CHRYSLER CARAVAN 2003 Service Manual LEFT LIFTGATE FLOOD LAMP - GRAY 3 WAY CAV CIRCUIT FUNCTION 1 Z311 20BK/VT GROUND 1 Z312 20BK/YL GROUND 2- - 3 M11 20YL/VT COURTESY LAMPS DRIVER LEFT LOW BEAM LAMP (EXPORT) - BLACK 2 WAY CAV CIRCUIT FU

Page 1066 of 2177

CHRYSLER CARAVAN 2003 Service Manual LEFT REAR LAMP ASSEMBLY - BLACK 6 WAY CAV CIRCUIT FUNCTION 1 Z363 18BK/DG (EXPORT) GROUND 1 L63 18WT/DG (EXCEPT EXPORT) LEFT REAR TURN SIGNAL DRIVER 2 L63 18WT/DG (EXPORT) LEFT REAR TURN SIGNAL DRIVER

Page 1067 of 2177

CHRYSLER CARAVAN 2003 Service Manual LEFT REAR SPEAKER (MIDLINE/HIGHLINE) - BLACK/RED 6 WAY CAV CIRCUIT FUNCTION 1 X151 20DG/WT (HIGHLINE) LEFT REAR PILLAR SPEAKER (+) 2 X15 16GY/DG (HIGHLINE) AMPLIFIED SPEAKER GROUND 3 X157 20DG (HIGHLI

Page 1068 of 2177

CHRYSLER CARAVAN 2003 Service Manual LEFT REPEATER LAMP (EXPORT) - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 A701 18BR/RD FUSED B(+) 2 L163 20WT/BR LEFT SIDE REPEATER LAMP FEED LEFT SEAT AIRBAG - YELLOW 2 WAY CAV CIRCUIT FUNCTION 1 R33 18WT/BK (

Page 1069 of 2177

CHRYSLER CARAVAN 2003 Service Manual LEFT SLIDING DOOR CONTROL MODULE C2 (POWER SLIDING DOOR) - BLACK/RED 2 WAY CAV CIRCUIT FUNCTION 1 Q71 20TN/VT LEFT DOOR MOTOR HALL EFFECT SUPPLY 2- - 3 Q35 20OR/GY LEFT DOOR LOCK SENSE 4 Q55 20OR/BR L

Page 1070 of 2177

CHRYSLER CARAVAN 2003 Service Manual LEFT SLIDING DOOR LOCK MOTOR/AJAR SWITCH (MANUAL SLIDING DOOR) - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 P5 20BK/DB LEFT SLIDING DOOR UNLOCK DRIVER 2 P32 20BK/TN LEFT SLIDING DOOR LOCK DRIVER 3 G77 20BK/DG

Page 1071 of 2177

CHRYSLER CARAVAN 2003 Service Manual LEFT TURN SIGNAL LAMP (EXPORT) - ORANGE 2 WAY CAV CIRCUIT FUNCTION 1 Z343 16BR GROUND 2 L61 16YL LEFT FRONT TURN SIGNAL DRIVER LEFT VISOR/VANITY LAMP (EXCEPT BASE) - BLACK 2 WAY CAV CIRCUIT FUNCTION A

Page 1072 of 2177

CHRYSLER CARAVAN 2003 Service Manual LICENSE LAMP (POWER RELEASE) - DK. GRAY 4 WAY CAV CIRCUIT FUNCTION 1 L77 18WT/BR FUSED PARK LAMP RELAY OUTPUT (LEFT) 2 Z367 20BK/BR GROUND 3 P30 20TN/DG LIFTGATE HANDLE SWITCH SENSE 4 Z430 20BK/LG GRO
