Page 1169 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual TEMPERATURE VALVE ACTUATOR (MTC) - BLACK 6 WAY CAV CIRCUIT FUNCTION 5- - 6- - 7 Z132 20BK/OR GROUND 8 C67 20RD/LB BLEND AIR DOOR POSITION CONTROL 9- - 10 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)

Page 1170 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual TRAILER TOW CONNECTOR - BLACK 10 WAY CAV CIRCUIT FUNCTION 1- - 2 L62 14BR/RD RIGHT TURN SIGNAL 3 L1 18VT/BK BACK-UP LAMP FEED 4 F30 14RD/WT FUSED CIGAR LIGHTER RELAY OUTPUT 5 L7 18BK/YL PARK LAMP RELA

Page 1171 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual TRANSMISSION CONTROL MODULE (4.7L) - BLACK 60 WAY CAV CIRCUIT FUNCTION 1 T1 18LG/BK TRS T1 SENSE 2 T2 18TN/BK TRS T2 SENSE 3 T3 18VT TRS T3 SENSE 4- - 5- - 6 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIG

Page 1172 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual TRANSMISSION CONTROL MODULE C1 (DIESEL) - BLACK 18 WAY CAV CIRCUIT FUNCTION 1 D21 20PK SCI TRANSMIT 2- - 3 W4 20PK/OR SHIFTER C5 SENSE 4 Y1 20DB/PK PARK LOCKOUT SOLENOID CONTROL 5- - 6- - 7 T41 20BK/W

Page 1173 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual TRANSMISSION SOLENOID ASSEMBLY (DIESEL) - BLACK 13 WAY CAV CIRCUIT FUNCTION 1 T14 18LG/WT N3 INPUT SPED SENSOR 2 T591 18YL/DB MODULATION PRESSURE SOLENOID CONTROL 3 T52 18RD/BK N2 INPUT SPEED SENSOR 4

Page 1174 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual VEHICLE INFORMATION CENTER - BLACK 6 WAY CAV CIRCUIT FUNCTION 1- - 2 D25 20YL/VT PCI BUS 3 F70 20PK FUSED B(+) 4 Z155 20BK/OR GROUND 5 G5 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START) 6- - VISCOUS/

Page 1175 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual

Page 1176 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual 8W-91 CONNECTOR/GROUND/SPLICE LOCATION TABLE OF CONTENTS page CONNECTOR/GROUND/SPLICE LOCATION DESCRIPTION..........................1 CONNECTOR/GROUND/SPLICE LOCATION DESCRIPTION This section provides
