OCCUPANT RESTRAINT SYSTEMS
220
5. Replace the head restraint and lift it up to the
uppermost lock position.
Be sure to close the cover when the anchor bracket is not in
use.
Installation with child restraint lower
anchorages
Lower anchorages for the child restraint systems
complying with the FMVSS225 or CMVSS210.2
specifications are installed in the rear seat.
The anchorages are installed in the seat cushion of the right
side seating position and between the center and left side
seating position.

OCCUPANT RESTRAINT SYSTEMS
221
Child restraint system complying with the FMVSS213 or
CMVSS213
specification can be fixed to these anchorages. In
this case, it is not necessary to fix the child restraint system with
a seat belt on the vehicle. CHILD RESTRAINT SYSTEM INSTALLATION
11st lock position
23rd lock position
1. Fold the seatback forward and then back to the 1st lock
position (most upright position) until it locks into place.
Adjust the seatback to the 3rd lock position.
Make sure the seatback is locked securely.

OCCUPANT RESTRAINT SYSTEMS
222
Canada only
Type A
Canada only
Type B

OCCUPANT RESTRAINT SYSTEMS
223
2. Widen the gap between the seat cushion and seatback
slightly and confirm the position of the lower anchorages
near the button on the seatback.
3. Type A — Latch the hooks of lower straps onto the
anchorages and tighten the lower straps.
3. Type B — Latch the buckles onto the anchorages.
For owners in Canada —
The symbol on a child restraint
system indicates the presence of a lower connector system. If your child restraint system has a top strap, it should be
anchored. (For the installation of the top strap, see “Using a
top strap” on page 217.)
For installation details, refer
to the instruction manual equipped
with each product.
CAUTION
 When using the lower anchorages for the child
restraint system, be sure that there are no irregular
objects around the anchorages or that the seat belt is
not caught.
 Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its
manufacturer.
 When using the lower anchorages for a child restraint
system, ensure that the seat is moved to the
rearmost position, with the seatback close to the
child restraint system.

OCCUPANT RESTRAINT SYSTEMS
224
After securing the child restraint system, never slide
or recline the seat.
 Do not install a child restraint system on the rear seat
if it interferes with the lock mechanism of the front
seats. This can cause death or serious injury to the
child and front passenger in case of sudden braking
or a collision.DRIVING POSITION MEMORY SYSTEM
A microcomputer will memorize the position of the driver’s
seat, and the positions of the tilt and telescopic steering, and
outside rear view mirrors. Two dif ferent driving position profiles
can be entered into the computer’s memory.
Recording a driving position in the computer’s memory can
only be done when the ignition k ey is in the “ON” position and
the selector lever is in the “P” position.

OCCUPANT RESTRAINT SYSTEMS
225
Setting the driving position
1. Adjust the driver’s seat, tilt and telescopic steering and
outside rear view mirrors to the desired position.
2. While pushing the “SET” button, push button “1” or “2”
until the signal beeps.
The beep sound means that the positions are recorded in the
computer’s memory.
By repeating these two steps and pressing the remaining
button, the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.
Recalling the memorized position
When you push button “1” or “2”, the driving position will
be automatically adjusted to the position recorded for that
button.
Conditions for memorized position activation
 Ignition key “ON” and selector lever in “P” position.
All parts of the memorized positions can be activated.
 Key not in ignition switch and within 30 seconds of opening
driver’s door.
The memorized position can be activated, except for the tilt
and telescopic steering.

OCCUPANT RESTRAINT SYSTEMS
226If any driving position memory switch is pushed while one of the
memorized driving position profiles is being activated, the
operation will stop.
To activate the system, push the desired button (“1” or “2”)\
again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle’s battery is disconnected, the computer’s
memory will
be erased and the memorized positions will have
to be set again.
CAUTION
 Do not start the vehicle while the adjustments are
being made.
 Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body
against the steering wheel. If this happens, you can
stop the movement by pressing another driving
position memory switch.
