.
 Be sure to remove the ignition key when you leave
your vehicle.
 Never leave anyone (particularly a small child) alone
in your vehicle, especially with the ignition key still
inserted. Otherwise, he/she could use the moon roof
switches and get trapped in the roof opening.
Unattended person (particularly a small child) can be
involved in a serious accident.
 Never sit on top of the vehicle around the roof
opening.
 Never try jamming any part of your body to activate
the jam protection function intentionally, as it could
result in a serious injury.
 The jam protection function may not work if
something gets caught just before the moon roof is
fully closed.
