Page 1529 of 2177

CHRYSLER CARAVAN 2003 Service Manual (7) Remove center console support bracket (Fig. 164). (8) Remove selector cable retainer clip (Fig. 165).(9) Remove selector cable from gearshift mecha- nism (Fig. 166). (10)2.4L Gas models goto Step

Page 1530 of 2177

CHRYSLER CARAVAN 2003 Service Manual (11) Remove battery hold down nut, clamp, and battery (Fig. 168). (12) Remove battery tray (Fig. 169). Disconnect battery temperature sensor.(13) Remove coolant recovery bottle from bracket. (14) Remo

Page 1531 of 2177

CHRYSLER CARAVAN 2003 Service Manual (17) Raise vehicle on hoist. (18) Remove selector cable from engine compart- ment, then remove cable from passenger compart- ment through opening in floor pan. INSTALLATION (1) From underneath vehicle

Page 1532 of 2177

CHRYSLER CARAVAN 2003 Service Manual (8) Install battery, hold-down clamp, and nut (Fig. 175). (9) Install battery thermal shield (Fig. 176).(10) Install selector cable to gearshift mechanism (Fig. 177). Install retainer clip (Fig. 178).

Page 1533 of 2177

CHRYSLER CARAVAN 2003 Service Manual (11) Install center console support bracket (Fig. 179). Torque support bracket-to-gearshift mechanism screws to 12 N´m (108 in. lbs.). (12) Install center console assembly (Fig. 180). Install and tor

Page 1534 of 2177

CHRYSLER CARAVAN 2003 Service Manual (15) Install gearshift knob to gearshift lever (Fig. 183). Orient shift pattern1¤4-turn clockwise, push down and rotate1¤4-turn counter-clockwise and release. Secure boot to knob. (16) Connect batte

Page 1535 of 2177

CHRYSLER CARAVAN 2003 Service Manual (3) Remove gearshift boot from center console by disengaging at three (3) retaining clips (Fig. 186). (4) Apply park brake to allow park brake handle to clear center console upon removal. (5) Remove t

Page 1536 of 2177

CHRYSLER CARAVAN 2003 Service Manual (8) Remove crossover cable retainer clip (Fig. 190). (9) Remove crossover cable from gearshift mecha- nism (Fig. 191). (10) Remove selector cable retainer clip (Fig. 192). (11) Remove selector cable f
