Page 1097 of 2177

CHRYSLER CARAVAN 2003 Service Manual REAR BLOWER MOTOR POWER MODULE C2 (3 ZONE ATC) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 12BK GROUND 2 12DG POWER FEED REAR BLOWER REAR CONTROL SWITCH C1 (3 ZONE MTC) - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 C

Page 1098 of 2177

CHRYSLER CARAVAN 2003 Service Manual REAR INTRUSION SENSOR (UNITED KINGDOM)-3WAY CAV CIRCUIT FUNCTION 1 B100 20TN REAR INTRUSION SENSOR SIGNAL 2 B200 20BK SENSOR GROUND 3- - REAR MODE MOTOR (3 ZONE ATC) - GRAY 2 WAY CAV CIRCUIT FUNCTION

Page 1099 of 2177

CHRYSLER CARAVAN 2003 Service Manual REAR WASHER PUMP MOTOR - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 W20 18BR/YL REAR WASHER PUMP MOTOR CONTROL 2 F301 18VT/PK FUSED ACCESSORY RELAY OUTPUT REAR WIPER MOTOR - GRAY 3 WAY CAV CIRCUIT FUNCTION 1

Page 1100 of 2177

CHRYSLER CARAVAN 2003 Service Manual REMOTE KEYLESS ENTRY ANTENNA (JAPAN) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 D10 18WT REMOTE KEYLESS ENTRY ANTENNA (+) 2 D10 18WT/LB REMOTE KEYLESS ENTRY ANTENNA (-) REMOTE KEYLESS ENTRY MODULE - BLACK 6

Page 1101 of 2177

CHRYSLER CARAVAN 2003 Service Manual RIGHT COMBINATION RELAY (TRAILER TOW) - BLACK 5 WAY CAV CIRCUIT FUNCTION 1 L62 18WT/BR RIGHT REAR TURN SIGNAL DRIVER 1 L62 18WT/BR RIGHT REAR TURN SIGNAL DRIVER 2 Z1 18BK/DG GROUND 3 L50 18WT/TN BRAKE

Page 1102 of 2177

CHRYSLER CARAVAN 2003 Service Manual RIGHT FOG LAMP (EXCEPT EXPORT) - BLACK 2 WAY CAV CIRCUIT FUNCTION A L90 18WT/OR FRONT FOG LAMP RELAY OUTPUT B Z348 18BK/OR GROUND RIGHT FOG LAMP (EXPORT) - WHITE 2 WAY CAV CIRCUIT FUNCTION 1 L90 18WT/

Page 1103 of 2177

CHRYSLER CARAVAN 2003 Service Manual RIGHT FRONT WHEEL SPEED SENSOR - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 B7 18DG/VT RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT SUPPLY 2 B6 18DG/WT RIGHT FRONT WHEEL SPEED SENSOR SIGNAL RIGHT FULL OPEN SWITCH (P

Page 1104 of 2177

CHRYSLER CARAVAN 2003 Service Manual RIGHT HIGH BEAM LAMP (EXPORT) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 Z344 16BR GROUND 1 Z344 16BR GROUND 2 L34 16GY RIGHT HIGH BEAM DRIVER RIGHT INSTRUMENT PANEL SPEAKER - BLACK 2 WAY CAV CIRCUIT FUNCTI
