Page 1033 of 2177

CHRYSLER CARAVAN 2003 Service Manual CLOCKSPRING C2 - YELLOW 4 WAY CAV CIRCUIT FUNCTION 1 R61 18LG/DB DRIVER SQUIB 2 LINE 1 2 R63 18LG/WT DRIVER SQUIB 2 LINE 2 3 R43 18LG/BR DRIVER SQUIB 1 LINE 1 4 R45 18LG/OR DRIVER SQUIB 1 LINE 2 CLOCK

Page 1034 of 2177

CHRYSLER CARAVAN 2003 Service Manual CONTROLLER ANTILOCK BRAKE - BLACK 24 WAY CAV CIRCUIT FUNCTION 1 Z107 12BK/DG GROUND 2 B1 18DG/OR RIGHT REAR WHEEL SPEED SENSOR SIGNAL 3 B2 18DG/LB RIGHT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 4- - 5 D

Page 1035 of 2177

CHRYSLER CARAVAN 2003 Service Manual CRANKSHAFT POSITION SENSOR (GAS) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 F888 18BR/PK (3.3L/3.8L) 8 VOLT SUPPLY 1 F855 20PK/YL (2.4L) 5 VOLT SUPPLY 2 K900 18DB/DG (3.3L/3.8L) SENSOR GROUND 2 K900 20DB/DG

Page 1036 of 2177

CHRYSLER CARAVAN 2003 Service Manual DRIVER AIRBAG SQUIB 1 - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 R43 20OR/LB DRIVER SQUIB 1 LINE 1 2 R45 20TN/LB DRIVER SQUIB 1 LINE 2 DRIVER AIRBAG SQUIB 2 - BROWN 2 WAY CAV CIRCUIT FUNCTION 1 R61 20BK/LB

Page 1037 of 2177

CHRYSLER CARAVAN 2003 Service Manual DRIVER DOOR COURTESY LAMP - GRAY 3 WAY CAV CIRCUIT FUNCTION 1 Z321 20BK/BR (LHD) GROUND 1 Z322 20BK/BR (RHD) GROUND 2- - 3 M21 20YL/BR COURTESY LAMPS DRIVER DRIVER DOOR LOCK SWITCH - BLACK 3 WAY CAV C

Page 1038 of 2177

CHRYSLER CARAVAN 2003 Service Manual DRIVER HEATED SEAT MODULE C2 - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 S1 18RD (RHD) SEAT BACK HEATER B(+) DRIVER 1 S1 18DB (LHD) SEAT BACK HEATER B(+) DRIVER 2 S2 18DG (LHD) SEAT BACK HEATER GROUND 2 S2 18

Page 1039 of 2177

CHRYSLER CARAVAN 2003 Service Manual DRIVER POWER SEAT HORIZONTAL MOTOR - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 P17 14LG/DG DRIVER SEAT HORIZONTAL REARWARD SWITCH SENSE 1 P115 14LG (RHD) (MEMORY) SEAT HORIZONTAL FORWARD DRIVER 1 P117 14LG/L

Page 1040 of 2177

CHRYSLER CARAVAN 2003 Service Manual DRIVER POWER SEAT RECLINER POSITION SENSOR - BLACK 3 WAY CAV CIRCUIT FUNCTION A P29 20LG/WT SEAT SENSOR 5 VOLT SUPPLY B P47 20LG/LB RECLINER POSITION SIGNAL C P28 20LG/BR SEAT POSITION SENSOR GROUND D
