62make your vehicle move slightly faster than its
normal idle speed. It should, however, slow
down after a short time. If it does not, have the
idle speed checked.
*
[ST07350( ALL)06/95]
If the engine idle speed does not slow down
automatically, do not allow your vehicle to idle
for more than 10 minutes. Have the vehicle
checked.
*
[ST07400( ALL)05/95]
RWARNING
Extended idling at high engine speeds can
produce very high temperatures in the
engine and exhaust system, creating the
risk of fire or other damage.
*
[ST07450( ALL)05/95]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[ST07500(BEF )03/95]
If you consistently start your vehicle in subzero
temperatures, use an engine block heater (if
your vehicle has this option).
%*
[ST07600(BEF )06/95]
Engine Block Heater (If equipped)
*
[ST07700(BEF )03/95]
Engine block heaters are strongly recommended
if you live in a region where temperatures reach
-10ÊF (-23ÊC) orbelow. An engine block heater
warms the engine coolant, which improves
starting, warms up the engine faster, and allows
the heater-defrost system to respond quickly.
*
[ST08000(BEF )05/95]
RWARNING
To prevent electrical shock, do not use
your heater with ungrounded electrical
systems or two-pronged (cheater) adapters.
File:04ltste.ex
Update:Wed Apr 17 08:49:38 1996

63
*
[ST08100(BEF )03/95]
For best results, plug the heater in at least three
hours before you start your vehicle. Using the
heater for longer than three hours will not
damage the engine, so you can plug it in at
night to start your vehicle the following
morning.
*
[ST08150(BEF )12/91]
NOTE: Be sure to disconnect the engine block
heater before driving your vehicle.
*
[ST08160( ALL)03/95]
If the Engine Cranks but Does
Not Start or Does Not Start After
a Collision
%*
[ST08170(BEF )04/95]
Fuel Pump Shut-off Switch
*
[ST08190( ALL)03/95]
If the engine cranks but does not start or does
not start after a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device intended to stop the fuel
pump when your vehicle has been involved in a
substantial jolt.
*
[ST08200( ALL)03/95]
Once the shut-off switch is triggered, you must
reset the switch by hand before you can start
your vehicle.
[ST08230( E )02/95]
one third page art:0020008-A
Fuel pump shut-off switch location
File:04ltste.ex
Update:Wed Apr 17 08:49:38 1996

64 [ST08240( E )02/95]
one third page art:0020988-AFuel pump shut-off switch location Ð Commercial stripped
chassis vehicles
*
[ST08260( ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
*
[ST08270( ALL)03/95]
If your engine cranks but does not start after a
collision or substantial jolt:
*
[ST08280( ALL)04/95]
1. Turn the ignition key to the OFF position.
*
[ST08290( ALL)03/95]
2. Check under the vehicle for leaking fuel.
*
[ST08300( ALL)03/95]
3. If you do not see or smell fuel, push the red
reset button down. If the button is already
set, you may have a different mechanical
problem.
*
[ST08310(BEF )03/95]
4. Turn the ignition key to the ON position for
a few seconds, then turn it to the OFF
position.
*
[ST08330( ALL)03/95]
5. Check under the vehicle again for leaking
fuel.If you see or smell fuel, do not start
your vehicle again.If you do not see or
smell fuel, you can try to start your vehicle
again.
File:04ltste.ex
Update:Wed Apr 17 08:49:38 1996

65
*
[ST08340( ALL)03/95]
6. Check all vehicle warning lights before
driving your vehicle.
*
[ST08350(BEF )03/95]
quarter page art:0020107-A
Reset button for fuel pump shut-off switch
%*
[ST09300( ALL)05/95]
Guarding Against Exhaust Fumes
*
[ST09400( ALL)02/95]
Carbon monoxide, although colorless and
odorless, is present in exhaust fumes. Take
precautions to avoid its dangerous effects.
*
[ST09500( ALL)05/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
*
[ST09600( ALL)05/95]
RWARNING
If you smell exhaust fumes inside your
vehicle, have your dealer inspect your
vehicle immediately. Do not drive if you
smell exhaust fumes.
*
[ST09700( E )03/95]
If your vehicle has rear windows and doors that
were installed as part of a van conversion, close
them while it is running. This prevents exhaust
fumes from being drawn into the passenger
compartment.
File:04ltste.ex
Update:Wed Apr 17 08:49:38 1996

66
*
[ST09900( ALL)01/95]
Have the exhaust and body ventilation systems
checked whenever:
*
[ST10000( ALL)02/95]
q
your vehicle is raised for service
*
[ST10100( ALL)02/95]
q
the sound of the exhaust system changes
*
[ST10200( ALL)01/95]
q
your vehicle has been damaged in a collision
*
[ST10300( ALL)01/95]
Improve your ventilation by keeping all air inlet
vents clear of snow, leaves, and other debris.
*
[ST10400( ALL)03/95]
If the engine is idling while you are stopped in
an open area for long periods of time, open the
windows at least one inch (2.5 cm). Also, adjust
the heating or air conditioning to bring in
outside air.
[ST10500( E )03/91]
q
HEATING Ð Set fan speed on MEDIUM or
HIGH, with the function control lever on
FLOOR, DEFROST or VENT and the
temperature control lever on any desired
position.
[ST10700( E )03/91]
q
AIR CONDITIONING Ð Set fan speed on
MEDIUM or HIGH with the function control
lever on any position (except OFF or MAX)
and the temperature control lever at a
comfortable level.
File:04ltste.ex
Update:Wed Apr 17 08:49:38 1996

67
Warning Lights and
Gauges
*
[LG00400( ALL)01/95]
The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
*
[LG00525( E M)12/91]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping a cluster. Your vehicle has
a mechanical cluster.
File:05ltlge.ex
Update:Wed Apr 17 08:49:15 1996

68 [LG02600( E )05/95]
full page art:0020042-JMechanical cluster
File:05ltlge.ex
Update:Wed Apr 17 08:49:15 1996

69
%*
[LG03000( ALL)06/94]
The Mechanical Cluster
*
[LG03100( ALL)06/93]
The following warning lights and gauges are on
the mechanical cluster. All of the warning lights
and gauges alert you to possible problems with
your vehicle. Some of the lights listed are
optional. The following sections detail what each
of these indicators means.
*
[LG03200( ALL)06/95]
Brake System Warning Light
*
[LG03350( EF )06/92]
The red warning light for the brakes can show
three things Ð that either the parking brake is
not fully released, that the brake fluid level is
low in the master cylinder reservoir or the
vacuum pressure is low on diesel engine
vehicles. If the fluid level is low, the brake
system should be checked by a qualified service
technician.
*
[LG03400( ALL)05/94]
This light comes on when you turn the ignition
key to START to verify that the indicator bulb is
working. If the light stays on or comes on after
you have released the parking brake fully, have
the hydraulic brake system serviced.
*
[LG03500( ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
*
[LG03600( ALL)05/95]
one inch art:0020044-A
Brake warning light symbols
File:05ltlge.ex
Update:Wed Apr 17 08:49:15 1996
