Page 1145 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual LINE PRESSURE SENSOR (4.7L) - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 Z114 14BK/LB GROUND 2 T138 14GY/LB 5 VOLT SUPPLY 3 T130 14VT/TN LINE PRESSURE SENSOR SIGNAL 4- - MANIFOLD ABSOLUTE PRESSURE SENSOR (4.0

Page 1146 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual MANUAL TEMPERATURE CONTROL C2 (MTC) - WHITE 2 WAY CAV CIRCUIT FUNCTION 1 Z118 12BK GROUND 2 C7 12BK/TN BLOWER MOTOR HIGH DRIVER MASS AIR FLOW SENSOR (DIESEL) - BLACK 5 WAY CAV CIRCUIT FUNCTION 1- - 2

Page 1147 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual OUTPUT SPEED SENSOR (4.7L) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 T14 18LG/WT OUTPUT SPEED SENSOR SIGNAL 2 T13 18DB/BK SPEED SENSOR GROUND OVERHEAD MAP/COURTESY LAMP - WHITE 3 WAY CAV CIRCUIT FUNCTION 1

Page 1148 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual OXYGEN SENSOR 2/2 DOWNSTREAM-4WAY CAV CIRCUIT FUNCTION 1 K200 18VT/OR (4.0L) OXYGEN SENSOR DOWNSTREAM RELAY OUTPUT 1 K200 18BR/WT (4.7L) OXYGEN SENSOR DOWNSTREAM RELAY OUTPUT 2 Z186 18BK GROUND 3 K4 1

Page 1149 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual PASSENGER BLEND DOOR MOTOR/ACTUATOR (RHD) (AZC) - BLACK 2 WAY CAV CIRCUIT FUNCTION A C94 20WT/DG (RHD) PASSENGER BLEND DOOR DRIVER (A) B C96 20WT/DB (RHD) PASSENGER BLEND DOOR DRIVER (B) PASSENGER CUR

Page 1150 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual PASSENGER DOOR MODULE C2 - BLACK 12 WAY CAV CIRCUIT FUNCTION 1 P95 20OR MIRROR HORIZONTAL DRIVER 2 C118 20BK/WT MIRROR HEATER GROUND 3 P64 20VT MIRROR VERTICAL POSITION SIGNAL 4 P69 20GY MIRROR SENSOR

Page 1151 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual PASSENGER HEATED SEAT CUSHION (PREMIUM I/III)-4WAY CAV CIRCUIT FUNCTION 1 P130 16DG/WT PASSENGER SEAT HEATER B(+) DRIVER 2 P88 16BK/BR HEATED SEAT DRIVER 3 P86 20DG/YL PASSENGER SEAT TEMPERATURE SENSO

Page 1152 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual PASSENGER POWER MIRROR - BLACK 12 WAY CAV CIRCUIT FUNCTION 1 C117 20BK MIRROR HEATER 12 VOLT SUPPLY 2 P65 20DG MIRROR HORIZONTAL POSITION SIGNAL 3 P69 2GY MIRROR SENSOR GROUND 4 P64 20VT MIRROR VERTIC
