NOTE: You may notice that the lights flicker
when the vehicle is turned on or off.
This is a normal condition.
*
[IP17890(BEF )05/95]
RWARNING
The Daytime Running Light (DRL) system
will not illuminate the tail lamps and
parking lamps. Turn on your headlamps
at dusk. Failure to do so may result in a
collision.
*
[IP17900(BEF )03/95]
Lighting Up the Instrument Panel and the
Interior of Your Vehicle
*
[IP18000(BEF )03/95]
The instrument panel lights can be turned on by
pulling the headlamp switch toward you to
either the first or outer position. You can
brighten or dim the instrument panel lights by
rotating the headlamp switch knob.
%*
[IP18400(BEF )03/95]
Cargo, Courtesy and Dome Lamps
*
[IP18700(BE )12/91]
Rear cargo lamps, equipped with an
ON/OFF/DOOR switch will light when the
doors are closed and the switch is in the ON
position.
[IP18900( E )03/91]
The standard dome lamp and cargo lamp (with
switch in DOOR position, if so equipped)
operate as courtesy lamps when either front
door is opened. Both the dome lamp and cargo
lamp can be turned on by rotating the headlamp
switch knob.
File:06ltipe.ex
Update:Wed Apr 17 08:48:31 1996

95 [IP18950( E )12/91]
When the cargo lamp switch (if so equipped) is
in the ªOFFº position, it will not turn on when
you open the doors or turn the headlamp switch
knob.
*
[IP19000(BE )05/95]
quarter page art:0020125-B
Rear cargo lamp with rear headliner
[IP19050( E )05/95]
quarter page art:0020829-A
Cargo lamp without rear headliner
File:06ltipe.ex
Update:Wed Apr 17 08:48:31 1996

96
*
[IP19425( E )10/94]
High-mount Brakelamp
[IP19465( E )02/92]
The highmount brakelamp is located outside the
vehicle, directly over the rear doors.
[IP19485( E )02/92]
one third page art:0020926-B
Highmount stoplamp
*
[IP20010( E )01/95]
Front and Rear Courtesy/Reading Lamps
[IP20020( E )05/91]
Your vehicle may be equipped with either one
courtesy/reading lamp located at the front-center
or three courtesy/reading lamps located at the
front-center, mid-center and rear-center of the
headliner (roof). The right lamps are for the
right side passengers and the left lamps are for
the driver and rear left side passenger.
*
[IP20030( E )05/95]
With the lens in the flat position, the
courtesy/reading lamp will illuminate when any
door is opened or when the headlamp dimmer
knob is rotated to the courtesy lamp position.
*
[IP20040( E )01/95]
With the lens in the rotated position, the
courtesy/reading lamp will illuminate.
File:06ltipe.ex
Update:Wed Apr 17 08:48:31 1996

97 [IP20050( E )03/91]
one third page art:0010480-C
Courtesy/reading lamps
%*
[IP20060(BEF )04/95]
Cleaning the Instrument Panel Lens
*
[IP20070(BEF )04/95]
Clean the instrument panel lens with a soft cloth
and a glass cleaner, such as Ford Ultra-Clear
Spray Glass Cleaner, or equivalent. Do not use
paper towel or an abrasive cleaner to clean the
lens as these may cause scratches.
%*
[IP20075(BEF )04/95]
Cleaning the Interior Lamps
*
[IP20080(BEF )04/95]
Your interior dome lamps and map lamps are
plastic and should be cleaned with a mild
detergent diluted in water. Rinse them with clear
water.
File:06ltipe.ex
Update:Wed Apr 17 08:48:31 1996

99
Steering Column Controls
*
[SC00400( ALL)01/95]
The controls on the steering column and wheel
are designed to give you easy access to the
controls while you are driving.
*
[SC00500( ALL)01/95]
The Turn Signal Lever
*
[SC00600( ALL)01/95]
You can use the turn signal lever on the left side
of the steering column to:
*
[SC00700( ALL)03/95]
q
operate the turn signals and cornering lamps
*
[SC00800(BEF )01/95]
q
turn the high beams on/off
*
[SC00900(BEF )05/95]
q
flash the lamps
*
[SC01000(BEF )01/95]
q
turn the windshield wipers and washer
on/off
*
[SC01100( ALL)01/95]
Turn Signals
*
[SC01200( ALL)03/95]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
*
[SC01400( ALL)03/95]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
File:07ltsce.ex
Update:Wed Apr 17 08:47:45 1996

100
*
[SC01700( ALL)05/95]
one third page art:0020081-C
Turn signal lever and functions
*
[SC01800( ALL)11/89]
If the turn indicator light in the instrument
panel does not illuminate or remains on (doesn't
flash) when you signal a turn, the turn signaling
system is malfunctioning. Have this condition
corrected as soon as possible, but make sure that
you use the accepted hand signals in the
meantime.
*
[SC03200( ALL)05/95]
High Beams
*
[SC03300( ALL)05/95]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[SC03400( ALL)05/95]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
File:07ltsce.ex
Update:Wed Apr 17 08:47:45 1996

101
*
[SC03800( ALL)05/95]
one third page art:0020074-B
Headlamp high beam switch and turn signal lever
*
[SC04200( ALL)05/95]
Flashing the Lights
*
[SC04300( ALL)06/95]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
*
[SC04400( ALL)03/95]
Windshield Wipers and Washer
*
[SC04500( ALL)03/95]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
*
[SC04600( ALL)05/95]
Turn the knob on the end of the turn signal
lever toward the front of the vehicle. You can
turn it to either the LO or HI speed position.
File:07ltsce.ex
Update:Wed Apr 17 08:47:45 1996

102
*
[SC04700( ALL)05/95]
Variable Interval Wipers
*
[SC04800( ALL)03/95]
In addition to two speed wipers, your vehicle is
equipped with wipers that you can set to
operate at varying intervals. For example, you
can set the interval so they wipe less often when
it drizzles or more often in heavier rain.
*
[SC04950( ALL)05/95]
one third page art:0020831-A
Interval wiper on turn signal lever
*
[SC05000( ALL)02/95]
To set the interval wipers, rotate the knob at the
end of the turn signal lever toward or away
from the instrument panel to the interval
operation you desire.
*
[SC05100( ALL)05/95]
Windshield Washer
*
[SC05200( ALL)05/95]
To clean the windshield, push in the end of the
wiper knob. For a constant spray, keep the knob
pushed in. After you release the knob, the
wipers operate for two to three cycles before
turning off (if wipers were off) or returning to
the interval selected.
*
[SC05300( ALL)01/95]
Do not try to clean the windshield when the
washer fluid container is empty or activate the
washers at any time for more than 15 seconds
continuously. This could damage the washer
pump system.
File:07ltsce.ex
