JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C300 (LHD) - GRAY (RIGHT BODY SIDE) CAV CIRCUIT A P130 16DG/WT (EXCEPT BASE) B Q13 16DB C B40 12LB D F9 14RD/BK (EXCEPT BUILT-UP-EXPORT) E P144 16BK/LG (EXCEPT BASE) F A141 16DG/BK (GAS) G- H- J- K- L

Page 1090 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C300 (LHD) - GRAY (RIGHT BODY SIDE) CAV CIRCUIT 32 - 33 - 34 - 35 - 36 - 37 X75 20GY/LG (BUILT-UP-EXPORT) 38 - 39 - 40 - 41 K106 20WT/DG (EXCEPT BUILT-UP-EXPORT) 42 K107 20OR/YL (EXCEPT BUILT-UP-EXPOR

Page 1091 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C300 (LHD) - GRAY (LEFT BODY SIDE) CAV CIRCUIT A P130 16DG/WT (HEATED SEATS) B Q13 16DB C B40 14LB D F9 14RD/BK (EXCEPT BASE)) E P144 16BK/VT (HEATED SEATS) F A141 16DG/BK (EXCEPT DIESEL) G- H- J- K-

Page 1092 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C300 (LHD) - GRAY (LEFT BODY SIDE) CAV CIRCUIT 33 - 34 - 35 - 36 - 37 X75 20GY/LG (BUILT-UP-EXPORT) 38 - 39 - 40 - 41 K106 20WT/DG (EXCEPT BUILT-UP-EXPORT) 42 K107 20OR/YL (EXCEPT BUILT-UP-EXPORT) 43

Page 1093 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C301 (RHD) - BLACK (LEFT BODY SIDE) CAV CIRCUIT A Q13 16DB B Q23 16RD/WT C F9 14RD/BK D F60 16RD/WT E Z9 16BK F Z5 16BK/VT G C15 12BK/WT H A148 16LG/RD J- K- L Q30 16TN M P130 16DG/WT 1 L50 18W/TTN 2

Page 1094 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C301 (RHD) - BLACK (LEFT BODY SIDE) CAV CIRCUIT 33 - 34 G78 20TN/BK 35 - 36 - 37 E21 20OR/RD 38 G77 20TN/OR 39 G76 20TN/YL 40 L1 18VT/BK 41 G5 20DB/WT 42 P86 20PK/BK 43 P29 20BR/WT 44 G73 20LG/OR 45 C

Page 1095 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C301 (RHD) - BLACK (RIGHT BODY SIDE) CAV CIRCUIT A Q13 16DB B Q23 16RD/WT C F9 14RD/BK D F60 16RD/WT E Z9 16BK F Z5 16BK/VT G C15 12BK/WT H A148 16LG/RD J- K- L Q30 16TN M P130 16DG/WT 1 L50 18WT/TN 2

Page 1096 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C301 (RHD) - BLACK (RIGHT BODY SIDE) CAV CIRCUIT 44 G73 20LG/OR 45 C235 20WT/LB (CD) 46 X160 20YL (CD) 47 X40 20WT/RD (CD) 48 - 49 X112 20RD (CD) 50 X41 20WT/DG (CD) 51 Z4 20WT/BK (CD) 52 Z17 20BK (CD
