Page 1105 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C316 (EXCEPT BUILT-UP-EXPORT) - (PEDAL SIDE) CAV CIRCUIT 1 Y153 16DB/RD 2 L1 18WT/BR 3 F72 16RD/YL 4 D25 20VT/YL 5 Y151 20LG/BR 6 Z155 20BK/OR 7 Y152 20LG/OR 8 Z151 16BK C316 (EXCEPT BUILT-UP-EXPORT)

Page 1106 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual C318 - (OVERLAY SIDE) CAV CIRCUIT 1 R72 20LB/WT (RHD) 1 R73 20LB/BR (LHD) 2 R74 20LB/YL (RHD) 2 R75 20LB/OR (LHD) C319 - (RIGHT BODY SIDE (LHD)/ LEFT BODY SIDE (RHD)) CAV CIRCUIT 1 R72 20LB/WT (LHD) 2

Page 1107 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual CAPACITOR NO. 1 (4.7L) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT 2- - CAPACITOR NO. 2 (4.7L) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 A142 14DG/OR AUTO SHUT DOWN RELAY

Page 1108 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual CLOCKSPRING C1 - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 X3 20GY/OR HORN RELAY CONTROL 2 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL 3 K4 20BK/LB SENSOR GROUND 4- - CLOCKSPRING C2-4WAY CAV CIRCUIT FUNCTION 1 R

Page 1109 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual COIL ON PLUG NO. 2 (4.7L) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K92 14TN/PK COIL DRIVER NO. 2 2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT 3- - COIL ON PLUG NO. 3 (4.7L) - BLACK 3 WAY CAV CIRCUIT FUNCTIO

Page 1110 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual COIL ON PLUG NO. 7 (4.7L) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K97 14BR COIL DRIVER NO. 7 2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT 3- - COIL ON PLUG NO. 8 (4.7L) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1

Page 1111 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual CONTROLLER ANTILOCK BRAKE - BLACK 24 WAY CAV CIRCUIT FUNCTION 1 Z101 12BK/OR GROUND 2 B1 18YL/DB RIGHT REAR WHEEL SPEED SENSOR SIGNAL 3 B2 18YL RIGHT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 4- - 5 D25

Page 1112 of 2199

JEEP GRAND CHEROKEE 2003 WJ / 2.G Workshop Manual CRANKSHAFT POSITION SENSOR (DIESEL) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 K924 20YL CRANKSHAFT POSITION SENSOR SIGNAL 2 2 K3 20BK CRANKSHAFT POSITION SENSOR SIGNAL 1 CRANKSHAFT POSITION SENSOR (GAS) -
