JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C107 (DIESEL) - GRAY (BODY SIDE) CAV CIRCUIT A B10 14BR/WT B A148 16LG/RD C C1 12DG D A149 12RD/TN E- F A1 12RD G A145 10WT/RD H A146 10OR/WT J A147 10RD/GY K A148 10PK/WT L A2 12PK/BK M B29 14DG/OR 1

Page 1074 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C107 (DIESEL) - GRAY (BODY SIDE) CAV CIRCUIT 30 B1 18YL/DB 31 - 32 M1 20PK/RD 33 F20 18DB/PK 34 L50 18WT/TN (RHD) 34 L50 18VT/TN (LHD) 35 R47 20DB/LB 36 T2 18TN/BK 37 Z305 20BK/OR 38 Z306 20BK/LG 39 R

Page 1075 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C107 (DIESEL) - GRAY (LEFT HEADLAMP AND DASH SIDE) CAV CIRCUIT A- B A148 16LG/RD C C1 12DG D A149 12RD/TN E- F A1 12RD G A145 10WT/RD H A146 10OR/WT J A147 10RD/GY K A148 10PK/WT L A2 12PK/BK M- 1 X2

Page 1076 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C107 (DIESEL) - GRAY (LEFT HEADLAMP AND DASH SIDE) CAV CIRCUIT 33 F20 18DB/PK 34 L50 18WT/TN 35 R47 18DB/LB 36 T2 18TN/BK 37 Z305 20BK/OR 38 Z306 20BK/LG 39 R49 18LB 40 K29 18WT/PK 41 C18 18DB (RHD) 4

Page 1077 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C107 (GAS) - GRAY/RHD BLACK/LHD (BODY SIDE) CAV CIRCUIT A- B- C- D- E A10 12RD/DG (LHD) E A10 10RD/DG (RHD) F- G- H- J- K- L- M A20 14RD/DB 1 V37 20RD/LG (RHD) 2 V11 20BK/TN 3 V3 16BR/WT (GAS) 4 V4 16

Page 1078 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C107 (GAS) - GRAY/RHD BLACK/LHD (BODY SIDE) CAV CIRCUIT 39 K31 18BR (RHD) 39 R49 20DB (LHD) 40 K29 18WT/PK (RHD) 41 K125 18WT/DB (RHD) 42 V32 22OR/DG (RHD) 43 R47 20DB/LB (RHD) 44 V35 20LG/RD (RHD) 45

Page 1079 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C107 (GAS) - GRAY/RHD BLACK/LHD (LEFT HEADLAMP AND DASH SIDE) CAV CIRCUIT A- B- C- D- E A10 12RD/DG F- G- H- J- K- L- M A20 12RD/DB 1 V37 18RD/LG (RHD) 2 V11 20BK/TN 3 V3 16BR/WT 4 V4 16RD/YL 5 V55 16

Page 1080 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C107 (GAS) - GRAY/RHD BLACK/LHD (LEFT HEADLAMP AND DASH SIDE) CAV CIRCUIT 39 K31 18BR (RHD) 40 K29 18WT/PK (RHD) 41 K125 18WT/DB (RHD) 42 V32 18OR/DG (RHD) 43 R47 18DB/LB (RHD) 44 V35 18LG/RD (RHD) 45
