JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C109 - BLACK (TRANSFER CASE JUMPER SIDE) CAV CIRCUIT 1 K77 18LG/BK 2 K4 18BK/LB C110 (DIESEL) - GRAY (LEFT HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 K154 10GY 2 K254 10GY/YL C110 (DIESEL) - GRAY (GLOW PLU

Page 1082 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C112 - BLACK (RIGHT HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 L34 18RD/OR 2 L44 18VT/RD 3 L60 20TN 4 L7 20BK/YL 5 L13 18BR/YL (BUILT-UP-EXPORT) 6 Z142 18BK C112 - BLACK (RIGHT FRONT LIGHTING MODULE SIDE)

Page 1083 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C200 - GRAY/LHD BLACK/RHD (LEFT BODY SIDE) CAV CIRCUIT A- B- C A1 12RD D- E- F- G A2 12PK/BK H C1 12DG J- K- M- L- 1 X56 18DB/PK (BASE) 1 X84 18OR/GY (EXCEPT BASE) 2 X86 18OR/RD (EXCEPT BASE) 2 X54 18

Page 1084 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C200 - GRAY/LHD BLACK/RHD (LEFT BODY SIDE) CAV CIRCUIT 35 X51 18WT/DG 36 X57 18DG/WT 37 L7 18BK/YL (BUILT-UP-EXPORT) 38 L13 18BR/YL (BUILT-UP-EXPORT) 39 V10 22BR (LHD) 39 V10 20BR (RHD) 40 X52 18DB/WT

Page 1085 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C200 - GRAY/LHD BLACK/RHD (INSTRUMENT PANEL SIDE) CAV CIRCUIT A- B- C A1 12RD D- E- F- G A2 12PK/BK H C1 12DG J- K- L- M- 1 X84 18OR/BK 2 X86 18OR/RD 3 X81 18YL/BK 4 X83 18YL/RD 5 X53 18DG/OR 6 X55 18

Page 1086 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C200 - GRAY/LHD BLACK/RHD (INSTRUMENT PANEL SIDE) CAV CIRCUIT 41 X58 18DB/OR 42 - 43 V13 18BR/LG 44 V14 20RD/VT 45 - 46 V20 18BK/WT 47 V22 18BR/YL 48 R46 20BR/LB 49 X64 18BR/WT 50 Z305 20BK/OR 51 Z306

Page 1087 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C202 (AZC) - WHITE (INSTRUMENT PANEL SIDE) CAV CIRCUIT 1 C100 20YL/DB (RHD) 1 C32 20GY/DB (LHD) 2 C100 20YL/DB (LHD) 2 C32 20GY/DB (RHD) 3 C96 20WT/DB (RHD) 3 C33 20DB/RD (LHD) 4 C94 20WT/DG (RHD) 4 C

Page 1088 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C202 (MTC) - WHITE (INSTRUMENT PANEL SIDE) CAV CIRCUIT 1- 2 C201 20LB/YL 3 G32 20BK/LB 4- 5 C67 20RD/LB 6- 7- 8- 9- 10 C6 14LB 11 Z132 20BK/OR 12 F22 20WT/PK 13 C7 12BK/TN 14 C1 12DG 15 C4 16TN 16 C5
