Page 1097 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C302 - BLACK (FRONT DRIVER DOOR SIDE) CAV CIRCUIT 1 P112 20YL/WT 2 P114 20YL/RD 3 D25 20YL/VT 4 Z1 12BK 5 E21 20OR/RD 6 Q13 16DB 7 Q23 16RD/WT 8 A146 12OR/WT 9 X85 18LG/DG (LHD PREMIUM) 9 X80 18LG/DG

Page 1098 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C303 - WHITE (REAR DOOR SIDE) CAV CIRCUIT 1 X58 18TN/DG (BASE) 1 X55 1 X92 18TN/DG (PREMIUM) 2 X52 18WT/VT (BASE) 2 X90 18WT/VT (PREMIUM) 3 E21 20OR/RD 4 P35 18OR/VT 5 P36 18PK/VT 6- 7- 8 Q14 16GY 9 Q

Page 1099 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C306 - BLACK (BODY SIDE) CAV CIRCUIT 1 P130 16DG/WT 2 Z238 16BK 3 F37 16RD/LB 4 P86 20PK/BK 5 P29 20BR/WT 6 P144 16BK/LG C306 - BLACK (POWER SEAT SIDE) CAV CIRCUIT 1 P130 16DG/WT (HEATED SEATS) 2 Z1 1

Page 1100 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C308 - WHITE (LEFT BODY SIDE) CAV CIRCUIT 1 G78 20TN/BK 2 P35 18PK/VT (RHD) 2 P35 18OR/VT (LHD) 3 P36 18OR/VT (RHD) 3 P36 18PK/VT (LHD) 4 V13 18BR/LG 5 V22 18BR/YL 6 F70 18PK 7 L50 18WT/TN 8 Z309 12BK

Page 1101 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C309 - WHITE (LEFT BODY SIDE) CAV CIRCUIT 1 D25 20YL/VT 2 M20 18YL/BK (RHD) 2 M20 20YL/BK (LHD) 3 M2 18YL (RHD) 3 M2 20YL/DG (LHD) 4 P112 20YL/WT 5 P114 20YL/RD 6 L1 20VT/BK 7 G5 20DB/WT 8 X75 20GY/LG

Page 1102 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C310 (EXCEPT BUILT-UP-EXPORT) - LT. GREEN (TRAILER TOW SIDE) CAV CIRCUIT 1 F9 14RD/BK 2 L62 20BR/RD 3 L1 18VT/BK 4 F30 14RD/TN 5 L7 18BK/YL 6 Z150 14RD/BK 7 B40 14LB 8 Z150 14BK 9 L50 18WT/TN 10 L63 2

Page 1103 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C312 - WHITE (LICENSE PLATE LAMP SIDE) CAV CIRCUIT 1 Z1 18BK 2 L7 18BK/YL 3 P101 18OR/PK 4 F70 18PK C313 - WHITE (FRONT DRIVER DOOR SIDE) CAV CIRCUIT 1 P112 20YL/WT 2 P114 20YL/RD C313 - WHITE (MUX JU

Page 1104 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C314 - LT. GRAY (FRONT PASSENGER DOOR SIDE) CAV CIRCUIT 1 D25 20YL/VT 2 A146 12OR/WT 3 P35 18OR/VT 4 P36 18PK/VT 5 Z1 12BK 6 Q14 16GY 7 Q24 16DG 8 E20 20OR/DB 9 X80 18LB/BK (LHD PREMIUM) 9 X85 18LB/BK
