Page 1161 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual RIGHT FRONT DOOR SPEAKER - WHITE 3 WAY CAV CIRCUIT FUNCTION 1 X56 18LB/BK (BASE) RIGHT FRONT DOOR SPEAKER (-) 1 X80 18LG/DG (RHD PREMIUM) RIGHT FRONT DOOR SPEAKER (-) 1 X80 18LB/BK (LHD PREMIUM) RIGHT

Page 1162 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual RIGHT FRONT SIDE MARKER LAMP (EXCEPT BUILT-UP-EXPORT) - WHITE 2 WAY CAV CIRCUIT FUNCTION 1 L7 20BK/PK PARK LAMP RELAY OUTPUT 2 L60 20TN RIGHT TURN SIGNAL RIGHT FRONT TURN SIGNAL LAMP (BUILT-UP-EXPORT)

Page 1163 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual RIGHT HIGH BEAM HEADLAMP - BLACK 2 WAY CAV CIRCUIT FUNCTION A Z1 18BK GROUND B L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT RIGHT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY CAV CIRCUIT FUNCTION 1 X86 18OR/RD

Page 1164 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual RIGHT REAR DOOR LOCK MOTOR/AJAR SWITCH - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 G76 18TN/YL RIGHT REAR DOOR AJAR SWITCH SENSE 2 Z1 18BK GROUND 3 P36 18PK/VT DOOR UNLOCK DRIVER 4 P35 18OR/VT DOOR LOCK DRIV

Page 1165 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual RIGHT SIDE REPEATER LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 L60 18TN RIGHT TURN SIGNAL 2 Z142 18BK GROUND RIGHT VISOR/VANITY LAMP - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 F70 20PK FUSE

Page 1166 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual SEAT MODULE C2 (PREMIUM) - ORANGE 20 WAY CAV CIRCUIT FUNCTION 1 F35 16RD FUSED B(+) 2 P131 16BK/OR (PREMIUM I/III) DRIVER SEAT HEATER B(+) DRIVER 3 Z1 16BK GROUND 4 P119 16YL/RD (PREMIUM II/III) SEAT

Page 1167 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual SHIFTER ASSEMBLY (GAS) - WHITE 6 WAY CAV CIRCUIT FUNCTION 1 E2 20OR PANEL LAMPS DRIVER 2 Z234 18BK GROUND 3 T6 18OR/WT OVERDRIVE OFF SWITCH SENSE 4 Z300 18BK GROUND 5 F12 20DB/WT FUSED IGNITION SWITCH

Page 1168 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual SPEED CONTROL SWITCH NO. 2 - BLACK 4 WAY CAV CIRCUIT FUNCTION 1- - 2 K4 20BK/LB SENSOR GROUND 3 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL 4- - SUNROOF CONTROL MODULE-8WAY CAV CIRCUIT FUNCTION A Q46 20OR
