Checking the Automatic Transmission
Fluid
*
[SV33701( ALL)05/95]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66ÊC-77ÊC),after approximately 20
miles (30 km) of driving. However, if necessary,
you can check the fluid level without having to
drive 20 miles (30 km) to obtain a normal
operating temperature if outside temperatures
are above50ÊF (10ÊC).
*
[SV33801( ALL)01/95]
NOTE: If the vehicle has been operated for an
extended period at high speeds or in
city traffic during hot weather, or
pulling a trailer, the vehicle should be
turned off for about 30 minutes to
allow the fluid to cool before checking.
*
[SV33910( ALL)06/95]
With the vehicle on a level surface, start the
engine and move the transmission shift selector
through all of the gear ranges allowing sufficient
time for each position to engage. Securely latch
the transmission shift selector in the P (Park)
position, fully set the parking brake and leave
the engine running.
*
[SV33930( ALL)10/89]
RWARNING
Your vehicle should not be driven if the
fluid level is below the bottom hole on
the dipstick and outside temperatures are
above50ÊF (10ÊC).
*
[SV33940( ALL)02/95]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

324
*
[SV33950( ALL)03/90]
When checking fluid at normal operating
temperature, the fluid level should be within the
crosshatched area on the dipstick. When the
vehicle has not been driven, and outside
temperature is above50ÊF (10ÊC), thefluid level
should be between the holes on the dipstick.
%*
[SV33960( ALL)05/95]
Adding Automatic Transmission Fluid
*
[SV33970( ALL)03/94]
The fluid type is stamped on the dipstick. Before
adding any fluid, be sure that the correct type
will be used.
*
[SV33980( ALL)10/89]
Add fluid in 1/2 pint (.25L) increments through
the filler tube to bring the level to the correct
area on the dipstick. If an overfill occurs, excess
fluid should be removed by a qualified
technician.
%*
[SV33990( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV34100( EF )03/94]
one third page art:0020946-A
Automatic transmission dipstick
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

325 [SV34200( E )03/93]
half page art:0020374-C
Automatic transmission dipstick location
[SV34300( E )12/91]
one third page art:0020375-B
Automatic transmission dipstick location
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

326 %
*
[SV35800( ALL)03/91]
Driveline Universal Joint and
Slip Yoke
*
[SV36000(BEF )06/93]
The universal joints that come standard with
your vehicle do not require lubrication. If your
original equipment universal joints are replaced
with universal joints equipped with grease
fittings, lubrication will be necessary at the
intervals shown in theMaintenance Schedule and
Recordbooklet.
*
[SV36300( ALL)03/95]
Brake Fluid
*
[SV36350( ALL)05/90]
Your vehicle is equipped with a brake fluid level
indicator in the master cylinder which lights the
BRAKE warning light on the instrument panel
when the brake fluid level is low.
*
[SV36400( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
*
[SV36500( ALL)10/89]
Check the brake fluid at least once a year. You
can do this by looking at the fluid level in the
plastic reservoir on the master cylinder. The
fluid level should be at or near the MAX mark.
*
[SV36550( ALL)05/95]
RWARNING
Brake fluid is toxic.
*
[SV36560( ALL)06/95]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
%*
[SV36600( ALL)02/95]
If the fluid is low, carefully clean and remove
the filler cap from the reservoir. Fill the
reservoir to the MAX line with Ford High
Performance DOT 3 Brake Fluid C6AZ-19542-AA
or DOT 3 equivalent fluid meeting Ford
specification ESA-M6C25-A.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

327
*
[SV36850( ALL)12/91]
NOTE: If brake fluid is spilled on painted
surfaces, it must be flushed and wiped
away immediately. Brake fluid may
dissolve the paint finish on your
vehicle.
*
[SV36900( ALL)01/95]
RWARNING
If you use a brake fluid that is not DOT
3, you will cause permanent damage to
your brakes.
*
[SV37000( ALL)01/95]
Do not fill the reservoir above the MAX line.
*
[SV37100( ALL)01/95]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
*
[SV37200( ALL)01/95]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
*
[SV37400(BEF )01/89]
quarter page art:0020381-A
Brake master cylinder
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

328
*
[SV37600( ALL)03/95]
Power Steering Fluid
*
[SV37700( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
*
[SV37800( ALL)03/95]
To check the level of your power steering fluid:
*
[SV37900( ALL)02/95]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[SV38000( ALL)01/95]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[SV38100(BEF )05/95]
3. Turn the engine off.
[SV38150( E)10/95]
All vehicles except E-Super Duty:
%*
[SV38200( ALL)03/94]
4. Check the fluid level on the dipstick (which
is highlighted in yellow in your vehicle). The
fluid level should be between the arrows in
the FULL HOT range, which is marked on
the side of the dipstick, opposite the side
marked FULL COLD. Do not add fluid if the
level is within the FULL HOT range.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

329
*
[SV38250( ALL)03/94]
one third page art:0021016-B
Power steering dipstick
[SV38700( E )08/91]
quarter page art:0020387-A
Power steering reservoir
*
[SV38800( ALL)07/94]
5. If the power steering fluid is low, add fluid
in small amounts, continuously checking the
level, until you reach the FULL HOT range.
Do not overfill.
*
[SV38850( ALL)03/95]
6. When you are finished, put the dipstick back
in and make sure that it fits snugly.
*
[SV38855( ALL)02/95]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the FULL
COLD range on the dipstick. The reading will
only be accurate if the fluid temperature is
approximately50ÊF to 85ÊF (10ÊC to 30ÊC).
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

330 [SV38860(E )10/95]E-Super Duty vehicles:
[SV38870( E)10/95]
4. Check the fluid level in the power steering
fluid reservoir. The fluid level should be
between the MIN and MAX lines on the side
of the reservoir.
[SV38880( E)10/95]
5. If the power steering fluid is below the MIN
mark, add fluid in small amounts until the
level is between the MIN and MAX lines on
the side of the reservoir.
[SV38890(E )10/95]
half page art:0021528-A
Power steering reservoir
*
[SV38895( E)10/95]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the MIN
on the reservoir. The reading will only be
accurate if the fluid temperature is
approximately50ÊF to 85ÊF (10ÊC to 30ÊC).
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996
