2006 LEXUS RX330 Owners Manual

CHASSIS
588
Snow tire installation
Snow tires should be installed on all wheels.
Installing snow tires on the front wheels only can lead to an
excessive difference in road grip capability between the front
and rear tires which could cause loss of vehicle control.
CAUTION
Snow tires should be inflated to the same pressure as
the original tires.
 Never drive over 120 km/h (75 mph) with any type of
snow tires.
Tire chain selection
1Side chain2Cross chain
Use the tire chains of correct size.
For 225/65R17 101S or P235/55R18 99V tires, use the
following type chains. mm (in.)
A: Diameter of side chain 3.0 (0.12)
B: Width of side chain 10.0 (0.39)
C: Length of side chain 30.0 (1.18)
D: Width of cross chain 14.0 (0.55)
E: Length of cross chain 25.0 (0.98)
F: Diameter of cross chain 4.0 (0.16)

CHASSIS
589
Regulations regarding the use of tire chains vary
according to location or type of road. Always check local
regulations before installing chains.
NOTICE
If the wrong combination of tire and chain is used, the
chains could damage the vehicle body.
Chain installation
Install the chains on the front tires as tightly as possible.
Do not use tire chains on the rear tires. Retighten chains
after driving 0.5 — 1.0 km (1/4 — 1/2 mile).
When installing chains on your tires, carefully follow the
instructions of the chain manufacturer.
CAUTION

Do not exceed 50 km/h (30 mph) or the chain
manufacturer’s recommended speed limit,
whichever is lower.
 Drive carefully avoiding bumps, holes, and sharp
turns, which may cause the vehicle to bounce.
 Avoid sharp turns or lockedwheel braking, as use of
chains may adversely affect vehicle handling.
 When driving with chains installed, be sure to drive
carefully. Slow down before entering curves to avoid
losing control of the vehicle. Otherwise an accident
may occur.
 Vehicles with electronically modulated air
suspension: When installing the tire chains, be sure
to turn off the height control and stop the engine.
Otherwise, the vehicle height may change in the
automatic leveling function, resulting in an
unexpected accident. For details, see page 446.
If the chains are installed, the tire pressure warning
system may not operate properly. See “Tire pressure
warning system” on page 462.

CHASSIS
590
REPLACING WHEELS
When to replace your wheels
If you have wheel damage such as bending, cracks or
heavy corrosion, the wheel should be replaced.
If you fail to replace a damaged wheel, the tire may slip off the
wheel or cause loss of handling control.
Replacement with used wheels is not recommended as they
may have been subjected to rough treatment or high mileage
and could fail without warning. Also, bent wheels which have
been straightened may have hidden structural damage and
therefore should not be used. Never use an inner tube in a
leaking wheel which is designed for a tubeless tire.
Wheel selection
When replacing wheels, care should be taken to ensure
that they are equivalent to those removed in load capacity,
diameter, rim width, and offset.
Correct replacement wheels are available at your Lexus
dealer.
A wheel of a different size or type may adversely affect
handling, wheel and bearing life, brake cooling,
speedometer/odometer calibration, stopping ability, headlight
aim, bumper height, vehicle ground clearance, and tire or snow
chain clearance to the body and chassis.
CAUTION
Observe the following instructions. Otherwise, an
accident may occur resulting in death or serious
injuries.
 Do not use wheels other than the manufacturer’s
recommended size, as this may cause dangerous
handling characteristics resulting in loss of control.
 Fourwheel drive models:
Do not use wheels of different brands, sizes and
types, as this may cause dangerous handling
characteristics resulting in loss of control.
Initial adjustment of the tire pressure warning system is
necessary after you have replaced your wheels. See “Tire
pressure warning system” on page 462.

CHASSIS
591
ALUMINUM WHEEL PRECAUTIONS
When installing aluminum wheels, check that the wheel nuts
are tight after driving your vehicle the first 1600 km (1000
miles).
 If you have rotated, repaired, or changed your tires, check
that the wheel nuts are still tight after driving 1600 km (1000
miles).
 When using tire chains, be careful not to damage the
aluminum wheels.
 Use only Lexus wheel nuts and wrench designed for your
aluminum wheels.
 When balancing your wheels, use only Lexus balance
weights or equivalent and a plastic or rubber hammer.
 As with any wheel, periodically check your aluminum
wheels for damage. If damaged, replace immediately.
SUSPENSION AND CHASSIS
CAUTION
Do not modify the suspension/chassis with lift kits,
spacers, springs, etc. It can cause dangerous handling
characteristics, resulting in loss of control.

CHASSIS
592

SECTION 6 – 4
593
SERVICE PROCEDURES AND
SPECIFICATIONS
Electrical components
Specifications594
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Checking battery condition 601
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery recharging precautions 604
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking and replacing the blade type fuses 605
. . . . . . . . . . . . . . . .
Checking the cartridge type fuses 607
. . . . . . . . . . . . . . . . . . . . . . . . . .
Adding washer fluid 609
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Checking the headlight aim 609
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing light bulbs 611
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

ELECTRICAL COMPONENTS
594
SPECIFICATIONS
— FUSE LOCATIONS
1Engine compartment
2 3 Driver’s side instrument panel— FUSES

Engine compartment
(with electronically modulated air suspension)

ELECTRICAL COMPONENTS
595
Engine compartment
(without electronically modulated air suspension)
64RY043
Driver’s side instrument panel
