CHRYSLER CARAVAN 2003 Service Manual LIFTGATE CINCH/RELEASE MOTOR (POWER LIFTGATE) - BLUE 7 WAY CAV CIRCUIT FUNCTION 1 Z78 20BK/OR GROUND 2 G78 20VT/OR LIFTGATE AJAR SWITCH SENSE 3 Q60 20OR/YL LIFTGATE PAWL SWITCH SENSE 4 Z245 18BK/GY GR

Page 1074 of 2177

CHRYSLER CARAVAN 2003 Service Manual MANIFOLD ABSOLUTE PRESSURE SENSOR (GAS) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K1 18VT/BR (3.3L/3.8L) MANIFOLD ABSOLUTE PRESSURE SENSOR SIGNAL 1 K1 18VT/BR (2.4L) MAP SIGNAL 2 K900 18DB/DG SENSOR GROUND

Page 1075 of 2177

CHRYSLER CARAVAN 2003 Service Manual MEMORY SEAT/MIRROR MODULE C2 - GRAY 16 WAY CAV CIRCUIT FUNCTION 1- - 2- - 3 P73 18TN/LB LEFT MIRROR COMMON DRIVER (RIGHT/DOWN) 4 P75 18DB LEFT MIRROR LEFT DRIVER 5 P71 18TN/GY LEFT MIRROR UP DRIVER 6

Page 1076 of 2177

CHRYSLER CARAVAN 2003 Service Manual MEMORY SET SWITCH - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 G200 20VT/BR MEMORY SELECT SWITCH MUX 2 G920 20VT/YL MEMORY SELECT SWITCH RETURN MESSAGE CENTER (HIGHLINE) - WHITE 14 WAY CAV CIRCUIT FUNCTION 1

Page 1077 of 2177

CHRYSLER CARAVAN 2003 Service Manual MULTI-FUNCTION SWITCH - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 W52 22BR/YL FRONT WIPER SWITCH MUX 2 G902 22VT/LB MULTI-FUNCTION SWITCH MUX RETURN 3 L305 20WT/LB TURN SIGNAL SWITCH MUX 4 G194 22VT/LG HIGH

Page 1078 of 2177

CHRYSLER CARAVAN 2003 Service Manual OXYGEN SENSOR 1/1 UPSTREAM (GAS) - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 K99 18BR/LG (3.3L/3.8L) OXYGEN SENSOR 1/1 HEATER CONTROL 1 Z42 18BK/LG (2.4L) GROUND 2 K99 18BR/LG (2.4L) O2 1/1 HEATER CONTROL 2

Page 1079 of 2177

CHRYSLER CARAVAN 2003 Service Manual PASSENGER BLEND DOOR ACTUATOR (MTC) - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 C34 20DB/LB (LHD) COMMON DOOR DRIVER (B) 1 C33 20LB/BR (RHD) PASSENGER BLEND DOOR DRIVER (A) 2 C33 20LB/BR (LHD) PASSENGER BLEND

Page 1080 of 2177

CHRYSLER CARAVAN 2003 Service Manual PASSENGER HEATED SEAT BACK - GREEN 2 WAY CAV CIRCUIT FUNCTION B S1 18WT (RHD) SEAT BACK HEATER B(+) DRIVER B S2 18GY (LHD) SEAT BACK HEATER GROUND A S2 18GY (RHD) SEAT BACK HEATER GROUND A S1 18WT (LH
