1996 FORD E SERIES Owners Manual

144 %
*
[FV52900(BEF )06/95]
Outside Mirrors (Manual Control)
*
[FV53000(BEF )06/95]
Adjust outside mirrors with the door closed and
the seat adjusted for comfort and proper vehicle
control. Move the mirrors for best view by
tilting up or down, left or right.
*
[FV53100(BEF )06/95]
On vehicles equipped with fold-away mirrors,
the mirrors should be folded rearward into the
body position before entering automatic car
wash systems.
[FV53600( E )05/95]
one third page art:0020884-C
Outside mirrors Ð manual control
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

145 [FV53700( E )05/91]
half page art:0020885-A
Outside mirrors Ð manual control
*
[FV53900( EF )05/90]
On vehicles equipped with ªnonº folding
(swing-out recreational) mirrors, automatic car
wash systems are not recommended. Use special
truck wash facilities for vehicles with this type
of mirror.
[FV54200( E )11/90]
For the Econoline van without rear door
windows and all Econolines equipped with the
swing-out recreational mirrors, the right-hand
side mirror is a flat glass mirror. All other
right-hand side/view mirrors used on the
Econoline are convex. Convex mirrors have a
curved surface and will show a wider view of
the lane next to and behind your vehicle.
*
[FV54400(BEF )05/95]
RWARNING
The side view mirror on the right makes
objects appear smaller and farther away
than they actually are.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

146
*
[FV54500(BEF )08/91]
Dual Electric Remote Control Mirrors
(If equipped)
*
[FV54600(BEF )08/91]
To adjust the remote controlled side mirrors:
*
[FV54800(BEF )06/94]
1. Find the control switch in the driver's door
panel.
*
[FV55000(BEF )06/94]
2. Select the right or left mirror by moving the
selector switch to R or L.
*
[FV55200(BEF )06/94]
3. Move the control knob in the direction you
want to move the mirror.
*
[FV55400(BEF )06/94]
4. Return the selector switch to the middle
position to keep the mirror in place.
[FV55600( E )12/91]
quarter page art:0020908-A
Power mirror control
*
[FV55900(BEF )12/91]
Do not clean the plastic housing of any electric
mirror with gasoline or other petroleum-based
cleaning products.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

147
*
[FV59400(BEF )01/95]
Console
*
[FV59500(BEF )12/91]
Your vehicle may have a full console. The full
console has the features shown in the illustration
below.
[FV60000( E )03/94]
half page art:0020682-D
The features on the console
[FV60050( E )03/94]
1. To install the table, locate the tabs into the
slots on the engine cover and push.
[FV60055( E )03/94]
2. To store table, lift at handle.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

148
%*
[FV69900(BEF )03/95]
Power Point Electrical Outlet
[FV70100( E )06/92]
The power point outlet is located in the left
hand (driver's side) quarter panel, next to the
rear ashtray. This outlet should be used in place
of the cigarette lighter for optional electrical
accessories.
*
[FV70200(BEF )06/92]
NOTE: Do not use the cigarette lighter in
place of the power point.
[FV70400( E )06/92]
quarter page art:0020930-A
Power point electrical outlet
[FV70600( E )07/92]
To access the outlet, press down while rotating
the cover counterclockwise.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

149
Electronic Sound Systems
*
[AS01100(BEF )04/95]
full page art:0060648-B
Compact Disc Radio
File:09ltase.ex
Update:Wed Apr 17 08:44:51 1996

150
%*
[AS01200(BEF )05/95]
Compact Disc Radio
*
[AS01250(BEF )05/95]
The Compact Disc Radio combines the Electronic
Stereo Radio with the Ford Compact Disc Player.
*
[AS01300(BEF )04/95]
Using the Controls on Your New Radio/CD
Player
*
[AS01400(BEF )04/95]
Most of the features of this unit work for both
radio and CD operation. Also, some of the knobs
and buttons control several different functions,
so be sure to read all of the operating
instructions carefully.
*
[AS01500(BEF )06/95]
How to turn the radio on and off
*
[AS01600(BEF )06/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS01625(BEF )06/95]
How to adjust the volume
*
[AS01650(BEF )06/95]
Press the +/Sside of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS01675(BEF )06/95]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off (with the
ªPOWERº button), the volume will
remain in the position it was set at
when radio power is switched back on.
*
[AS01700(BEF )06/95]
Selecting the AM or FM frequency band
*
[AS01800(BEF )06/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to tune radio stations.
File:09ltase.ex
Update:Wed Apr 17 08:44:51 1996

151 %
*
[AS01900(BEF )05/95]
How to tune radio stations
*
[AS02000(BEF )07/94]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS02100(BEF )04/95]
q
Using the ªSCAN/TUNEº button to manually
tune
*
[AS02200(BEF )06/95]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐ pressing and releasing either the
top
aor bottom
bhalf of the ªSEEKº
button. To change frequencies quickly, press
andhold downeither the top or bottom half
of the ªSEEKº button. While you are
manually tuning, the display will show a
blinking ªMº.
*
[AS02300(BEF )04/95]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
