Page 1057 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual AUTOMATIC ZONE CONTROL MODULE C2 (AZC) - WHITE 12 WAY CAV CIRCUIT FUNCTION 1- - 2 C94 20WT/DG PASSENGER BLEND DOOR DRIVER (A) 3 C95 20WT/BK DRIVER BLEND DOOR DRIVER (B) 4 C96 20WT/DB PASSENGER BLEND D

Page 1058 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual BODY CONTROL MODULE C1 - GRAY 26 WAY CAV CIRCUIT FUNCTION 1 Z132 20BK/OR GROUND 2 G52 20YL HEADLAMP SWITCH MUX 3 E19 20RD PANEL LAMPS DIMMER SIGNAL 4- - 5 G70 20BR/TN (BUILT-UP-EXPORT LHD RHD)HOOD AJA

Page 1059 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual BOOST PRESSURE SENSOR (DIESEL) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K4 20BK/LB SENSOR GROUND 2 Y53 20BK/YL BOOST PRESSURE SENSOR SIGNAL 3 K6 20VT/WT SENSOR REFERENCE VOLTAGE B BRAKE LAMP SWITCH - GRAY

Page 1060 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C101 (4.0L RHD) - LT. GRAY (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 B22 18DG/YL 2 K99 18LB/OR 3 K299 18BR/WT 4 K6 18VT/BK 5 C18 18DB 6- C101 (4.7L RHD) - BLACK (ENGINE SIDE) CAV CIRCUIT 1 K4 18BK/LB (HI

Page 1061 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C102 (DIESEL) - BLACK (LEFT HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 D21 18PK 2 D25 18VT/YL 3 K226 18DB/WT 4 D52 18LG/VT 5 D51 18DG/WT 6 B22 18DG/YL 7 F991 20OR/DB 8 T752 18DG/OR 9 K236 18GY/PK 10 K132 1

Page 1062 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C102 (GAS RHD) - BLACK (ENGINE SIDE) CAV CIRCUIT 1 A30 14RD/WT (4.7L) 2 F991 18OR/DB 3 K173 18LG 4 F42 18DG/LG 5 A7 14RD/BK 6 L1 18VT/BK 7 Z306 20BK/LG 8 T41 18BK/WT 9- 10 K4 18BK/LB 11 K200 18VT/OR (

Page 1063 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C103 (GAS) - GRAY (RIGHT HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 F22 20WT/PK (EXCEPT 4.7L RHD) 1 F22 18WT/TN (4.7L RHD) 2 T6 18OR/WT (4.7L LHD) 2 C18 20DB (4.0L LHD BUILT-UP-EXPORT) 2 C18 18DB (4.0L EXC

Page 1064 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C104 - LT. GRAY (RIGHT HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 K200 18VT/OR (4.0L EXCEPT BUILT-UP-EXPORT) 1 K4 18BK/LB (4.7L HIGH OUTPUT) 2 K99 18BR/OR (4.7L) 2 F991 20OR/DB (4.0L) 3 K173 18LG (4.0L) 4
