Page 1521 of 2177

CHRYSLER CARAVAN 2003 Service Manual (6) Remove four (4) center console-to-gearshift mechanism screws. Remove console assembly (Fig. 134). (7) Remove center console support bracket (Fig. 135).(8) Remove crossover cable retainer clip (Fig

Page 1522 of 2177

CHRYSLER CARAVAN 2003 Service Manual (10)2.4L Gas equipped models goto Step 15. 2.5L TD models:Remove battery thermal shield (Fig. 138). (11) Remove battery hold down nut, clamp, and battery (Fig. 139).(12) Remove battery tray (Fig. 140)

Page 1523 of 2177

CHRYSLER CARAVAN 2003 Service Manual (15) Disconnect crossover cable from transaxle crossover lever (Fig. 142). (16) Remove crossover cable retainer clip and dis- engage cable from mount bracket (Fig. 142). (17) Raise vehicle on hoist. (

Page 1524 of 2177

CHRYSLER CARAVAN 2003 Service Manual (6) Install coolant recovery bottle to bracket. (7) Connect battery temperature sensor to battery tray. Install battery tray into position (Fig. 145). (8) Install battery, hold-down clamp, and nut (Fi

Page 1525 of 2177

CHRYSLER CARAVAN 2003 Service Manual (11) Adjust crossover cable (Refer to 21 - TRANS- MISSION/TRANSAXLE/MANUAL/GEAR SHIFT CABLE - ADJUSTMENTS). (12) Install center console support bracket (Fig. 150). Torque support bracket-to-gearshift

Page 1526 of 2177

CHRYSLER CARAVAN 2003 Service Manual (15) Install gearshift boot to console (Fig. 153). Secure with three (3) retainer clips. (16) Install gearshift knob to gearshift lever (Fig. 154). Orient shift pattern 1¤4-turn clockwise, push down

Page 1527 of 2177

CHRYSLER CARAVAN 2003 Service Manual (4) Apply park brake to allow park brake handle to clear center console upon removal. (5) Remove two (2) cupholder bottom plugs (Fig. 157). (6) Remove four (4) center console-to-gearshift mechanism sc

Page 1528 of 2177

CHRYSLER CARAVAN 2003 Service Manual GEARSHIFT CABLE - SELECTOR REMOVAL (1) Disconnect battery negative cable. (2) Remove gearshift knob by pushing down and rotating 1¤4-turn clock-wise (Fig. 160). (3) Remove gearshift boot from center
